FB rx7 wiper arm conversion - RX7Club.com - Mazda RX7 Forum

1st Generation Specific (1979-1985) 1979-1985 Discussion including performance modifications and technical support sections

FB rx7 wiper arm conversion

Old 05-20-18, 10:25 PM
  #1
Newbie
Thread Starter

Join Date: Jul 2017
Location: Tomah,WI
Posts: 3
Thanks: 0
Thanked 3 Times in 1 Post
WI FB rx7 wiper arm conversion

TLDR: Wiper arms from a 1997 Saturn Sl2 or any S series can be used to convert our wiper blades from the pin style to the much better hook style.

I just wanted to post this in hopes it helps someone else who wants to update their wiper arms, or is missing their wiper arms and doesn't want to dish out $50 on ebay. My car was missing its wiper arms entirely and I'm a cheap bastard so I went looking through the scrap heap to see what I could make work. Alas, the wiper arms from a 1997 Saturn SL2 bolted straight on and work excellent. I know only one is pictured however I can assure you both are currently in use. In case you're in a scrap yard pulling this as you read, I'll let you know that I used the rear wiper blade from 2 2003 subaru foresters on my wipers and they work perfectly. You might get away with something longer but this is just what worked for me. Good luck!
zeke lowther is offline
The Following 3 Users Say Thank You to zeke lowther For This Useful Post:
DreamInRotary (02-17-19), RGHTBrainDesign (12-05-18), t_g_farrell (12-06-18)
Old 12-05-18, 11:24 PM
  #2
X27
Junior Member

Join Date: Dec 2017
Location: WI
Posts: 10
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by zeke lowther View Post
TLDR: Wiper arms from a 1997 Saturn Sl2 or any S series can be used to convert our wiper blades from the pin style to the much better hook style.

I just wanted to post this in hopes it helps someone else who wants to update their wiper arms, or is missing their wiper arms and doesn't want to dish out $50 on ebay. My car was missing its wiper arms entirely and I'm a cheap bastard so I went looking through the scrap heap to see what I could make work. Alas, the wiper arms from a 1997 Saturn SL2 bolted straight on and work excellent. I know only one is pictured however I can assure you both are currently in use. In case you're in a scrap yard pulling this as you read, I'll let you know that I used the rear wiper blade from 2 2003 subaru foresters on my wipers and they work perfectly. You might get away with something longer but this is just what worked for me. Good luck!
I'm going to give it a try, thanks.
X27 is offline
Old 12-06-18, 06:59 AM
  #3
Waffles - hmmm good
iTrader: (1)

t_g_farrell's Avatar

Join Date: Jul 2004
Location: Huntersville, N.C.
Posts: 7,763
Thanked 76 Times in 74 Posts
Nice to know. Good work!
t_g_farrell is offline
Old 12-06-18, 08:44 AM
  #4
Censored
iTrader: (14)

Join Date: Jul 2002
Location: usa
Posts: 10,516
Thanked 18 Times in 16 Posts
Hmmmm..... GM parts on an FB?


Seriously, good tip! Those original wipers arms are getting hard to find. Especially the plastic caps.
ray green is offline
Old 12-06-18, 10:45 AM
  #5
Senior Member
iTrader: (13)

hoang5659's Avatar

Join Date: May 2009
Location: H-town
Posts: 707
Thanked 0 Times in 0 Posts
this is exactly what i have been looking for. i hate the pin style wiper arms. now i need to find some of these wiper arms. cheers!
hoang5659 is offline
Old 12-06-18, 11:47 AM
  #6
Waffles - hmmm good
iTrader: (1)

t_g_farrell's Avatar

Join Date: Jul 2004
Location: Huntersville, N.C.
Posts: 7,763
Thanked 76 Times in 74 Posts
In or on whats the difference? Parts are parts.
t_g_farrell is offline
Old 12-06-18, 06:07 PM
  #7
Armchair engineer
iTrader: (2)

j9fd3s's Avatar

Join Date: Mar 2001
Location: http://www.k2rd.com
Posts: 24,296
Thanks: 0
Thanked 101 Times in 92 Posts
if it helps i just measured an original wiper blade and it is 450mm, or 18". once you ditch the pin style wiper, there is a whole universe of blades to choose from
j9fd3s is offline
Old 12-06-18, 06:28 PM
  #8
Senior Member

aeenox's Avatar

Join Date: Jul 2013
Location: Los Angeles
Posts: 262
Thanked 6 Times in 6 Posts
I would like to have the wiper blade setup with just one blade in the center for the whole windshield.

Something like this one:
aeenox is offline
Old 12-06-18, 07:28 PM
  #9
malignant narcissist
iTrader: (2)

diabolical1's Avatar

Join Date: Feb 2002
Location: FL
Posts: 9,374
Thanked 46 Times in 43 Posts
Thanks. That was a great find with the Saturn arms.


Originally Posted by aeenox View Post
I would like to have the wiper blade setup with just one blade in the center for the whole windshield.
Only cars that readily come to mind are the original VW Scirocco (good luck finding one) and few of the 1980s-90s Mercedes-Benz.
diabolical1 is offline
Old 12-07-18, 12:53 AM
  #10
Senior Member

Jon_Valjean's Avatar

Join Date: Apr 2002
Location: Napier
Posts: 414
Thanked 0 Times in 0 Posts
Originally Posted by diabolical1 View Post
Thanks. That was a great find with the Saturn arms.



Only cars that readily come to mind are the original VW Scirocco (good luck finding one) and few of the 1980s-90s Mercedes-Benz.
Second generation Honda Preludes had single wipers and can still be found.
Jon_Valjean is offline
Old 12-07-18, 05:35 PM
  #11
Censored
iTrader: (14)

Join Date: Jul 2002
Location: usa
Posts: 10,516
Thanked 18 Times in 16 Posts
My 85 Suburu XT had the single wiper blade, pretty cool in its day:


But I wouldn't want to retrofit that single wiper motor to an FB, the Rotary Gods would never forgive me.
ray green is offline
Old 12-12-18, 12:44 AM
  #12
84SE-EGI helpy-helperton

LongDuck's Avatar

Join Date: Oct 2002
Location: Phoenix, AZ
Posts: 2,575
Thanked 20 Times in 18 Posts
I'm still using a set of Triple-Edge wiper blades (*circa 1998) which I pulled off of my Black 80LS and put on my 84SE. After all this time, they're still going strong; silicone blade with extra edges on the sides, and they've never worn out, never shown any signs of failure, and still work as well today as when these things were popular on the "As-Seen-On-TV" commercials.

I tried to buy another set for my other vehicles, and the company went out of business. They made them so well that they had no repeat customers...
LongDuck is offline
Old 01-09-19, 07:57 AM
  #13
Waffles - hmmm good
iTrader: (1)

t_g_farrell's Avatar

Join Date: Jul 2004
Location: Huntersville, N.C.
Posts: 7,763
Thanked 76 Times in 74 Posts
Back to the OP post. What about the plastic cover that hides the bolt on the stock arms? Can that be moved over on these arms so it looks unmolested?
t_g_farrell is offline
Old 01-09-19, 03:53 PM
  #14
Full Member

Maxwedge's Avatar

Join Date: Jun 2018
Location: Pennsylvania
Posts: 155
Thanked 8 Times in 6 Posts
Zeke, did the splines match exactly, or did you have to force them at all? Also, when in use do the blades stay on the glass and work well, or do they go over the windshield frame anywhere? Any chance of getting a pic with them swept up, to see how much of the windshield gets swept? I love the idea, but worry about wonky fitment or operation.
Thanks!

Last edited by Maxwedge; 01-09-19 at 06:04 PM.
Maxwedge is offline
Old 01-10-19, 01:40 PM
  #15
Full Member
iTrader: (1)

derSchwamm's Avatar

Join Date: Dec 2014
Location: East TN
Posts: 207
Thanked 8 Times in 2 Posts
Originally Posted by Maxwedge View Post
Zeke, did the splines match exactly, or did you have to force them at all? Also, when in use do the blades stay on the glass and work well, or do they go over the windshield frame anywhere? Any chance of getting a pic with them swept up, to see how much of the windshield gets swept? I love the idea, but worry about wonky fitment or operation.
Thanks!
Subbing. I'd like to know this as well
derSchwamm is offline
Old 01-10-19, 04:38 PM
  #16
Full Member

84rtaryrcket's Avatar

Join Date: Dec 2007
Location: Upton,Ma
Posts: 173
Thanks: 0
Thanked 3 Times in 3 Posts
also subbing. curious about wonky operation.and black caps
84rtaryrcket is offline
Old 01-19-19, 11:54 AM
  #17
1st-Class Engine Janitor
iTrader: (15)

DivinDriver's Avatar

Join Date: Jun 2008
Location: Chino Hills, CA
Posts: 8,359
Thanked 10 Times in 9 Posts
The black caps are hard enough to find... but even worse are the rubber boots that cover the shaft under the wiper arm. They age quickly (-10 years) even when the car is garaged, shrink, and get brittle.
DivinDriver is offline
Old 02-17-19, 07:51 PM
  #18
Junior Member

Join Date: Feb 2019
Location: Tucson
Posts: 13
Thanked 0 Times in 0 Posts
I'll have to find a set of these, the passenger one is missing the pin. Unless someone sells just the pins, this may be the better and more resourceful alternative. Anyone have any leads on the wiper mechanism bushings too?
spedy7 is offline
Old 02-17-19, 10:30 PM
  #19
Always Wanting to Learn
iTrader: (46)

DreamInRotary's Avatar

Join Date: Aug 2011
Location: Cambridge, Minnesota
Posts: 2,990
Thanked 26 Times in 24 Posts
I'd be super interested in this swap as well, so long as the black caps would actually work and cover the nut!
DreamInRotary is offline
