Originally Posted by Montego

I have a feeling that when you said "twins" TwinCharged thought you had stock turbos (I know I did). Because even though technically the BRN's are twins, just about everyone calls them BNR's to make the distinction between the stock hitachi turbos aka "twins". So you aren't wrong but its hard to change people's terminology once it has set in. But in any case, BNR's can handle a lot more than the stockers and so your build makes total sense.

Now are you running the BRN's sequentially or no-seq?

Yeah, I should have specified. Thanks. They are still in sequential. In the passenger corner of the engine bay you can see a custom built setup which is the pressure and vacuum tanks. I built them out of aluminum with the internal area the same as stock. I also made my own valve setup made up of Mac valves. I’ll attach a pic.
