Originally Posted by Ball joint

94 touring
Ebay intake, DP, MP, CB, underdrive pulley, power FC, walbro 255, 4x850cc injectors, non sequential turbos, Greddy intercooler piping+elbow, Ebay SMIC, stage 2 streetport motor from rx7 store, profec B running 14PSI, DEFI boost and EGT gauges, everything bypassed with block off plates.

what power are you making with those mods mate?

Brad.

ps feel free to pm me the answer.
