starters
#1
starters
I have a kind of dead spot in my starter, well sometimes it kind of skips or I dont really know how to describe it.
I have the wiring all sorted unless there is something else im missing with that- good heavy gauge wire right from battery
But I get this sort of dead spot where it stops cranking for a second or sounds like it almost binds for a second ( hard to explain?)
I remember about guys swapping in rx8 starters or is there something else people have been using?
Need this to be plug and play I dont want to make a project out of it for the 3-4 times a year I drive the car but its sometimes embarrassing when leaving a parkinglot full of nice cars
I have the wiring all sorted unless there is something else im missing with that- good heavy gauge wire right from battery
But I get this sort of dead spot where it stops cranking for a second or sounds like it almost binds for a second ( hard to explain?)
I remember about guys swapping in rx8 starters or is there something else people have been using?
Need this to be plug and play I dont want to make a project out of it for the 3-4 times a year I drive the car but its sometimes embarrassing when leaving a parkinglot full of nice cars
#2
well I did find this, I guess this is the bees knees
the N327 ( NA auto ) 2kw starter fits straight into the position where the N318 ( turbo manual ) 1.4 kw starter falls out
no mods required
for the FD and rx8, you can swap the N327 guts straight into the appropriate nose very easily in just minutes
as for the 20B starter, you need to have the correct engine rear plate that will take the forwards facing starter ( FD auto or 20B )
if you have the NA 5spd// you are out of luck.. these take the earlier direct drive starters, that run on the smaller ring gear ..and are not the geared type discussed above
no mods required
for the FD and rx8, you can swap the N327 guts straight into the appropriate nose very easily in just minutes
as for the 20B starter, you need to have the correct engine rear plate that will take the forwards facing starter ( FD auto or 20B )
if you have the NA 5spd// you are out of luck.. these take the earlier direct drive starters, that run on the smaller ring gear ..and are not the geared type discussed above
#3
Retired Moderator, RIP
iTrader: (142)
Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,581
Likes: 0
Received 131 Likes
on
114 Posts
numerous times I have had a bad start.
I got "what is it now..dammit!"..is it the starter?..clutch interock?...
nope..damn positive cable at the battery.
I'm surprised when the cable is tight but still not enough to give good contact.
I got "what is it now..dammit!"..is it the starter?..clutch interock?...
nope..damn positive cable at the battery.
I'm surprised when the cable is tight but still not enough to give good contact.
Trending Topics
#9
1308ccs of awesome
iTrader: (9)
https://www.amazon.com/World-Power-S.../dp/B004ABKUE6
some are rebuilt with 1.2kw motors I think, I would get the AC Delco that specifies 2.0 kw
#10
Rotary $ > AMG $
iTrader: (7)
Hey Rob-
The automatic N/A starter is a direct bolt up to your TII.
I bought a bosch 2.0KW starter for Rx7 Automatic transmission. I don't remember if it's reman or new. The starter motor is longer, just like eage8 picture shows. I questioned the validity of the automatic n/a starter as an upgrade on my TII. My experience has proven to me that the automatic starter does in fact spin the motor faster under full voltage. Even more importantly, the automatic starter spins the motor much faster under low voltage conditions.
Good Luck
Jack
The automatic N/A starter is a direct bolt up to your TII.
I bought a bosch 2.0KW starter for Rx7 Automatic transmission. I don't remember if it's reman or new. The starter motor is longer, just like eage8 picture shows. I questioned the validity of the automatic n/a starter as an upgrade on my TII. My experience has proven to me that the automatic starter does in fact spin the motor faster under full voltage. Even more importantly, the automatic starter spins the motor much faster under low voltage conditions.
Good Luck
Jack
#13
Rotary $ > AMG $
iTrader: (7)
The effect is really quite dramatic.
We didn't make this up, we learned it from Mazda on the RX8.
#16
I wish I was driving!
Real world experience, as well as the laws of physics, prove otherwise.
#19
Rotary $ > AMG $
iTrader: (7)
If the no load speed on the electric motor is 3000rpm, then the loaded speed *cannot* be 3000 rpm. Available torque vs actual load will determine maximum speed. Increase the available torque on the same load, the max loaded speed will increase.
The 2.0KW motor automatic starter has more torque. On a given load it will in fact spin that load at a faster speed. It will ALSO attain it's maximum rotational speed more quickly.
These two characteristics, 1) higher maximum cranking speed, and 2) shorter time to attain maximum cranking speed, are both desirable for our cars.
I probably wouldn't recommend you throw away a perfectly functioning 1.4kw starter just to buy a 2.0kw starter, but if you are buying a new starter out of necessity, go for the upgrade.
Edit: A couple of years ago, hiroichi1515 helped me rebuild the engine from my TII.(Thanks Derrick) I installed a fuel-cut switch to help manage starting during break in. It was still a royal pain in the *** to start that engine until it was fully broken in, especially for the first couple of weeks. I was additionally struggling with voltage drains and grounding issues. An upgraded starter spinning that tight new motor would have been extremely helpful during the break-in period.
If I ever rebuild a rotary again, Tii or N/A, I will upgrade the starter as part of the rebuild process.
Last edited by jackhild59; 10-20-16 at 11:32 AM.
#20
i just like buying stuff and hate when my starter does that thing, its not all the time but enough to annoy the crap out of me
I can probably sell my starter to someone else or Ill just keep it in my spare parts pile ( btw it was a new not reman starter but I dont remember where I got it from)
I can probably sell my starter to someone else or Ill just keep it in my spare parts pile ( btw it was a new not reman starter but I dont remember where I got it from)
#21
Eats, Sleeps, Dreams Rotary
iTrader: (1)
I see that the examples are heavily stacked against me, but as the rotary is so resistance free when starting,
guess I just assumed the larger capacity starter couldn't turn the engine any faster. Were not talking about a
14:1 cr big block, the little rotary is so resistant free, we all know it can be turned by hand by just pulling on
the fan belt. To get my arms around this, guess I'll need to check when I get back home in late November and
check the starting RPM's.
Thanks for the lesson.
guess I just assumed the larger capacity starter couldn't turn the engine any faster. Were not talking about a
14:1 cr big block, the little rotary is so resistant free, we all know it can be turned by hand by just pulling on
the fan belt. To get my arms around this, guess I'll need to check when I get back home in late November and
check the starting RPM's.
Thanks for the lesson.
#22
We had a hard time sourcing the 2kw auto starters, bought a few that showed up as 1.2kw TII starters, so we decided to build our own. 2kw starters DRASTICALLY increase cranking rpm, the typical TII cranking rpm is 175, as verified by our Mazda compression tester. With our 2kw starter cranking speed is increased to around 275rpm.
High Torque 2KW Starter (87-91 Turbo II RX-7)
High Torque 2KW Starter (87-91 Turbo II RX-7)
#23
B O R I C U A
iTrader: (14)
This is an explanation so you can understand the relationship of torque to speed on dc motors.
If the no load speed on the electric motor is 3000rpm, then the loaded speed *cannot* be 3000 rpm. Available torque vs actual load will determine maximum speed. Increase the available torque on the same load, the max loaded speed will increase.
The 2.0KW motor automatic starter has more torque. On a given load it will in fact spin that load at a faster speed. It will ALSO attain it's maximum rotational speed more quickly.
These two characteristics, 1) higher maximum cranking speed, and 2) shorter time to attain maximum cranking speed, are both desirable for our cars.
I probably wouldn't recommend you throw away a perfectly functioning 1.4kw starter just to buy a 2.0kw starter, but if you are buying a new starter out of necessity, go for the upgrade.
Edit: A couple of years ago, hiroichi1515 helped me rebuild the engine from my TII.(Thanks Derrick) I installed a fuel-cut switch to help manage starting during break in. It was still a royal pain in the *** to start that engine until it was fully broken in, especially for the first couple of weeks. I was additionally struggling with voltage drains and grounding issues. An upgraded starter spinning that tight new motor would have been extremely helpful during the break-in period.
If I ever rebuild a rotary again, Tii or N/A, I will upgrade the starter as part of the rebuild process.
If the no load speed on the electric motor is 3000rpm, then the loaded speed *cannot* be 3000 rpm. Available torque vs actual load will determine maximum speed. Increase the available torque on the same load, the max loaded speed will increase.
The 2.0KW motor automatic starter has more torque. On a given load it will in fact spin that load at a faster speed. It will ALSO attain it's maximum rotational speed more quickly.
These two characteristics, 1) higher maximum cranking speed, and 2) shorter time to attain maximum cranking speed, are both desirable for our cars.
I probably wouldn't recommend you throw away a perfectly functioning 1.4kw starter just to buy a 2.0kw starter, but if you are buying a new starter out of necessity, go for the upgrade.
Edit: A couple of years ago, hiroichi1515 helped me rebuild the engine from my TII.(Thanks Derrick) I installed a fuel-cut switch to help manage starting during break in. It was still a royal pain in the *** to start that engine until it was fully broken in, especially for the first couple of weeks. I was additionally struggling with voltage drains and grounding issues. An upgraded starter spinning that tight new motor would have been extremely helpful during the break-in period.
If I ever rebuild a rotary again, Tii or N/A, I will upgrade the starter as part of the rebuild process.
We had a hard time sourcing the 2kw auto starters, bought a few that showed up as 1.2kw TII starters, so we decided to build our own. 2kw starters DRASTICALLY increase cranking rpm, the typical TII cranking rpm is 175, as verified by our Mazda compression tester. With our 2kw starter cranking speed is increased to around 275rpm.
High Torque 2KW Starter (87-91 Turbo II RX-7)
High Torque 2KW Starter (87-91 Turbo II RX-7)
