removing theexhaust inserts
06-15-07, 01:43 AM
#2
Law Breaker
Join Date: Oct 2005
Location: S.F. Bay Area, California 510
Posts: 3,333
Likes: 0
Received 0 Likes
on
0 Posts
https://www.rx7club.com/general-rotary-tech-support-11/need-help-removing-exhaust-port-sleeves-661416/
read my post there. they are easy to get out, just takes time.
read my post there. they are easy to get out, just takes time.
06-15-07, 09:32 AM
#4
Seduced by the DARK SIDE
Join Date: Apr 2001
Location: Orange Park FL (near Jax)
Posts: 7,323
Likes: 0
Received 2 Likes
on
2 Posts
Mazda put them there as heat shields.
Without them you may get more exhaust heat into the housing & water jacket.
I don't know if it's enough to be a problem.
My guess is, if your cooling system can handle it - no worries.
My port job was pretty mild, so I left them in.
Without them you may get more exhaust heat into the housing & water jacket.
I don't know if it's enough to be a problem.
My guess is, if your cooling system can handle it - no worries.
My port job was pretty mild, so I left them in.
Last edited by SureShot; 06-15-07 at 09:40 AM.
06-15-07, 11:25 AM
#7
Winter sucks
Join Date: Jan 2004
Location: Newberg, Oregon
Posts: 3,083
Likes: 0
Received 0 Likes
on
0 Posts
I'm taking my NA ones out and putting in TII ones.... It'll save me a bit of grinding...
Edit: the screw/slide hammer method hasn't worked for me yet. Always strips the threads on the screw and never graps the roll pin. Was going to try and weld the screw to the rollpin, but I hate welding that close to the alum. I don't want to damage anything.
Edit: the screw/slide hammer method hasn't worked for me yet. Always strips the threads on the screw and never graps the roll pin. Was going to try and weld the screw to the rollpin, but I hate welding that close to the alum. I don't want to damage anything.
Trending Topics
06-15-07, 03:10 PM
#8
Seduced by the DARK SIDE
Join Date: Apr 2001
Location: Orange Park FL (near Jax)
Posts: 7,323
Likes: 0
Received 2 Likes
on
2 Posts
I don't recall how big the hole in the roll pin is, or what's behind it.
Is it big enough to drill through to the other side, then use that hole as a pilot to drill from the other side to the pin & drive it out?
Just a thought..
-Bill
Is it big enough to drill through to the other side, then use that hole as a pilot to drill from the other side to the pin & drive it out?
Just a thought..
-Bill
06-15-07, 07:05 PM
#11
rotorhead
Thread Starter
Join Date: Sep 2005
Location: spokane
Posts: 90
Likes: 0
Received 0 Likes
on
0 Posts
ok so what i originally did is i ported the exhaust really big with the insert out cuz i wanted to go a little bigger well i am hearing that my motor wont last very long if i leave them out????? now has anyone out there experimented with this????
06-15-07, 07:09 PM
#12
I wish I was driving!
Leaving the sleeves out is for high rpm Periphereal Ports and Massive bridgeports. Removing the sleeves leaves a port outlet size of a hair under 2.5". For turbo cars, you want to keep the outlet to around 2", as exists with the stock sleeves, in order to keep exhaust gas velocity high to aid in spooling the turbocharger.
