Distributor Spark Plug Wire Order
I need help finding out the firing order and the position of the spark plug wires on the distributor cap. MY newly aqquired 81 needs work, and it's been idling very strangely, and dying. The biggest problem is when the pedal is pushed to the floor, the RPMs just creep slowly up. Anyone know anything?
03-07-05, 05:50 PM
#2
sellout
iTrader: (4)
Join Date: Jan 2005
Location: Lawrence KS
Posts: 3,078
Likes: 0
Received 0 Likes
on
0 Posts
okay, start from the plug ( vent?) and go clockwise; rear low plug, front low plug, front coil, front-top plug, rear-top plug, and the middle is the rear coil. hope you can understand that, if not sorry. hopefully somebody can draw you a picture.
03-07-05, 05:52 PM
#3
Mmmm Cheeze....
iTrader: (2)
Join Date: Jul 2004
Location: Oklahoma
Posts: 748
Likes: 0
Received 0 Likes
on
0 Posts
The dizzy cap will say L T L1 L2 T1 T2 On the rotor housings it may or may not say which one goes to which but the rotor housing closest to the radiator is 1 and the rear is 2. The top spark plugs are the t (trailing) and the bottom spark plugs are L (leading). So starting with the top left spark plug the order is T1 T2 L2 L1
The L and T plugs on the dizzy cap go to the coils. I "think" that the one closest to the fron of the car is the trailing and the one closest to the rear is the leading. Can someone confirm that or does it even matter?
The L and T plugs on the dizzy cap go to the coils. I "think" that the one closest to the fron of the car is the trailing and the one closest to the rear is the leading. Can someone confirm that or does it even matter?
03-07-05, 09:46 PM
#6
1981 Mazda RX-7 GSL
In my haynes manual this is what they show....don't know if it will help.
The Haynes manual is confusing.
I do draw!
I will check the order of mine tomorrow to verify & post.
Rotor location and distributor rotation.jpg
The Haynes manual is confusing.
I do draw!
I will check the order of mine tomorrow to verify & post.
Rotor location and distributor rotation.jpg
Last edited by Myc1972; 03-07-05 at 09:55 PM.
03-08-05, 01:33 PM
#7
1981 Mazda RX-7 GSL
Diagram
Here you go!
I got this Distributor Spark Plug Wire Order from my 1981.
I even made a nice diagram for you, it should be your answer.
Hope it helps people out!
Myc1972
I got this Distributor Spark Plug Wire Order from my 1981.
I even made a nice diagram for you, it should be your answer.
Hope it helps people out!
Myc1972
Last edited by Myc1972; 03-08-05 at 01:49 PM.
