Rotary-Works V-mount Install

Old 07-25-11, 05:56 PM
  #51
Rotary Freak
iTrader: (9)

Join Date: Feb 2007
Location: dayton,ohio
Posts: 2,617
Thanks: 0
Thanked 1 Time in 1 Post
Originally Posted by TrboSpdAnt View Post
LOL. Oh have I got a GREAT addition to THIS story....

Got the bracket kit... NOTHING of theirs fits right. Gilmer-Drive pulleys need modification, as well!

The V-mount kist pissed me off so Io bad I sent a SCATHING 3-page email.... To which they replied...!

Nothing.

****-o. Bupkiss. Nada. Zip. Zero. Zilch.

They DID, however, go so far as deleting my account, so I can't log-i, to their site, for ANY reason (just to hit their 'Installation Instructions section, so that I could add it to my fodder-collection, against them).

Whatta buncha chodes.

Will post a link to the Email that I sent to them - both here and in the 'complaints' section.


>>>> Here's the link to the directory, with 3 different formats, of the email. <<<<


The audio recording will also be posted, when I can get the time to set it up and allocate an hour-or-so, to crawling up their asses, like a proctologist.
Did you get the gilmer drive for the 13brew? They don't work since our waterpump spins the opposite way.
turboIIrotary is offline
Old 07-25-11, 06:31 PM
  #52
Boost makes cars smile.
5 Year Member
iTrader: (5)

TrboSpdAnt's Avatar

Join Date: May 2005
Location: ...
Posts: 1,424
Thanks: 0
Thanked 0 Times in 0 Posts
If you look on the RW site, there isn't a delineation to WHICH 13B it's produced for (12A/13B/20B).

If you read that email, I sent, you'll see where I had the issue(s).

How would the direction of travel of the pump, proper, have any affect upon the ability of the pulley? Lol. I guess their site omits more than I thought.
TrboSpdAnt is offline
Old 07-25-11, 10:50 PM
  #53
Bubblicious DEF.
5 Year Member
iTrader: (35)

muibubbles's Avatar

Join Date: May 2008
Location: 732
Posts: 4,252
Thanks: 0
Thanked 0 Times in 0 Posts
wow... this temps me to make my own kit and sell..............
muibubbles is offline
Old 07-26-11, 12:04 AM
  #54
Registered User
iTrader: (6)

Join Date: Sep 2009
Location: Union City, CA
Posts: 1,105
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by muibubbles View Post
wow... this temps me to make my own kit and sell..............
Do It!!!

I'd love to see a pink based vmount kit...lol
Rotary Extreme Sales 1 is offline
Old 07-26-11, 12:12 AM
  #55
Bubblicious DEF.
5 Year Member
iTrader: (35)

muibubbles's Avatar

Join Date: May 2008
Location: 732
Posts: 4,252
Thanks: 0
Thanked 0 Times in 0 Posts
^^ haha only thing is its too hard to accomadate everything. i made my own and love it but then i keep forgetting i got rid of a lot of junk so its a hell of a lot easier to make one for my car.. a/c? whats that! hahahha
muibubbles is offline
Old 07-26-11, 12:49 AM
  #56
Boost makes cars smile.
5 Year Member
iTrader: (5)

TrboSpdAnt's Avatar

Join Date: May 2005
Location: ...
Posts: 1,424
Thanks: 0
Thanked 0 Times in 0 Posts
Ditto, here.

No A/C, No P/S.

I have half of that equation, down... Made my own (only needed the RW kit for the oil cooler mounting bracket.... FAIL), but much like you, wouldn't even try to accommodate periphery such things as ac or ps.

Got pics of the vmount of yours? I'll show everyone mine (no pun intended), once I get it all together.
TrboSpdAnt is offline
Old 07-26-11, 05:43 AM
  #57
Bubblicious DEF.
5 Year Member
iTrader: (35)

muibubbles's Avatar

Join Date: May 2008
Location: 732
Posts: 4,252
Thanks: 0
Thanked 0 Times in 0 Posts
yerp, these are some old ones when i was in the process... ill post better ones up tomorrow when i take the car out and try firing it up (fingers crossed)


my "mounts"
Name:  DSC_1068-1.jpg
Views: 1242
Size:  103.4 KB

Name:  DSC_0905.jpg
Views: 1221
Size:  109.1 KB

the gap is smaller, this is just mock up, and the sides have support to narrow the gap of the rad.
Name:  DSC_0907.jpg
Views: 1227
Size:  95.6 KB

ill eventually make ducting but i dont think i need it since the design has very tiny gaps...


Name:  DSC_0536.jpg
Views: 1221
Size:  102.2 KB
muibubbles is offline
Old 07-26-11, 07:22 AM
  #58
Registered User
iTrader: (6)

Join Date: Sep 2009
Location: Union City, CA
Posts: 1,105
Thanks: 0
Thanked 0 Times in 0 Posts
hahaha, omg, pink parts, it looks cool man, really.

you can see my fc vmounts in my sig, it took forever but i was able to keep everything, a/c, ps, and i even made hood dampers and a mini battery kit.

but your pics are of an FD, do you have pics of your Fc stuff?
Rotary Extreme Sales 1 is offline
Old 07-26-11, 12:00 PM
  #59
Bubblicious DEF.
5 Year Member
iTrader: (35)

muibubbles's Avatar

Join Date: May 2008
Location: 732
Posts: 4,252
Thanks: 0
Thanked 0 Times in 0 Posts
haha yesss the pink... i couldnt image how hard it was to fab those up... retaining all that junk in the engine bay and fabbing around it cant be to easy! i like the second one but they both look good

Lol yeah they are in the FD... this is the ermm 3rd gen section? i dont own an fc haha although id love to mod one of those.......
muibubbles is offline
Old 07-27-11, 01:00 AM
  #60
Senior Member
iTrader: (19)

tek_88's Avatar

Join Date: Jan 2007
Location: oroville
Posts: 406
Thanks: 0
Thanked 0 Times in 0 Posts
I bought their vmount radiator and it went on fine, no slotting the brackets. Just bolted on, went to find some rad hose and was good to go. My water temps are always 74-80 C and air temps are 30-40 C.
tek_88 is offline
Old 07-27-11, 03:01 AM
  #61
Registered User
iTrader: (6)

Join Date: Sep 2009
Location: Union City, CA
Posts: 1,105
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by muibubbles View Post
haha yesss the pink... i couldnt image how hard it was to fab those up... retaining all that junk in the engine bay and fabbing around it cant be to easy! i like the second one but they both look good

Lol yeah they are in the FD... this is the ermm 3rd gen section? i dont own an fc haha although id love to mod one of those.......

Thanks, it was very time consuming to do it right, this thread is for the RW Fc vmount.

But for the money the RW FC vmount kit is a great buy.

I might offer a limited edition pink kit in your honor..lol

Ben
Rotary Extreme Sales 1 is offline
Old 02-23-13, 05:25 AM
  #62
Full Member

Join Date: Jan 2011
Location: Sweden
Posts: 94
Thanks: 0
Thanked 0 Times in 0 Posts
Lifting an old thread

bought the RW v-mount radiator för about 1,5 year ago, already had a IC I was going to use...

now finnaly Im soon to get my car running... BUT the drain plug leaks!! and since I live in sweden and only have M-threading on the rest of the car and wanna replace that shitty plastic plug with a bolt and washer, my question then is what Threading is the plug?? so I can order a correct one

not very many hardware stores have a large UNC storage, and to me it looks to be fine threading UNC as well

anybody that can help? RW hasn't answered my email I sent 2-3 weeks ago...
Wolf_ is offline
Old 02-23-13, 12:33 PM
  #63
Registered User
iTrader: (6)

Join Date: Sep 2009
Location: Union City, CA
Posts: 1,105
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by Wolf_ View Post
Lifting an old thread

bought the RW v-mount radiator för about 1,5 year ago, already had a IC I was going to use...

now finnaly Im soon to get my car running... BUT the drain plug leaks!! and since I live in sweden and only have M-threading on the rest of the car and wanna replace that shitty plastic plug with a bolt and washer, my question then is what Threading is the plug?? so I can order a correct one

not very many hardware stores have a large UNC storage, and to me it looks to be fine threading UNC as well

anybody that can help? RW hasn't answered my email I sent 2-3 weeks ago...

alternate method if you cant find the correct bolt, take it to any shop that can weld aluminum and make your own drain plug.

1. get a threaded aluminum bung with matching bolt with rubber or teflon washer, you can get this in your countries metric system.
2. have the shop install it in the right location and weld the other one shut.
Rotary Extreme Sales 1 is offline
Old 02-23-13, 12:50 PM
  #64
Oilfield Trash
10 Year Member
iTrader: (13)

mymmeryloss's Avatar

Join Date: May 2005
Location: Colorado
Posts: 705
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by Rotary Extreme Sales 1 View Post

alternate method if you cant find the correct bolt, take it to any shop that can weld aluminum and make your own drain plug.

1. get a threaded aluminum bung with matching bolt with rubber or teflon washer, you can get this in your countries metric system.
2. have the shop install it in the right location and weld the other one shut.
Thats what i would do...
mymmeryloss is offline
Old 02-23-13, 07:43 PM
  #65
Full Member

Join Date: Jan 2011
Location: Sweden
Posts: 94
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by Rotary Extreme Sales 1 View Post
alternate method if you cant find the correct bolt, take it to any shop that can weld aluminum and make your own drain plug.

1. get a threaded aluminum bung with matching bolt with rubber or teflon washer, you can get this in your countries metric system.
2. have the shop install it in the right location and weld the other one shut.

went all day to figure out it is 9/16" UNF threading... now on the hunt for a bolt, to bad all hardware stores with any kind of UNF/UNC bolts in the area are closed weekends


had the rewelding option in my head all day, but that is more work and money then a bolt and washer/rubber seal
Wolf_ is offline
Old 02-25-13, 12:28 AM
  #66
Registered User
iTrader: (6)

Join Date: Sep 2009
Location: Union City, CA
Posts: 1,105
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by Wolf_ View Post
went all day to figure out it is 9/16" UNF threading... now on the hunt for a bolt, to bad all hardware stores with any kind of UNF/UNC bolts in the area are closed weekends


had the rewelding option in my head all day, but that is more work and money then a bolt and washer/rubber seal
ok ok true that...lol
Rotary Extreme Sales 1 is offline
Old 02-27-13, 04:54 PM
  #67
Full Member

Join Date: Jan 2011
Location: Sweden
Posts: 94
Thanks: 0
Thanked 0 Times in 0 Posts
well finnaly the headache is over.. it wasn't 9/16 unf, it was 1/2" uhf... so now I can move on and refill the entire coolingsystem again
Wolf_ is offline
Old 07-07-17, 11:59 AM
  #68
My girl
iTrader: (3)

Houstonderk's Avatar

Join Date: Apr 2004
Location: Andrews AFB, MD
Posts: 2,173
Thanks: 0
Thanked 1 Time in 1 Post
So how has the performance and longevity been for this kit? Still seems to be a lower priced kit and the slight alterations to the brackets don't seem to bad.
Houstonderk is offline
Old 10-10-17, 01:25 PM
  #69
Full Member
iTrader: (1)

Join Date: Jan 2006
Location: Alexandria, VA
Posts: 74
Thanked 1 Time in 1 Post
I know this is an old thread but i didn't find this bolt info easily so i figured id post it here for others looking.

If you are running the Rotary-Works/ cxracing / ebay / chinese made radiator with the plastic drain plug, please do yourself a favor and replace it, preferably before installing everything. It's not a standard bolt thread pattern. It is a 1/4in pipe plug that you can find down the plumbing isle at home depot or ace.

I got mine at Ace, so here is the item number (4504999). Ace also carries a hex head plug if you dont want the square head.
Home depot also has it, dont know the part number but i believe the size is labeled as 1/4 MIP.
almcbs is offline
The Following User Says Thank You to almcbs For This Useful Post:
Spalato (11-16-17)
Old 10-22-17, 04:36 PM
  #70
Full Member
iTrader: (1)

Henry Erazo's Avatar

Join Date: Feb 2016
Location: Irving Tx
Posts: 83
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by keister View Post
Here's some pictures of how I have it all mounted. As well as a small review of problems/issues/ things you need to know for this kit.

Kinda dark out when I took the pic's so if needed I can take more tomorrow.

1. On the back of the rad, the stock fans did not lign up at all. Fan shroud had to
be coerced to even go in the tabs at the bottom. Also only two of the holes ligned
up at the top bolt mounts. the 3rd isn't even remotely in the right spot.

2. I have the touring model with only the driver side oil cooler, the return line for the
rad pointed straight down into the hardlines for the oil cooler with about 1mm to
spare. It had to be removed and a 90* elbow welded in. Odd that this wasn't
considered as the other side of the rad already had a 90* elbow for the inlet.

Also, AC does hold charge. Even with the "snakey" look of the hard lines.

Had to find a rubber rad hose for the inlet. Return has a 4'' section of alu in
between two rubber couplers. No rad hoses provided.

On the plus side..my car runs cold. 85-93*C W, 22-28*C Air
•So brackets need to modified as far as what I have read on this thread by others for radiator and the IC
•readjust "snakes" the AC lines.
Is the inlet for rad necessarily needs to be readjusted for the rad hose to connect?

what else do I need to keep in mind once I decide to go with this kit?
-sorry for bumping up an old thread
Henry Erazo is offline
Old 10-22-17, 11:08 PM
  #71
Full Member
iTrader: (1)

Join Date: Jan 2006
Location: Alexandria, VA
Posts: 74
Thanked 1 Time in 1 Post
Originally Posted by Henry Erazo View Post
•So brackets need to modified as far as what I have read on this thread by others for radiator and the IC
•readjust "snakes" the AC lines.
Is the inlet for rad necessarily needs to be readjusted for the rad hose to connect?

what else do I need to keep in mind once I decide to go with this kit?
-sorry for bumping up an old thread

I just did this install like last month. Here are some quick notes.
  • IC and Rad brackets do need to be modified. Usually just some trimming and maybe extending the hole some more if necessary.
  • The L brackets are fine, as i didnt need to alter those.
  • You will more than likely have to buy bolts to mount the rad mount to the frame rail on the passenger side. I dont remember the size on the bolt but is it bigger than the other side and any other bolts.
  • You will need to replace the rad drain plug. This is a must as the plastic pos will constantly leak. I put the size of that bolt in the post above.1
  • There is a good chance you will need to buy the appropriate bolts to fit in the rad and IC.
  • Stock fans will not fit on the rad without some cutting and trimming. Near the inlet and outlet for the rad on the fan needs to be trimmed, and the feet on the bottom to fit into the slots on the radiator. Also, only one screw hole lined up with my rad after i opened that hole up some more.
  • As for radiator hoses, you will need to grab some flex hose from the auto store. I wish i kept the part numbers for the hoses that I got but i completely forgot to write it down. For the inlet side (side with the oil cooler) if you get a flex hose that goes straight then to a 90 degree bend, it will fit with barely touching the oil cooler line. You will have to make sure you trim down the fan shroud enough though. For the other side, you can grab a straight flex hose and that should do the trick no problem.
  • As for the condenser, just carefully bend the line so that they work with however you are trying to set things up. I will say to do this slowly and try to think it out so you are just bending stuff over and over. I think i leaked out freon at the connection point to the condenser because when i was moving the lines it started to unscrew itself, so just make sure you check that if you dont plan on having the system drained ahead of time.
  • Mounting the condenser is a project by itself. You will have to come up with your own thing for this, i just used some zipties and varies pieces of metal to make sure that it stays away from hitting the rad.
  • One of the lower hard lines on the condenser will interfere with the lower rad mount, I just cut some of that mount out as having all that excess metal is pointless imo.
  • Dont forget you will have to extend the fan wires.
  • IC doesnt involve much adjusting to get to fit properly.
  • I put some foam between the IC and the drier (believe that's what the part is called) as the IC will press up against it.
  • You will prob also need some IC piping, unless the supplied pipes work for your set up.

I think i pretty much hit all the main things. It seems like a lot but honestly if you are fine with doing some fab work then it's not to much. Def worth it imo for the price.
almcbs is offline
Old 01-18-18, 09:51 PM
  #72
Full Member
iTrader: (1)

Henry Erazo's Avatar

Join Date: Feb 2016
Location: Irving Tx
Posts: 83
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by almcbs View Post
I just did this install like last month. Here are some quick notes.
  • IC and Rad brackets do need to be modified. Usually just some trimming and maybe extending the hole some more if necessary.
  • The L brackets are fine, as i didnt need to alter those.
  • You will more than likely have to buy bolts to mount the rad mount to the frame rail on the passenger side. I dont remember the size on the bolt but is it bigger than the other side and any other bolts.
  • You will need to replace the rad drain plug. This is a must as the plastic pos will constantly leak. I put the size of that bolt in the post above.1
  • There is a good chance you will need to buy the appropriate bolts to fit in the rad and IC.
  • Stock fans will not fit on the rad without some cutting and trimming. Near the inlet and outlet for the rad on the fan needs to be trimmed, and the feet on the bottom to fit into the slots on the radiator. Also, only one screw hole lined up with my rad after i opened that hole up some more.
  • As for radiator hoses, you will need to grab some flex hose from the auto store. I wish i kept the part numbers for the hoses that I got but i completely forgot to write it down. For the inlet side (side with the oil cooler) if you get a flex hose that goes straight then to a 90 degree bend, it will fit with barely touching the oil cooler line. You will have to make sure you trim down the fan shroud enough though. For the other side, you can grab a straight flex hose and that should do the trick no problem.
  • As for the condenser, just carefully bend the line so that they work with however you are trying to set things up. I will say to do this slowly and try to think it out so you are just bending stuff over and over. I think i leaked out freon at the connection point to the condenser because when i was moving the lines it started to unscrew itself, so just make sure you check that if you dont plan on having the system drained ahead of time.
  • Mounting the condenser is a project by itself. You will have to come up with your own thing for this, i just used some zipties and varies pieces of metal to make sure that it stays away from hitting the rad.
  • One of the lower hard lines on the condenser will interfere with the lower rad mount, I just cut some of that mount out as having all that excess metal is pointless imo.
  • Dont forget you will have to extend the fan wires.
  • IC doesnt involve much adjusting to get to fit properly.
  • I put some foam between the IC and the drier (believe that's what the part is called) as the IC will press up against it.
  • You will prob also need some IC piping, unless the supplied pipes work for your set up.
I think i pretty much hit all the main things. It seems like a lot but honestly if you are fine with doing some fab work then it's not to much. Def worth it imo for the price.
Did you evaporated the refrigerant out first and then readjusted the AC lines after or had it mounted the way they are and did it the way they are without evaporating?
Henry Erazo is offline
Old 01-23-18, 04:59 AM
  #73
Full Member
iTrader: (1)

Henry Erazo's Avatar

Join Date: Feb 2016
Location: Irving Tx
Posts: 83
Thanks: 0
Thanked 0 Times in 0 Posts
Originally Posted by keister View Post
Here's some pictures of how I have it all mounted. As well as a small review of problems/issues/ things you need to know for this kit.

Kinda dark out when I took the pic's so if needed I can take more tomorrow.

1. On the back of the rad, the stock fans did not lign up at all. Fan shroud had to
be coerced to even go in the tabs at the bottom. Also only two of the holes ligned
up at the top bolt mounts. the 3rd isn't even remotely in the right spot.

2. I have the touring model with only the driver side oil cooler, the return line for the
rad pointed straight down into the hardlines for the oil cooler with about 1mm to
spare. It had to be removed and a 90* elbow welded in. Odd that this wasn't
considered as the other side of the rad already had a 90* elbow for the inlet.

Also, AC does hold charge. Even with the "snakey" look of the hard lines.

Had to find a rubber rad hose for the inlet. Return has a 4'' section of alu in
between two rubber couplers. No rad hoses provided.

On the plus side..my car runs cold. 85-93*C W, 22-28*C Air
Not too sure if I’m seeing if the condenser is mounted in with tabs or just that the AC lines are holding in up. Do you happen to have any more pictures just to clarify the confusion. Sorry to bother but this would help me a ton.
Henry Erazo is offline
Old 01-23-18, 08:48 AM
  #74
Full Member
iTrader: (1)

Join Date: Jan 2006
Location: Alexandria, VA
Posts: 74
Thanked 1 Time in 1 Post
Originally Posted by Henry Erazo View Post
Did you evaporated the refrigerant out first and then readjusted the AC lines after or had it mounted the way they are and did it the way they are without evaporating?
I didn't evaporate the system but with that being said I do think one of my connectors to the confessor came loose and leaked everything out anyways. That or I made a hole somewhere (doubt it). It's not to hard to bend, you just have to make sure you dont kink any of that line and that's the part that gets annoying. I used a combination of a few metal pieces and some zip ties to hold the condenser up off the rad. I would take some pics for you but everything sits under the intercoler and I'm in the middle of a move so dont have the tools available to take it off.
almcbs is offline
Related Topics
Thread
Thread Starter
Forum
Replies
Last Post
24seven_dada
3rd Generation Specific (1993-2002)
20
11-10-18 01:03 PM
Jeff20B
1st Generation Specific (1979-1985)
73
09-16-18 08:16 PM
SakeBomb Garage
Vendor Classifieds
6
08-09-18 06:54 PM
sinclair7seven
General Rotary Tech Support
11
09-11-15 11:15 AM
Enzo1944
New Member RX-7 Technical
2
09-06-15 09:57 AM


Thread Tools
Search this Thread
Quick Reply: Rotary-Works V-mount Install


Contact Us Archive Advertising Cookie Policy Privacy Statement Terms of Service

© 2019 MH Sub I, LLC dba Internet Brands

We are a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for us to earn fees by linking to Amazon.com and affiliated sites.
