need gurus help cant figure this out
#1
need gurus help cant figure this out
car still idling high, started it up, let it idle for about 10 to 15 mins and it started to idle pretty smoothly (but at 2k rpm), then it just starts to hiccup between 2.1k and 1.8k rpm .. i let it run for another 5 mins thinking it would learn to idle .. got out the car noticed puddle of water on the floor, overflow tank is spitting out water and lots of smoke from turbo area
what are symptoms of bad turbos? could bad turbos cause high idling? is this indicative of something more serious?
i took a video of it if this helps
http://www.youtube.com/watch?v=VzN79tD9oqI
what are symptoms of bad turbos? could bad turbos cause high idling? is this indicative of something more serious?
i took a video of it if this helps
http://www.youtube.com/watch?v=VzN79tD9oqI
#4
Original Gangster/Rotary!
iTrader: (213)
From what I remember you've starting about 175 threads in the last year while you were attempting to install your new engine.
Who built the engine?
I think you posted the wrong video btw. that seems to be a still shot of your engine bay, car not running.
Who built the engine?
I think you posted the wrong video btw. that seems to be a still shot of your engine bay, car not running.
#5
Mr. Links
iTrader: (1)
#7
yes its a still shot of the car i turned it off cause i was worried something was seriously wrong with it, the idling rpms were hiccuping before i turned it off
Trending Topics
#14
Rotary Ninja
Join Date: Oct 2007
Location: Wichita Falls, TX
Posts: 683
Likes: 0
Received 0 Likes
on
0 Posts
there are 2 throttle stops. the one that is vertical and an actual screw adjusts the bottom throttle plate and affects the TPS voltage. the second one is horizontal and doesnt have a head. it adjusts the top 2 plates and has no effect on TPS voltage. make sure both are adjusted.
I recently did a vac simplification and emissions/air pump removal, and afterwards I had a strange idle problem. This is exactly what I did to fix mine, it should work for you.
Disconnect the ISC, it is the white connector on the back side of the UIM/TB.
I would suggest backing the vertical adjustment screw all the way out (make sure you lock it in place, or the vibration from the engine will drive it in, prevent the throttle plates from closing, and leave the engine in a very high rpm).
then turn the Bleed screw under the TB about 2 turns out (this will give you room to adjust the idle slightly higer or lower later).
start the motor and adjust the horizontal adjustment screw untill your idle is near where you would like it, or slightely higher, as you can lower it with the bleed screw later. I would suggest setting it around 750 or so, with A/C and all electronics off, as the ISC will raise idle to compensate for the A/C and electronics.
This should help you get your idle in check. I would check your TPS voltages while your at it. if that isnt tight, it will vibrate loose and cause all sorts of problems. Hope this helps.
I recently did a vac simplification and emissions/air pump removal, and afterwards I had a strange idle problem. This is exactly what I did to fix mine, it should work for you.
Disconnect the ISC, it is the white connector on the back side of the UIM/TB.
I would suggest backing the vertical adjustment screw all the way out (make sure you lock it in place, or the vibration from the engine will drive it in, prevent the throttle plates from closing, and leave the engine in a very high rpm).
then turn the Bleed screw under the TB about 2 turns out (this will give you room to adjust the idle slightly higer or lower later).
start the motor and adjust the horizontal adjustment screw untill your idle is near where you would like it, or slightely higher, as you can lower it with the bleed screw later. I would suggest setting it around 750 or so, with A/C and all electronics off, as the ISC will raise idle to compensate for the A/C and electronics.
This should help you get your idle in check. I would check your TPS voltages while your at it. if that isnt tight, it will vibrate loose and cause all sorts of problems. Hope this helps.
#15
Senior Member
Join Date: Nov 2007
Location: Warwickshire, UK
Posts: 251
Likes: 0
Received 0 Likes
on
0 Posts
Pop the elbow and check the throttle body. When my turbo's were dying, they dumped a lot of oil in the inlet. This then clogged up all the idle control gubbins, and I was left with a weird idle that randomly got higher and higher. Was idling at 2.5k at one point.
