Front mount intercooler
#3
half ass 2 or whole ass 1
iTrader: (114)
oh boy.... here we go with this old technology ****.... im so tired of hearing that term on this forum.
theres nothing wrong with a front mount. they work fine. are you looking for a kit or are you wanting to but just a front mount and make your own piping?
theres nothing wrong with a front mount. they work fine. are you looking for a kit or are you wanting to but just a front mount and make your own piping?
#6
Rotary Enthusiast
iTrader: (19)
Join Date: Apr 2002
Location: Colorado Springs, CO
Posts: 1,169
Likes: 0
Received 11 Likes
on
10 Posts
The V-mount is superior because it cools the air while reducing the piping volume for better response.
The FMIC is a inferior design to the V-mount because it doesn't perform as well in almost....yes almost every category. FMIC do well cooling the air charge, but at the expense of spool and cooling. the v-mount does it all.
You can make a v-mount cheap as well if you piece it all together and make the brackets yourself.
The FMIC is a inferior design to the V-mount because it doesn't perform as well in almost....yes almost every category. FMIC do well cooling the air charge, but at the expense of spool and cooling. the v-mount does it all.
You can make a v-mount cheap as well if you piece it all together and make the brackets yourself.
#7
Sponsor
iTrader: (41)
The problem is no one makes a nice bolt in v-mount kit right now except Greddy. Its a great kit but will run you close to $3600. There are RX-7store and Defined, but neither come with all the brackets that you will need to mount the power steering, a/c, etc. If you have some fabrications skills its not a big deal but it does take some work. I install a lot of Greddy kits at the shop because despite the price, they are extremely complete with all the brackets and ducting and work very well. For a front mount the best deal in my opinion is a Greddy M spec replica.
Trending Topics
#8
Rotary Enthusiast
iTrader: (19)
Join Date: Apr 2002
Location: Colorado Springs, CO
Posts: 1,169
Likes: 0
Received 11 Likes
on
10 Posts
The problem is no one makes a nice bolt in v-mount kit right now except Greddy. Its a great kit but will run you close to $3600. There are RX-7store and Defined, but neither come with all the brackets that you will need to mount the power steering, a/c, etc. If you have some fabrications skills its not a big deal but it does take some work. I install a lot of Greddy kits at the shop because despite the price, they are extremely complete with all the brackets and ducting and work very well. For a front mount the best deal in my opinion is a Greddy M spec replica.
#9
The Blitz FMIC is the a great solution, the placement does not extent the piping much further than the typical v-mount and it does not completely block the radiator like the Greddy (styles). Additionally comes with every bracket, bolt, hose, etc for installation and it does not require the front nose or bumper support to be modified.
#12
Full Member
Thread Starter
iTrader: (3)
Join Date: Oct 2007
Location: Bronx new york
Posts: 106
Likes: 0
Received 0 Likes
on
0 Posts
Thanks for replys guys
I know I will loose some spooling with the extra piping.
The goal is cooler air with the front mount. The turbo I'll be runing is an efr8379 or a gt35r.
And the hp goal will be 450.
I know I will loose some spooling with the extra piping.
The goal is cooler air with the front mount. The turbo I'll be runing is an efr8379 or a gt35r.
And the hp goal will be 450.
#14
Senior Member
Join Date: Feb 2013
Location: Fort Worth, TX.
Posts: 273
Likes: 0
Received 0 Likes
on
0 Posts
As said above ETS makes a quality kit for a good price
ETS Mazda RX7 FD Intercooler Upgrade Kit 1993-1995
Also you can do a Vmount for pretty cheap, Go with a Bell intercooler and either source the radiator from them as well or some other place. Piping is easy to get, brackets you can get from your local hardware store. Honestly it's really easy to make your own quality kit, don't need to spend a crazy amount to just be ripped off from aftermarket companies.
ETS Mazda RX7 FD Intercooler Upgrade Kit 1993-1995
Also you can do a Vmount for pretty cheap, Go with a Bell intercooler and either source the radiator from them as well or some other place. Piping is easy to get, brackets you can get from your local hardware store. Honestly it's really easy to make your own quality kit, don't need to spend a crazy amount to just be ripped off from aftermarket companies.
#16
Rotary Enthusiast
iTrader: (19)
Join Date: Apr 2002
Location: Colorado Springs, CO
Posts: 1,169
Likes: 0
Received 11 Likes
on
10 Posts
This is more important than a FMIC IMO. you get cold air into the intake, compress it, and need less intercooler power, with the V-mount you have fresh air cooling the intercooler, and radiator. He also went to a dual oil cooler set up.
