Complete TB Coolant line bypass
Just wondering if anyone has taken the TB coolant line removal any further than just moving the line from the back of the TB to the connection just under it?
Coolant normally runs from the block connection near the firewall and close to the rear rotor oil injector, to the TB, then to the coolant line that is right by the fuel lines, which carries it along the front top of the motor and joins back to the water pump housing. If this was run straight from the rear connection to the water pump housing, then one could remove the hard line that is connected to the bracket for the fuel lines and clean things up a bit.
I'm not sure if there is enough clearance to the left of the rat's nest connections (looking from the front of the engine) for the line to run through. It would essentially run right above the secondary injectors and fuel rail, straight up to the termination. Since I'm bored and I want to work on something, I'll give it a shot and see if I can make things fit.
Anyone thinking of anything that I could have overlooked? There is an attachment point that goes from the hard line for the coolant to the rat's nest, but this doesn't hold the rat's nest in because it is attached to a bracket that screws down to the block.
Let me know what you guys think.
Jason
Coolant normally runs from the block connection near the firewall and close to the rear rotor oil injector, to the TB, then to the coolant line that is right by the fuel lines, which carries it along the front top of the motor and joins back to the water pump housing. If this was run straight from the rear connection to the water pump housing, then one could remove the hard line that is connected to the bracket for the fuel lines and clean things up a bit.
I'm not sure if there is enough clearance to the left of the rat's nest connections (looking from the front of the engine) for the line to run through. It would essentially run right above the secondary injectors and fuel rail, straight up to the termination. Since I'm bored and I want to work on something, I'll give it a shot and see if I can make things fit.
Anyone thinking of anything that I could have overlooked? There is an attachment point that goes from the hard line for the coolant to the rat's nest, but this doesn't hold the rat's nest in because it is attached to a bracket that screws down to the block.
Let me know what you guys think.
Jason
#2
Banned. I got OWNED!!!
Join Date: Jul 2004
Location: next to the polishing wheel!!!
Posts: 1,179
Likes: 0
Received 1 Like
on
1 Post
I plug the rear iron with a pipe plug and I remove the steel tube on the water pump house and some are threaded and pluged and some are welded closed ,which ever the customer wonts .I do not connect the two nipples with a rubber hose . A hose is a failure point . I make a cover plate for the throttle body to cover the holes where the hot wax rod was .
#5
7-itis
Thread Starter
iTrader: (1)
Join Date: Aug 2004
Location: UPSTATE New York
Posts: 399
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by GARCO MOTORWORKS
I plug the rear iron with a pipe plug and I remove the steel tube on the water pump house and some are threaded and pluged and some are welded closed ,which ever the customer wonts .I do not connect the two nipples with a rubber hose . A hose is a failure point . I make a cover plate for the throttle body to cover the holes where the hot wax rod was .
I took some pics as I went along, so I will post those soon.
Thanks for the replies!
Jason
#6
www.lms-efi.com
iTrader: (27)
Originally Posted by gracer7-rx7
There was a thread about that ages ago. Some people in that thread were concerned about interrupting the flow of hot coolant by plugging that up. Others like GARCO above don't seem to have that concern.
We do it on race engines all the time. It is NOT an issue. I have an engine in for overhaul right now that originally built by Speedsource. It's plugged in a similar manner.
Trending Topics
#9
7-itis
Thread Starter
iTrader: (1)
Join Date: Aug 2004
Location: UPSTATE New York
Posts: 399
Likes: 0
Received 0 Likes
on
0 Posts
Pics as promised
And with everything mounted back on there:
I would love to tap and properly plug the holes, but I don't want shavings to get into the coolant and I think it would be a little difficult to get the one on the rear iron. Not even going to bother with rubber caps.
I didn't have any clearance problems to speak of, however I do not have the primary or secondary injectors in but the plugs for them seem to line up fine.
I'm getting good at this whole rat's nest removal/installation thing It is much less intimidating now, and I'm getting a basic understanding of how ***** routed.
Jason
And with everything mounted back on there:
I would love to tap and properly plug the holes, but I don't want shavings to get into the coolant and I think it would be a little difficult to get the one on the rear iron. Not even going to bother with rubber caps.
I didn't have any clearance problems to speak of, however I do not have the primary or secondary injectors in but the plugs for them seem to line up fine.
I'm getting good at this whole rat's nest removal/installation thing It is much less intimidating now, and I'm getting a basic understanding of how ***** routed.
Jason
#10
RX-7 Bad Ass
iTrader: (55)
I've done a few different techniques on the many FC's I've worked on, and here's some of my findings -
Running the hose from the rear nipple to the water pump nipple will work, but the line has to be VERY well routed so it isn't pinched or rubbing on something. I've seen about 2 of these hoses fail on an FC when routed like that due to being pinched, but FC upper intake manifolds sit MUCH closer to the block than the FD's. If the line is routed well, that could work. For extra measure, I would put split loom tubing or something over the hose to prevent it from being chafed.
Using rubber vacuum caps is a HUGE no-no. The cheap ones from the auto parts store have NO business on an FD, period - not for vacuum caps, not for coolant, nothing. Now, for vacuum caps, I have used a high-temp rubber cap from McMaster-Carr that works great, but I wouldn't use it for coolant - the rubber has to be compatible with coolant and the pressure and heat it sees, and I doubt those caps are compatible.
However, one kinda ghetto but works great trick is to take the stock rubber hose, cut a short length, stick a bolt of appropriate size in one end and hose clamp that down, then hose clamp the hose "cap" on the nipple. Looks ghetto when you see it, but it holds up GREAT, far better than any cap.
Welding or tapping/plugging is the 100% best way to go. But, this usually isn't feasible without serious disassembly.
Personally, I run the coolant through the throttle body. The warmup feature works well, and I really don't think a warm throttle body is robbing me of that much horsepower. But, I can understand doing so if you're single turbo/no emissions and going "bare block".
Dale
Running the hose from the rear nipple to the water pump nipple will work, but the line has to be VERY well routed so it isn't pinched or rubbing on something. I've seen about 2 of these hoses fail on an FC when routed like that due to being pinched, but FC upper intake manifolds sit MUCH closer to the block than the FD's. If the line is routed well, that could work. For extra measure, I would put split loom tubing or something over the hose to prevent it from being chafed.
Using rubber vacuum caps is a HUGE no-no. The cheap ones from the auto parts store have NO business on an FD, period - not for vacuum caps, not for coolant, nothing. Now, for vacuum caps, I have used a high-temp rubber cap from McMaster-Carr that works great, but I wouldn't use it for coolant - the rubber has to be compatible with coolant and the pressure and heat it sees, and I doubt those caps are compatible.
However, one kinda ghetto but works great trick is to take the stock rubber hose, cut a short length, stick a bolt of appropriate size in one end and hose clamp that down, then hose clamp the hose "cap" on the nipple. Looks ghetto when you see it, but it holds up GREAT, far better than any cap.
Welding or tapping/plugging is the 100% best way to go. But, this usually isn't feasible without serious disassembly.
Personally, I run the coolant through the throttle body. The warmup feature works well, and I really don't think a warm throttle body is robbing me of that much horsepower. But, I can understand doing so if you're single turbo/no emissions and going "bare block".
Dale
#13
All Spooled Up
iTrader: (7)
Originally Posted by GARCO MOTORWORKS
I plug the rear iron with a pipe plug and I remove the steel tube on the water pump house and some are threaded and pluged and some are welded closed ,which ever the customer wonts .I do not connect the two nipples with a rubber hose . A hose is a failure point . I make a cover plate for the throttle body to cover the holes where the hot wax rod was .
Like he said. I pull out the nipples and tap the rear iron 1/4" NPT and TIG weld shut the front one. No failures now...
tom
#14
Full Member
Join Date: Nov 2007
Location: Dearborn, MI
Posts: 103
Likes: 0
Received 0 Likes
on
0 Posts
would drilling/ tapping the rear iron be feasibly with the keg assembled? i mean concerning getting debris into the cooling system?
i guess one could just flush it out by putting a garden hose up agains the water pump inlet and ghetto sealing it on there with your hand/ a rag. does that sound like it would clean everything out reasonably well? anyone else have any good techniques for flushing the coolant?
