Starter Trouble
We just installed a new starter in our 85 RX7 (12A). Now, when we attempt to hook up the battery, the engine tries to start, even though the key is not even in the ignition. Ignition switch was working properly prior to the starter install and is working fine in all other respects. Wires appear to be connected correctly. What are we missing?
#2
Senior Member
iTrader: (6)
We just installed a new starter in our 85 RX7 (12A). Now, when we attempt to hook up the battery, the engine tries to start, even though the key is not even in the ignition. Ignition switch was working properly prior to the starter install and is working fine in all other respects. Wires appear to be connected correctly. What are we missing?
#3
Full Member
Thread Starter
Join Date: Sep 2006
Location: NE PA
Posts: 94
Likes: 0
Received 0 Likes
on
0 Posts
I had the same thing happen to me earlier this winter.. are you getting your starters at Napa? I had to order in 4 starters, and only one of them was correct. The problem is that thick copper wire running from the solenoid to the motor is hooked up to the wrong prong, but it can't just be switched i'll post up a picture of a faulty one they gave me, and try to make some sense!
#4
Senior Member
iTrader: (6)
This is a brand new napa starter, that ran nonstop as soon as I reconnected the battery. When I first picked up this starter, that fat copper wire was hooked up to the prong on the left (2), not (3). I took it back to napa, and we checked out my core. Thinking we had solved the problem, we ran that wire over to prong (3) and I went home and tried it again.
Same thing happened again, instant power to the starter, as soon as I plugged in my battery. By this time, they had already sent my core away, so we began to order in starter after starter. The fourth one showed up, and we figured out the problem.
The metal plate, marked (1), should be on prong (3), NOT (2). As soon as power hits that plate, the starter is going to run no matter what. The correct starter should have the copper wire coming out of the starter motor around the STAR area, and basically following that curved line to the prong.
I hope this makes some sense, just take a look at the starter you have. (1) should be on prong (3), and the copper should be run to prong (3) originally, not prong (1)
#5
Senior Member
iTrader: (6)
Yeah my experience was horrible with napa.. after the 2nd and 3rd starters came in backwards, I asked for my refund. Beings they had already sent off my core, they said they had no way of refunding me my core charge, but just the 70 bucks for the starter. Long story short... I started making an *** of myself.. and told the guy "I'LL SIT HERE AND ORDER IN 100 STARTERS IF I HAVE TO, AND THEY'RE ALL GOING TO BE WRONG! JUST LET ME KEEP THIS ONE AS A CORE AND I'LL GO SOMEWHERE ELSE."
.................................................
he overnighted 2 more, and the fourth one that came in was hooked up correctly. It was also painted flat black as well...... what do you do?! Just keep ordering in until you get it.. because they are out there floating around in the napa warehouses.
.................................................
he overnighted 2 more, and the fourth one that came in was hooked up correctly. It was also painted flat black as well...... what do you do?! Just keep ordering in until you get it.. because they are out there floating around in the napa warehouses.
Trending Topics
#8
Damn, it did start!
Does this mean NAPA is slipping or is this an obscure incident?
#10
Full Member
Thread Starter
Join Date: Sep 2006
Location: NE PA
Posts: 94
Likes: 0
Received 0 Likes
on
0 Posts
#11
Senior Member
iTrader: (6)
Just keep trying! This is a Napa problem, and I think we must be the only two who have ever ordered a 1st gen starter from them. Like I said, my correct starter arrived and it was flat black, i'm pretty sure they have an extra hereat the Minot store.. but have them order in several and hopefully one will turn up. Better luck! Justin
#12
Full Member
Thread Starter
Join Date: Sep 2006
Location: NE PA
Posts: 94
Likes: 0
Received 0 Likes
on
0 Posts
Just keep trying! This is a Napa problem, and I think we must be the only two who have ever ordered a 1st gen starter from them. Like I said, my correct starter arrived and it was flat black, i'm pretty sure they have an extra hereat the Minot store.. but have them order in several and hopefully one will turn up. Better luck! Justin
#13
Senior Member
iTrader: (6)
Originally Posted by Leading Rotarian;1[RIGHT
[/RIGHT]0530646]They sell two different models. We are trying the other model.
#16
Full Member
Thread Starter
Join Date: Sep 2006
Location: NE PA
Posts: 94
Likes: 0
Received 0 Likes
on
0 Posts
Gave up on NAPA after three starters. It came to a head when the NAPA folks first blamed my ignition switch and then me for the problem. Went to Advance auto. They had a picture of the starter on their computer at the store and in the picture starter was set up just like my original. Picking it up today.
#23
Waffles - hmmm good
iTrader: (1)
My parts store preferences:
1. Advanced Auto - its close and I can order on the web and pick up in the store. They usually have the right parts.
2. O'reillys - They let me walk back in the parts bins to help pick out the right parts and try really hard to help out.
3. Walmart - Cause its cheap stoopid!
4. CarQuest - For really odd ball stuff that just has to be ordered in and the above don't carry it. Also the place for special fluids like silicone brake fluid.
5. Autozone - When desparate.
6. Napa - Never go there.
1. Advanced Auto - its close and I can order on the web and pick up in the store. They usually have the right parts.
2. O'reillys - They let me walk back in the parts bins to help pick out the right parts and try really hard to help out.
3. Walmart - Cause its cheap stoopid!
4. CarQuest - For really odd ball stuff that just has to be ordered in and the above don't carry it. Also the place for special fluids like silicone brake fluid.
5. Autozone - When desparate.
6. Napa - Never go there.
#25
Senior Member
iTrader: (6)
Update
Just an update, the starter that napa finally found for me is junk! Last may, it started spinning only and not kicking out. It only kicked out when it wanted to, so it was a guessing game on when I would be able to start the car.
Between that, the horrendous summer flood, and being down a leading igniter, I never drove it enough to make it a top priority. I replaced the battery cables to the starter, the igniter, and it is getting more than enough power. The car is running like a top, WHEN the starter decides to kick out.
Today, I picked up an o'reilly starter, and I will report how it does soon! I was very tempted to order an fc starter, but didn't want to go and track down the long starter bolt I needed. I am happily bringing my napa starter back for the $17 dollar core charge!
Justin
Between that, the horrendous summer flood, and being down a leading igniter, I never drove it enough to make it a top priority. I replaced the battery cables to the starter, the igniter, and it is getting more than enough power. The car is running like a top, WHEN the starter decides to kick out.
Today, I picked up an o'reilly starter, and I will report how it does soon! I was very tempted to order an fc starter, but didn't want to go and track down the long starter bolt I needed. I am happily bringing my napa starter back for the $17 dollar core charge!
Justin
