dhahlen

iTrader: (5)

Just curious on what to expect with this setup and tuning from XS.

Engine with 3mm Seals
T78 Turbo (Actually A MHI TD-06)
50mm Wastegate
Downpipe, Midpipe, Catback
HKS Type S FMIC
550 Primary, 1600 Secondary with Fuel pressure Regulator
Apexi Power FC & AVC-R
Koyo Raditor
ACT Clutch Kit

No porting on the engine.

I am curious how much boost I should be using, the turbo spools around 3800rpm I'm told. Usually high hp apps it's better to have an unported motor. I want to push 500hp if possible, but I am not sure if this setup will get me where I need to be. I might upgrade the fuel system to 850/1600 or 1000/1600 either way please post your insight and let me know what you all think!

Thanks,
-Darren-

gen3RxProj

id say about 400 at 15 and 500 (maybe) 20-21 psi. conservatively tuned.... PORT IT!

gen3RxProj

I'd suggest 1000/1600, hell i even have 1300/1600 for my setup.(gonna go for high high hp sometime). I have the aeromotive 1000hp fuel pump. everyone says its loud but I can't even hear it.

dhahlen

iTrader: (5)

why do you say port the engine? i hear for high hp, you want to leave it unported. Hrmm, can the engine safely handle 20psi? I dont want to blow another seal... hah

RX7WEEE

iTrader: (16)

ummmm porting makes HP.... the bigger the port the more air u can force into the combustion chamber.

so a 1/2 bridge ported motor will make alot more power than a street port because it can flow alot more air into it.

dhahlen

iTrader: (5)

i'll check it out! Thanks for the info.. keep posting if you have any more suggestions.

93FD3S

Its not just the size of the port that makes horsepower but rather the method and other upgrades in conjunction with the port.

nyt

iTrader: (1)

your numbers are way high

widebody2

Hate to break it to you but a MHI TD06 is quite a bit smaller than a greddy T78. The T78 is a hybrid of the MHI TD08. A t-88 is a full TD08. I believe there are 3 different TD08s and the T-88 is the largest of the 3...That last part is a faint memory so don't quote me on it. There is zero chance that you can make 500 hp with the TD06...I think 400 is even tough. I haven't looked in a while but even the old greddy adds would say that the TD06 kit was basically for someone who was satisfied with the power of the twin setup but wanted to simplify things.

nyt

iTrader: (1)

... i run 550s and 1680s on a setup that makes over 450 with a walbro pump, rest of fuel system stock...

overkill will only hurt your gase economy

widebody2

The turbo to the right is a smaller TD08. It is basically a T78. The one next to it is a T04b with a .6, .96 ar, the smallest is a t25. Have you seen your turbo compared to any other turbos? How big is it compared to these? Probably impossible to tell by pictures...

gen3RxProj

How long do 550's last with a gt42?

widebody2

you don't need to upgrade your injectors

nyt

iTrader: (1)

yes, you do...
maybe not primary injectors, but 550/850 combo will max out pretty easy

widebody2

take another look at his current setup

widebody2

NYT where on LI are you?

nyt

iTrader: (1)

i dont see any injectors listed in his primary setup? I only see the ones that are hypothetical (which would be fine)

widebody2

Yeah I was looking at his thing with the single turbo and ment he didn't need to upgrade the primaries like he was talking about right after his little list there. For some reason I was thinking his car actually had all that stuff and was getting tuned by xs right now...I am a little too lazy to read the small print sigs

dhahlen

iTrader: (5)

I thought it wsa a TD06, this kit is a TD08 then... I purchased the kit off of WB2 so he knows the ****... I just wanted some ideas....

So TD08, not TD06 correct? lol

Klar

Bigger porting changes your power band, spools bigger turbos faster, and achives higher hp#'s with less boost due to more airflow. Pick your port then match with a proper sized turbo for the power/responce that you want.

widebody2

aww hey whats up...didn't know that was you. Yeah thats a TD08.

dhahlen

iTrader: (5)

Rockin... whew... had me scared for a second! Your turbo is a hair smaller I believe you mentioned that. WHat are you pushing with your setup?

maxcooper

Estimate your fuel system capacity here:
http://maxcooper.com/rx7/how-to/fuel_system/calcs.html

-Max
