Race Car Tech Discuss anything related to road racing and auto X.

SCCA Autocross Class FD RX7

Old 06-24-16, 09:55 AM
  #1
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
VA SCCA Autocross Class FD RX7

Good morning all,

I would like to autocross my FD. However, it has some mods that departs from it's AS class. After being put to sleep (on numerous occasions) from reading the SCCA rules; I just can't make any sense out of it. My goal is to accurately classify the car; not that it (or I for that matter) would compete in nationals. Therefore, I seek the advise from this group! Can you help assess which class this car would run in?

The specifics are:
94 FD Touring, MB
stock suspension
rebuilt engine with 2,500mi (with full rat's nest - no simplified rat's nest)
99 efini sequential turbo
hollowed cat (will replace with hi-flow cat soon)
r1 dual oil coolers
ast deleted
open intake (2 narrow K&N air filters)
efini y-pipe
greddy hard pipes
blitz SMIC
front strut tower brace (not factory; think it was a cusco aluminium brace)
fluidyne rad
2000 Type RZ wheels: front 235/45ZR17 rear 255/40ZR17

Thanks again for helping me assess the car and make sense of the 2016 rule book!
Cheers,
George
Gen2n3 is offline
Old 06-24-16, 11:02 AM
  #2
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
I hope this is the only omission to the list of parts:
Bonez downpipe is also installed.
Gen2n3 is offline
Old 06-24-16, 11:55 AM
  #3
Lives on the Forum
iTrader: (9)

BLUE TII's Avatar

Join Date: Mar 2001
Location: CA
Posts: 7,070
Liked 145 Times in 128 Posts
Technically, you would be in Super Street Mod (SSM) because the '99 spec turbos although stock Mazda components were never sold in the US.

Really, you should be in A Street Prepared (ASP) as long as your rebuilt motor is not ported and has stock internals.
BLUE TII is offline
Old 06-24-16, 12:24 PM
  #4
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
Originally Posted by BLUE TII View Post
Technically, you would be in Super Street Mod (SSM) because the '99 spec turbos although stock Mazda components were never sold in the US.

Really, you should be in A Street Prepared (ASP) as long as your rebuilt motor is not ported and has stock internals.
Thanks, Blue TII!

And yes, the motor internals are stock and no porting.
Gen2n3 is offline
Old 06-24-16, 12:28 PM
  #5
Rotary Enthusiast
iTrader: (2)

Rocketeerbandit's Avatar

Join Date: Aug 2014
Location: Rockledge, FL
Posts: 766
Liked 15 Times in 12 Posts
Im in ASP but after installing Ohlins, pfc ecu, and 99 turbos, I should be in SSM
Rocketeerbandit is offline
Old 06-24-16, 01:13 PM
  #6
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
Rocketeer, how did you fair against others in ASP at your local chapter?
Gen2n3 is offline
Old 06-24-16, 02:17 PM
  #7
1308ccs of awesome
iTrader: (9)

eage8's Avatar

Join Date: Sep 2003
Location: Woodbine, MD
Posts: 6,175
Liked 10 Times in 10 Posts
In Virginia beach there is a group of guys that run a local class which is basically street modified class with street tires. Just run that and have fun.
eage8 is offline
Old 06-24-16, 02:45 PM
  #8
Rotary Enthusiast
iTrader: (2)

Rocketeerbandit's Avatar

Join Date: Aug 2014
Location: Rockledge, FL
Posts: 766
Liked 15 Times in 12 Posts
There isn't a lot of ASP drivers locally. So sometimes I automatically get bumped in a higher class. But it's a tough class, I'm not going to lie. But I'm not far behind. I'm actually have competing times with BSP like mazdaspeed miatas. I'm literally a second or two behind drivers in that class raw time.
Rocketeerbandit is offline
Old 06-24-16, 08:54 PM
  #9
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
Originally Posted by eage8 View Post
In Virginia beach there is a group of guys that run a local class which is basically street modified class with street tires. Just run that and have fun.
eage8, thanks! I'll have to look into that. I should be running next weekend.
Gen2n3 is offline
Old 06-24-16, 08:56 PM
  #10
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
Originally Posted by Rocketeerbandit View Post
There isn't a lot of ASP drivers locally. So sometimes I automatically get bumped in a higher class. But it's a tough class, I'm not going to lie. But I'm not far behind. I'm actually have competing times with BSP like mazdaspeed miatas. I'm literally a second or two behind drivers in that class raw time.
So, you get bumped up to SSP? If you run 1sec behind those speed miatas then that's mighty impressive!
Gen2n3 is offline
Old 06-25-16, 07:22 AM
  #11
Rotary Enthusiast
iTrader: (2)

Rocketeerbandit's Avatar

Join Date: Aug 2014
Location: Rockledge, FL
Posts: 766
Liked 15 Times in 12 Posts
Thank you @Gen2n3 I can try to find the final times
Rocketeerbandit is offline
Old 06-25-16, 07:57 AM
  #12
Rotary Enthusiast
iTrader: (2)

Rocketeerbandit's Avatar

Join Date: Aug 2014
Location: Rockledge, FL
Posts: 766
Liked 15 Times in 12 Posts

Last edited by Rocketeerbandit; 06-25-16 at 08:00 AM.
Rocketeerbandit is offline
Old 07-30-16, 03:57 PM
  #13
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
VA Pungo Airfield AutoX Runs

After getting good feedback from this thread, I ran my FD on 3 July. Thanks, Blue TII and Rocketeerbandit for the advice.

Here is a link to all 6 autocross runs at Pungo Airfield, VA:

More details from this event are in the description.

Enjoy the link!
Gen2n3 is offline
Old 07-30-16, 04:50 PM
  #14
Rotary Enthusiast
iTrader: (2)

Rocketeerbandit's Avatar

Join Date: Aug 2014
Location: Rockledge, FL
Posts: 766
Liked 15 Times in 12 Posts
What camera do you use? The Garmin?
Rocketeerbandit is offline
Old 07-30-16, 05:07 PM
  #15
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
Yes, I use the Garmin VIRB XE (Auto Racing Bundle). The bundle comes with an OBD module that records a lot more info.
Gen2n3 is offline
Old 07-30-16, 06:30 PM
  #16
Rotary Enthusiast
iTrader: (2)

Rocketeerbandit's Avatar

Join Date: Aug 2014
Location: Rockledge, FL
Posts: 766
Liked 15 Times in 12 Posts
Here's sOme videos






And previous autocross

Rocketeerbandit is offline
Old 07-30-16, 06:39 PM
  #17
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
Fast runs! I like the fender cam perspective. It looked like a few cones came close to the GoPro!
Gen2n3 is offline
Old 08-07-16, 03:21 PM
  #18
Junior Member
iTrader: (9)

denizpa's Avatar

Join Date: Dec 2010
Location: Bethlehem
Posts: 41
Likes: 0
Liked 0 Times in 0 Posts
Hey,

I have some similar modifications and i've been running in ASP.

I've been fairly competitive; what keeps me back is not having a set of Hoosier A6s yet. Even then, there is an STI in ASP with hoosiers and our times are very similar.

I need some more camber upfront; does anyone have a good recommendation on adjustable camber plates that will play nice with my HKS Hipermax IV GTs? Does anyone run these: Cusco Pilllowball Front Mazda RX-7 FD3S

Here are some of my videos from this season:

https://www.youtube.com/watch?v=xTVZ...ature=youtu.be

https://www.youtube.com/watch?v=nLey...ature=youtu.be

https://www.youtube.com/watch?v=2LNm...ature=youtu.be

Last edited by denizpa; 08-07-16 at 03:24 PM.
denizpa is offline
Old 08-07-16, 03:39 PM
  #19
Junior Member
iTrader: (9)

denizpa's Avatar

Join Date: Dec 2010
Location: Bethlehem
Posts: 41
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by Gen2n3 View Post
Yes, I use the Garmin VIRB XE (Auto Racing Bundle). The bundle comes with an OBD module that records a lot more info.
This might be an ignorant question; I was under the impression that the obd reader for the virb won't get much data given that it's OBD1. What kind of data are you gathering?

I've been using go pros but I would certainly consider upgrading to the virb if the data is good!
denizpa is offline
Old 08-07-16, 03:55 PM
  #20
Lives on the Forum
iTrader: (9)

BLUE TII's Avatar

Join Date: Mar 2001
Location: CA
Posts: 7,070
Liked 145 Times in 128 Posts
I need some more camber upfront; does anyone have a good recommendation on adjustable camber plates that will play nice with my HKS Hipermax IV GTs? Does anyone run these: Cusco Pilllowball Front Mazda RX-7 FD3S

FD RX-7 is not strut front suspension (thank god), so we can use the stock front lower control arm front eccentric adjuster to add camber.

If you already have this stock available camber maxed out (around -2.5 at stock height) you will have to functionally or actually change the lengths of upper and/or lower suspension arms.

In ASP you are allowed to replace any *suspension* bushing with offset bushings (so you can do upper and/or lower).

SuperPro has offset upper and lower bushings to add more camber to the front of the FD-

http://www.superpro.com.au/find/supe.../cid-999500856

Or you can make your own-

https://www.rx7club.com/suspension-w...shings-941277/

In addition to offset suspension bushings, in ASP you may substitute aftermarket upper OR lower control arm to change camber (but not both) and the changed arm is NOT allowed to change the roll center (by moving ball joint location).

For the FD you will probably then use some of the aftermarket adjustable upper arms.

As far as I know the lower arms available correct for roll center as well.
BLUE TII is offline
Old 08-08-16, 09:09 PM
  #21
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
Originally Posted by denizpa View Post
This might be an ignorant question; I was under the impression that the obd reader for the virb won't get much data given that it's OBD1. What kind of data are you gathering?

I've been using go pros but I would certainly consider upgrading to the virb if the data is good!
Denizpa,

For my FD, I only capture recorded speed, lat-G's, lap times, total times, heading, course map+position. On my MINI Clubman, the OBD2 module captures RPM, MAF, Engine Load, Coolant Temp, throttle/brake data, etc.

I prefer the VIRB over the GoPro because of the data it captures then displayed as overlays on the video. I also found the video quality and options to be superior to the GoPro (3 or 4). The editing software (VIRB Edit) is fairly straight forward and easy to use. You can also customize the gauges and arrange them to suit your needs. It won me over just for the course map!

Remember that our cars are not OBD2 compliant, or OBD1 for that matter! We only have the diagnostic port in the engine bay so the OBD2 module that comes with the VIRB Auto Racing bundle will not even fit. The OBD2 module only works with OBD2 compliant vehicles.

Did I answer your question?
Gen2n3 is offline
Old 08-08-16, 09:15 PM
  #22
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
To follow up with the previous post about VIRB data, here's my latest auto-x run from Sunday. There are 2 "oops" moments in it. I also added a custom graphic in the speedometer. Enjoy the video!


Last edited by Gen2n3; 08-08-16 at 09:16 PM. Reason: Added small note
Gen2n3 is offline
Old 08-08-16, 09:28 PM
  #23
Moderator
Thread Starter
iTrader: (1)

Gen2n3's Avatar

Join Date: Jun 2004
Location: Virginia Beach, VA
Posts: 1,554
Liked 141 Times in 128 Posts
Denizpa,

I watched your 3 videos and I am impressed! That was some great driving! I am also jealous about the size of the tracks. The track I normally run on is much smaller than the locations you were at. Then again, each location brings its own challenges.

Thanks for sharing the videos!
Gen2n3 is offline
Old 08-09-16, 08:28 PM
  #24
Junior Member
iTrader: (9)

denizpa's Avatar

Join Date: Dec 2010
Location: Bethlehem
Posts: 41
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by BLUE TII View Post
I need some more camber upfront; does anyone have a good recommendation on adjustable camber plates that will play nice with my HKS Hipermax IV GTs? Does anyone run these: Cusco Pilllowball Front Mazda RX-7 FD3S FD RX-7 is not strut front suspension (thank god), so we can use the stock front lower control arm front eccentric adjuster to add camber. If you already have this stock available camber maxed out (around -2.5 at stock height) you will have to functionally or actually change the lengths of upper and/or lower suspension arms. In ASP you are allowed to replace any *suspension* bushing with offset bushings (so you can do upper and/or lower). SuperPro has offset upper and lower bushings to add more camber to the front of the FD- http://www.superpro.com.au/find/supe.../cid-999500856 Or you can make your own- https://www.rx7club.com/suspension-w...shings-941277/ In addition to offset suspension bushings, in ASP you may substitute aftermarket upper OR lower control arm to change camber (but not both) and the changed arm is NOT allowed to change the roll center (by moving ball joint location). For the FD you will probably then use some of the aftermarket adjustable upper arms. As far as I know the lower arms available correct for roll center as well.
Thank you very much for this information, this is very helpful. I'm going to check out the camber bushings and see how that feels.
denizpa is offline
Old 08-09-16, 08:31 PM
  #25
Junior Member
iTrader: (9)

denizpa's Avatar

Join Date: Dec 2010
Location: Bethlehem
Posts: 41
Likes: 0
Liked 0 Times in 0 Posts
Originally Posted by Gen2n3 View Post
Denizpa, I watched your 3 videos and I am impressed! That was some great driving! I am also jealous about the size of the tracks. The track I normally run on is much smaller than the locations you were at. Then again, each location brings its own challenges. Thanks for sharing the videos!
Thanks for the feedback. Your videos are pretty nice as well, I love the overlay. I'll have to check out the virb maybe next season.

There are a lot of very competitive guys in my region so the best I've ever been in pax is 20/~140.
denizpa is offline
