My first rotary almost caught fire...plan for it not to happen again

3rd Generation Specific (1993-2002) 1993-2002 Discussion including performance modifications and Technical Support Sections.

My first rotary almost caught fire...plan for it not to happen again

Old 09-28-15, 11:49 AM
  #1
Full Member
Thread Starter
iTrader: (11)

Join Date: Oct 2006
Location: South Carolina
Posts: 105
Received 1 Like on 1 Post
SC My first rotary almost caught fire...plan for it not to happen again

Ok so my plan was to keep this RX7 a rotary powered daily driver. That almost came to an end yesterday after running to the store the car drove fine no issues sequential set up working perfect. On the way home during a spirited drive the boost pattern was all over the place. Pull into the driveway and the smoke started coming from under the hood and I could smell fuel. I ran inside the house and grabbed my fire extinguisher from the kitchen. Came back outside popped the hood and no fire just some smoke residue and a strong smell of fuel. So I let the car cool down and and pressurize the fuel system to see whats going on. I can't see under the upper intake but I can hear fuel leaking and fuel is pouring on to the ground under the car. So I pull the intake off,coils and rats nest off, by the way all the vacuum lines are hard as rock and broke during this process. Looks like the Fuel Pulsation Dampener is leaking,so now its time to start buying parts. This car has been sitting in a garage for almost 11years, i was able to get some history on the car per the owner it is as follows:
1994 R2 black on black 68k miles
M2 upgraded ball bearing turbos
M2 upgraded ECM
M2 medium intercooler
M2 air intake
down pipe and cat back not sure what kind
Seq. set up running 12#s of boost
Here are my plans:
What I have come up with so far:
New FPD and fuel recall kit(I also have some bigger injectors to put in and move the secondaries to the primary spot) not sure how involved this process is???
New vacuum lines,Dales check valves, block off plates for all emissions
Do a simplified seq. set up and delete all the emissions and air pump
Install the mid pipe no cats. that came with the car
Install the APEXI Power FC that came with the car new in the box
Install new Ron Davis radiator that came with the car
I just want to make sure I am not forgetting anything since this is my first rotary powered car. BTW that rats nest is a pain in the *** to work on!!!!!! hopefully with the new soft vacuum lines it will go in easier then it came out.
ls1swap is offline
Old 09-28-15, 01:09 PM
  #2
Rotary Enthusiast
iTrader: (31)

Spalato's Avatar

Join Date: Jul 2004
Location: US/EU
Posts: 912
Received 27 Likes on 18 Posts
Glad you and your car are safe.

I'm not sure if this is the correct information, but I'm under the impression that lifting your hood up when there is a pontential of fire is not a good idea as this gives the fire more air to breathe and expand. I would think that extinguishing it from below is a safer approach.

As I said this is just an assumption, I have no experience with engine fires.
Spalato is offline
Old 09-28-15, 01:30 PM
  #3
PedoBear
iTrader: (4)

nycgps's Avatar

Join Date: Jun 2006
Location: Bye NYC. you SUCKED!
Posts: 1,420
Received 0 Likes on 0 Posts
^^ you are right, you do NOT open the hood when you know there is a chance of having engine fire. fire goes to the direction of oxygen (air), when u open the hood it introduces a LOT of oxygen and might make it worst, depends on the type of fire extinguisher you have you gonna have to spray it differently.
nycgps is offline
Old 09-28-15, 02:24 PM
  #4
Tony Stewart Killer.
iTrader: (12)

Snook's Avatar

Join Date: Mar 2002
Location: FL
Posts: 5,150
Likes: 0
Received 0 Likes on 0 Posts
tune it after, make sure
Snook is offline
Old 09-28-15, 02:28 PM
  #5
Rotary Enthusiast
5 Year Member

96fd3s's Avatar

Join Date: Apr 2008
Location: NZ
Posts: 1,092
Likes: 0
Received 0 Likes on 0 Posts
Glad you found the problem before it became a real problem!

In order to install new, larger injectors your going to need a new fuel rail, fuel pressure reg, fuel lines to suit, and probably a new fuel pump (or there's not much point in new, larger injectors)

I think in order to put the secondaries in the primary spot you need to have the rail milled down a little bit. (iv never done it but im pretty sure thats whats required). BUT if your putting in new, bigger secondaries then I question the reasoning of putting the bigger (old) injectors in the primary position.

You going to have more then enough fuel with new, larger secondaries, and the stock secondaries in the primary position are just going to make it idle worse.

I would say install the new secondaries, fuel rail etc, but leave the stock primaries there, unless you really need the fuel. Which I don't think you do.
96fd3s is offline
Old 09-28-15, 02:33 PM
  #6
It Just Feels Right
iTrader: (10)

TomU's Avatar

Join Date: Feb 2014
Location: Arlington, VA
Posts: 1,639
Received 58 Likes on 56 Posts
bench check any mechanical/electrical items you re-install (i.e. solenoids/actuators/coils/etc). FSM details this (also check the solenoids warm as well)

Deleting cats makes your exhaust stinky BTW
TomU is offline
Old 09-29-15, 07:30 AM
  #7
Lousy Crew Chief
iTrader: (8)

Join Date: Feb 2010
Location: Surprise, AZ
Posts: 964
Likes: 0
Received 45 Likes on 31 Posts
Work slow replacing the vacuum lines. Get some good quality silicone hose and it won't get hard again. For the rats nest, I cut each hose in half, one at s time, and heat up the connection with a light let before gently twisting the break the seal and pulling it off. Each rats nest solenoid new from Mazda is $60-70 so take your time. Your coil harness is probably crispy and could use a replacement. Repacking the injectors would also be a good idea. Mine were beginning to spider web on my rx7 with 64k.

Matt
Mrmatt3465 is offline
Old 09-29-15, 03:45 PM
  #8
ArmitageFD3S
iTrader: (13)

ArmitageGVR4's Avatar

Join Date: Oct 2002
Location: Herndon, Virginia
Posts: 2,209
Received 8 Likes on 6 Posts
Originally Posted by TomU View Post
bench check any mechanical/electrical items you re-install (i.e. solenoids/actuators/coils/etc). FSM details this (also check the solenoids warm as well)

Deleting cats makes your exhaust stinky BTW
+1 for both of these. Troubleshooting solenoid-related boost issues after everything is back together => you hating life.
ArmitageGVR4 is offline
Old 09-29-15, 05:42 PM
  #9
Moderator
iTrader: (25)

Spirit-RE's Avatar

Join Date: Dec 2008
Location: Janesville, WI
Posts: 2,922
Received 13 Likes on 13 Posts
Glad your car is OK!

The pulsation dampener on my FD started leaking after a day long cruise/spirited drive. Got it home and smelled a strong fuel odor, let it cool down, and had steady fuel drips from the God forsaken thing. Some scary ****, thinking how close it nearly was to burning to the ground. Thread a blockoff into the rail, and never worry about it again, those pulsation dampeners belong nowhere but the trash.
Spirit-RE is offline
Old 09-30-15, 05:06 AM
  #10
Full Member
Thread Starter
iTrader: (11)

Join Date: Oct 2006
Location: South Carolina
Posts: 105
Received 1 Like on 1 Post
Thanks for the advice so far, I will look into the fuel injectors a little more when I get to that point. From reading on the forum I assumed this was a common practice(moving the stock secondaries to the primary fuel rail and adding new larger injectors to the secondary rail)Ordered vacuum lines and check valves per Dale Clark and got with Ray Crowe for the other parts.
ls1swap is offline
Old 09-30-15, 06:15 AM
  #11
Form > Function
iTrader: (101)

MattGold's Avatar

Join Date: Dec 2003
Location: Metro Detroit
Posts: 1,600
Received 166 Likes on 91 Posts
Moving the secondaries to the primary spot IS a common "upgrade"... but then again, so is crappy idle.

If you're deleting emissions, I would also purchase a JDM UIM and LIM and S8 JDM Compression Tube.

The JDM UIM and LIM are a bit cleaner and already have some equipment delete which will result in less block off plates. The S8 JDM Compression Tube (No ACV Nipple) already has the ACV deleted, so no need for a cap.


Last edited by MattGold; 09-30-15 at 06:31 AM.
MattGold is offline
Old 09-30-15, 07:31 AM
  #12
Tony Stewart Killer.
iTrader: (12)

Snook's Avatar

Join Date: Mar 2002
Location: FL
Posts: 5,150
Likes: 0
Received 0 Likes on 0 Posts
I used 850 stock injectors In primary rail without issues. Had 1600 secondaries. No idle issues at all.
Snook is offline
Old 10-01-15, 07:58 PM
  #13
Sponsor
RX7Club Vendor
iTrader: (41)

IRPerformance's Avatar

Join Date: Apr 2003
Location: NJ
Posts: 11,012
Received 56 Likes on 48 Posts
Depends on the ecu, quality of your tune, and perception of a good idle. The main problem is idle and cruising afrs are less than ideal. Best budget upgrade is the Full Function FD step up kit. Keep the stock primaries, install a new pulsation damper, and add the secondary rail, injectors of your choice, and regulator. You can even make it fit with all the sequential and emissions junk if you get the 34mm height rail.
__________________
http://irperformance.com
Engine builds, single turbo kits, parts sales, performance upgrades, maintenance, tuning
732-662-1794 [email protected]
Brand new Mazda oem 13brew motors available. $4699 NO CORE FEE. VERY LIMITED. Check out our new turbo kits http://www.irperformance.com/product...zda/rx7/turbo/
IRPerformance is offline
