Help!!!! Injectors not firing!!!!
So, no start, narrowed it down to where I can see that no fuel is coming out of primary injectors. Please help troubleshooting!!!! Thanks.
#3
Moderator
iTrader: (7)
I've taken a long set of wires and tested each injector from the ECU to the ground end of the harness. I touched the wires to a 9v battery to fire the injector.
Naturally the injector rail must be lifted above a catch cup to see if fuel is released. Also keep the 9v battery well away from the fuel.
Also check continuity of the wiring from injector to ECU and injector to ground.
Naturally the injector rail must be lifted above a catch cup to see if fuel is released. Also keep the 9v battery well away from the fuel.
Also check continuity of the wiring from injector to ECU and injector to ground.
#6
Junior Member
Thread Starter
iTrader: (1)
Join Date: Jul 2012
Location: San Diego
Posts: 23
Likes: 0
Received 0 Likes
on
0 Posts
I was able to fire up the primaries by direct 9vdc on it and it fired up after few tries. When I was installing the wires back, I was still on ACC and noticed that the resistor were clicking the injector. I think I lnow the culprit, but will take few days until the parts get here. Did anybody experienced this before? Thanks, Jack.
