Boost issue
Hi guys, my series 8 makes full boost on both turbos perfectly, but I have an issue where if I'm WOT on full boost and then I let my foot off the throttle for a split second (eg loss of traction) and then put my foot back down to WOT again, I completely lose all boost. Is this likely a solenoid problem, and if so which would be the culprit?
Thanks
Thanks
#2
Rotary Enthusiast
Hi guys, my series 8 makes full boost on both turbos perfectly, but I have an issue where if I'm WOT on full boost and then I let my foot off the throttle for a split second (eg loss of traction) and then put my foot back down to WOT again, I completely lose all boost. Is this likely a solenoid problem, and if so which would be the culprit?
Thanks
Thanks
#3
Lives on the Forum
iTrader: (26)
What do you mean by WOT?
When an FD floods, deflooding procedure includes putting the accelerator to the floor * and cranking.
* This supposedly cuts of the fuel flow.
I don't know if that would be the case when the car is actually running.
In any event, time to "run codes" (if you still have stock ecu).
When an FD floods, deflooding procedure includes putting the accelerator to the floor * and cranking.
* This supposedly cuts of the fuel flow.
I don't know if that would be the case when the car is actually running.
In any event, time to "run codes" (if you still have stock ecu).
#6
Senior Member
iTrader: (16)
It’s probably a sticking turbo control solenoid. They’ve been known to act like that. Give this thread a read.
https://www.rx7club.com/3rd-generati...ctive-1120259/
Being a series 8 with the black box, you will have to replace the whole assembly or split the box and replace just that solenoid. There’s a few write ups on how to do that here. You’ll have to search a little bit to find how others did it.
~ GW
https://www.rx7club.com/3rd-generati...ctive-1120259/
Being a series 8 with the black box, you will have to replace the whole assembly or split the box and replace just that solenoid. There’s a few write ups on how to do that here. You’ll have to search a little bit to find how others did it.
~ GW
The following users liked this post:
mikey13b (01-29-24)
Trending Topics
#8
Full Member
Thread Starter
Are you saying it won't build boost again after getting back on the throttle? If so then yes it could be solenoid along with a bunch of other issues with the sequential control system. Do some testing to see if this is only during secondary operation or with both turbos just by letting off the throttle and getting back on when the primary and secondary.
#9
Full Member
Thread Starter
What do you mean by WOT?
When an FD floods, deflooding procedure includes putting the accelerator to the floor * and cranking.
* This supposedly cuts of the fuel flow.
I don't know if that would be the case when the car is actually running.
In any event, time to "run codes" (if you still have stock ecu).
When an FD floods, deflooding procedure includes putting the accelerator to the floor * and cranking.
* This supposedly cuts of the fuel flow.
I don't know if that would be the case when the car is actually running.
In any event, time to "run codes" (if you still have stock ecu).
#11
Full Member
Thread Starter
It’s probably a sticking turbo control solenoid. They’ve been known to act like that. Give this thread a read.
https://www.rx7club.com/3rd-generati...ctive-1120259/
Being a series 8 with the black box, you will have to replace the whole assembly or split the box and replace just that solenoid. There’s a few write ups on how to do that here. You’ll have to search a little bit to find how others did it.
~ GW
https://www.rx7club.com/3rd-generati...ctive-1120259/
Being a series 8 with the black box, you will have to replace the whole assembly or split the box and replace just that solenoid. There’s a few write ups on how to do that here. You’ll have to search a little bit to find how others did it.
~ GW
#12
Senior Member
iTrader: (16)
Thanks that thread does sound very similar to what im experiencing, so it looks sticky solenoid is probably it. Yep ive replaced my charge control solenoid in the black box before so I’ll be ok with that. There are 2 turbo control solenoids, one in the black box and one connected to the acv, do you think both need changing or is just one the likely culprit?
I’ve actually never tinkered with the S8 black box and did not realize the solenoid mounted on the acv was not relocated into the assembly. The us cars got the rats nest of spaghetti.
In my experience it was the one in the rats nest labeled “E” in the vac diagrams here >
https://www.rx7club.com/3rd-generati...2/#post8113663
Solenoid “E” works in tandem with the vacuum one mounted on the acv. I wish there was a rhyme or reason to why some work and why others stick. Some have said it’s due to running higher boost than they were designed to ( factory 10 psi ) others with completely stock cars have suffered from it. My personal opinion is that it was a short cut for the designers to just convert the vacuum solenoid design over to be used with pressure rather then redesign something new, specific for that circuit. I feel as if it lacks the correct internal spring pressure required to overcome the force applied, but I digress.
Also, just to note. Adaptronic has made a name for itself with high failure rate. Just keep an eye out as support for that ecu is discontinued.
~ GW
The following users liked this post:
mikey13b (01-29-24)
#13
Full Member
Thread Starter
I’ve actually never tinkered with the S8 black box and did not realize the solenoid mounted on the acv was not relocated into the assembly. The us cars got the rats nest of spaghetti.
In my experience it was the one in the rats nest labeled “E” in the vac diagrams here >
https://www.rx7club.com/3rd-generati...2/#post8113663
Solenoid “E” works in tandem with the vacuum one mounted on the acv. I wish there was a rhyme or reason to why some work and why others stick. Some have said it’s due to running higher boost than they were designed to ( factory 10 psi ) others with completely stock cars have suffered from it. My personal opinion is that it was a short cut for the designers to just convert the vacuum solenoid design over to be used with pressure rather then redesign something new, specific for that circuit. I feel as if it lacks the correct internal spring pressure required to overcome the force applied, but I digress.
Also, just to note. Adaptronic has made a name for itself with high failure rate. Just keep an eye out as support for that ecu is discontinued.
~ GW
In my experience it was the one in the rats nest labeled “E” in the vac diagrams here >
https://www.rx7club.com/3rd-generati...2/#post8113663
Solenoid “E” works in tandem with the vacuum one mounted on the acv. I wish there was a rhyme or reason to why some work and why others stick. Some have said it’s due to running higher boost than they were designed to ( factory 10 psi ) others with completely stock cars have suffered from it. My personal opinion is that it was a short cut for the designers to just convert the vacuum solenoid design over to be used with pressure rather then redesign something new, specific for that circuit. I feel as if it lacks the correct internal spring pressure required to overcome the force applied, but I digress.
Also, just to note. Adaptronic has made a name for itself with high failure rate. Just keep an eye out as support for that ecu is discontinued.
~ GW
Btw my adaptronic has been great, I've had it since it first got released (its the 2nd version) and cant fault it apart from a lose wideband connection which they soldered up and hasnt been an issue since, but thanks for the heads up, I hadnt heard any bad reports before.
