xxpezzxx

what is the torque on the fat *** nut?

boosted1205

iTrader: (9)

It's about 90-95 lbs.
Use some Loc-tite on the threads

xxpezzxx

thanx the book dosent say and i did a search but nothing only how to get the thing off that was fun.

Project84

No, its way more then 90-95lbs. Its 290-360 ft-lbs. And thats according to the Mazda factory service manual.

boosted1205

iTrader: (9)

What?? Eccentric Shaft Bolt. Not Flywheel Nut.

boosted1205

iTrader: (9)

Just curious, why are you asking? If you are planning on removing the bolt to change the thermo pellet, you need to take a little precaution. Anyway, just wondering.

Project84

He said fat *** nut!

J-Rat

iTrader: (2)

NEGATIVE~!

The E-shaft is approx 90-100 Ft Lbs.

The only reason its so hard to get off, is the sheer amount of lock-tite used on it.

Jarrett

fong

iTrader: (77)

so, which is right? someone told me that is about over 300 ft/lb. I even broke my ratch while using extension bar. damn it

boosted1205

iTrader: (9)

E-shaft bolt (19mm) is about 90-95-100 lbs. (take your choice)
Flywheel nut (2 5/8") 290-350 lbs. (bitch to take off)

fong

iTrader: (77)

I got my flywheel and flywheel nut off, but having problem to take out the e-shaft bolt. usually, we can rotate the rotor with 19mm on e-shaft bolt, but I couldn't turn it at all, after few turns. I even broke my ratch. it seems like engine locked up or something?

weird

RETed

It's around 100ft-lb.
There is a LOT more threadlocker on the threads on this stupid bolt, thus you have a lot more trouble getting this stupid bolt off.&nbsp The Flywheels nut will have, maybe, 1/4" of thread with threadlocker; the e-shaft bolt has like over an inch covered with threadlocker.


-Ted

adamlewis

From the S5 FSM

88IntegraLS

350 foot pounds. Basically a 175 pound man standing on the end of a two foot flywheel nut wrench.

Mr. Gadget

and whats the calculation for a 300 lb man....

boosted1205

iTrader: (9)

In my case, have whoever is at home and have them stand on the engine stand while you put your weight on the extension bar. An impact does *NOT* work unless you have one of those 500ft lbs woozies.

88IntegraLS

A 300 pound man would need to stand 1.16 feet away from the center of the flywheel nut wrench for 350 foot pounds torque on the nut.
