I blew the engine in my FC almost a year and a half ago. I've been saving up money ever since then to get it running again. I could have started it up again soon after blowing the engine, but i wanted to get quite a lump sum of money together so i could do something crazy and do everything at the same time.

Now the time has come and I've been toying with the idea of a 20b. One of the biggest questions that I have is, where do you get parts for the engine. little things such as an oil pan gasket or intake manifold gasket? Where do you guys buy your small regular maintenance items that are 20b specific?

Thanks,
Jonathan



i personaly dont like to use oil-pan gaskets , they tend to leak , i usually use that grey gasket maker stuff ,worked great so far.
Intake gasket , ....when all else fails ...make youre own
Other little maintenance stuff....oil filter,use same as 13B, fuel filter ,.depends on youre setup
Just think of the 20B as a larger 13B , a lot of things are interchangable



Yep. Also rx7.com has gaskets for these, but like felix says, its easier and cheaper to make your own.



Ebay has intake gaskets now for $40.00
So far Ebay seems to be the best place to find any 20B parts



They are the same source

Mazdaspeed has all the spare parts you'll need for the 20b with the exception of the e-shaft, and for now, the sought after thick intermediate housing. Mazdaspeed will be offering these again VERY soon for the low price of $2400.

By far the best sealeant I have used is HondaBond available from any Honda dealer. This goop blows away anything P-Tex makes.



The black market.



At $2400 its almost cheaper to just CNC mill one out of billit steel.



Have at it



What about aluminum? Might as well make it lighter in the process.



Does racing beat offer the center plate in aluminum?



Then you'd have to plate the sides.

No



http://www.xtremerotaries.com/

These guys had a very trick aluminum center iron at PRI. No price given yet. I'm sure it will be spendy but at $2400 for a stock piece it'd be worth a look.



Wow! That's awesome! I was wondering when or if anyone would ever make an aluminum center iron...



this might not have anything to do with the subject of conversation but i have a 20b automatic transmission with less than 50k miles on it. willing to let it go for cheap. well...it does have some relevance when i think about it. Anyway, im also in the middle of a 20b swap into an fc though. i have a bent throttle body that i dont know what to do with and is hampering my progress. anyway, good luck to you man.



Is the thermal expansion of the aluminum plate vastly different than that of the stock plate?



Yes



NOOB here, Quick question on the center irons.... the one iron is the same as the 13b and the other where can it be found if it can be found and what is it actual name. i cant search it if i dont know what it is. Thanks



From Mazda:
Intermediate Housing (1st Thick)
Part Number NF01-10-D50D

From Mazdatrix:
Side Housing, Second
Part Number 10-D50Y-N3H1-01
http://www.mazdatrix.com/3rotor.htm

From Atkins:
20B Thick Center Cast Iron
SKU NF01-10-D50D/N3H1-10-D50Y-01
http://www.atkinsrotary.com/store/pr...2&bestseller=Y

From Turbosmart:
20B Center Plate
Part Number: TS-9801-1002
http://www.turbosmartonline.com/index.php?id=283



Much appriciated thanks a bunch


...i see where all the cost comes from...



Everyone knows I have something going on in my garage.. I confess to have created the first wooden center plate w/ plastic nitrated surface for the 20B engines! Details to follow...



Turbosmart now offer the centre plate in billet. Anyone heard news about these?



Nope, never heard of it. How much food can it hold?



I think it's the new belt-drive model. 2liter model probably.



Hi, I'm new to this forum business so I hope this post comes out right.

I have a FULL set of brand new genuine Mazda plates and housings for a 20B still in their boxes, a brand new block if you will.
I am looking at expressions of interest, I would nearly go as far to say this is the only full set for sale anywhere?

Does anyone have any thoughts as to what this may be worth?

Thanks for reading my post.
