stickmantijuana

iTrader: (1)

I can't wait to hear how it sounds!

patman

iTrader: (3)

not a fan of the wastegate placement, but otherwise looks real nice.

Post some pics of it in the car once you get it bolted up.

John Huijben

iTrader: (1)

What's wrong with the wastegate placement? Doesn't look so bad to me, nice work!

cardmarc

Who did your welding work for this 3 rotor manifold. I have a SS one that needs some mods.....
Marc

Gorilla RE

iTrader: (1)

Aside from putting the wastegate on the turbine housing, the location he currently has it placed in is the best one possible on that setup.

-J

Turblown

iTrader: (12)

That design is very nice! One of the best I've seen on here...

patman

iTrader: (3)

The wastegate outlet in that location interrupts flow to the turbine, which will cause lag and later spool. While it is important to ensure adequate flow to the wastegate to avoid boost creep, it is not worth sacrificing a clear flow path to the turbine, unless it has to be there for packaging reasons.

Not trying to be critical of your design, it will work just fine, and the increase in lag and later spool will likely be so minor you won't notice.

olyrx7

iTrader: (3)

Great looking manifold!

RedDream

iTrader: (1)

Hey stick, just wanted to know if you fabricated this manifold since I saw on the 8club you bought your welder.. nice work on it bro the placement for everything looks sick keep us posted on how it turned out

diabolical1

iTrader: (3)

i very much like the design as well.
