81 fb rx7 rats nest question
So I had a previous post about my car starting revving up to 4000 then dying. So I decided to put my rats nest back on however I can't find a diagram anywhere that matches my rats nest 80 and earlier have 4 solenoids 85 has 6 but mine has 5. Harness has orange yellow blue grey and white but no brown plug. I'm uploaded pics of my rats nest to see if anyone can point me to what goes where most of its hooked up still minus a few vacuum lines. Any help would be awesome as I want to get it back to stick to just enjoy driving it.
Last edited by Thomas Fitzgerald; 04-17-16 at 11:21 PM. Reason: Adding pics
#2
Out In the Barn
iTrader: (9)
Check out the 1981 wiring diagram. It shows 5.
http://www.foxed.ca/rx7manual/manual...ingDiagram.pdf
http://www.foxed.ca/rx7manual/manual...ingDiagram.pdf
#4
Out In the Barn
iTrader: (9)
Because foxed.ca does not have the 1981 or 1982 factory service manuals, this is the best I could find. Page 66.
http://foxed.ca/rx7manual/manuals/19...ing_manual.pdf
On a side note, I really respect a novice that does a little research. Foxed.ca is a good place to start.
http://foxed.ca/rx7manual/manuals/19...ing_manual.pdf
On a side note, I really respect a novice that does a little research. Foxed.ca is a good place to start.
