2port S5 rack to ford 302 pump.Problem.

Reply



Old 09-19-16, 07:42 PM
  #1
*MODERATOR*
Thread Starter
iTrader: (142)

misterstyx69's Avatar

Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,438
Thanks: 0
Thanked 33 Times in 31 Posts
2port S5 rack to ford 302 pump.Problem.

I think I may have the lines mixed up as the steering will snap to the right when I try to turn the wheel.
Can I get PICS of the S5 rack outlets and their corresponding hoses?
OR can someone who has hooked up a Ford 302 pump to a 2 port rack tell me where the heck the hoses connect?..
THANKS GENTS!
STYX!~
misterstyx69 is online now
Reply With Quote
Old 09-20-16, 06:09 PM
  #2
Lacks Ample Funds
iTrader: (1)

ACR_RX-7's Avatar

Join Date: May 2014
Location: PNW
Posts: 934
Thanked 4 Times in 3 Posts
You do have it hooked up backwards. I don't have a pick, but I remember years ago when I was in tech school we hooked up a rack backwards and it did the exact same thing.
ACR_RX-7 is offline
Reply With Quote
Old 09-20-16, 11:54 PM
  #3
*MODERATOR*
Thread Starter
iTrader: (142)

misterstyx69's Avatar

Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,438
Thanks: 0
Thanked 33 Times in 31 Posts
Never assume that the parts you get are what you need!

The Hose that was with the car had the connections and I attached them and THIS was what I got..Wham..

SO,I forage the country side for someone to make a Frakkin line..Can I get a Hydraulic line done by a Hydraulic PLACE?..NO...What the Living Buzzard is up with that???

So..snowplows have hydraulics and YES we are Canadian and have....YES.....places that repair plows.
I am getting a line done tomorrow and the "other line"?...gonna chop it and use it as Return since it no longer needs the special doo-dad on it!
misterstyx69 is online now
Reply With Quote
Old 09-21-16, 07:08 PM
  #4
*MODERATOR*
Thread Starter
iTrader: (142)

misterstyx69's Avatar

Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,438
Thanks: 0
Thanked 33 Times in 31 Posts
YEP..it was the lines.

Future TECH INFO on 2 port Rack:
the HIGH pressure is the port that is Closest to the TOP of the rack at the Steering shaft and has the "straight line" in the port.(17mm wrench takes the line off the rack)
The LO pressure has the Horseshoe shaped pipe and 19mm banjo bolt on it.
misterstyx69 is online now
Reply With Quote
Old 10-27-16, 07:45 AM
  #5
*MODERATOR*
Thread Starter
iTrader: (142)

misterstyx69's Avatar

Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,438
Thanks: 0
Thanked 33 Times in 31 Posts
Just a Little Update:
If this happens..Check for LEAKS!

The slamming of the wheel to one side caused the input shaft seal to get squished and it eventually failed and blew fluid out of the steering rack!
Good news is that you can change the seal while the rack is in the car..(my case anyways..)
Bad News is to try and get the Seal Kit...In Canada..within 2 weeks...before the snow flies!
misterstyx69 is online now
Reply With Quote
Old 03-07-17, 01:08 PM
  #6
Can Post Only in New Member Section

Join Date: Jan 2015
Location: lincoln ne
Posts: 2
Thanks: 0
Thanked 0 Times in 0 Posts
not so

Originally Posted by misterstyx69 View Post
YEP..it was the lines.

Future TECH INFO on 2 port Rack:
the HIGH pressure is the port that is Closest to the TOP of the rack at the Steering shaft and has the "straight line" in the port.(17mm wrench takes the line off the rack)
The LO pressure has the Horseshoe shaped pipe and 19mm banjo bolt on it.
you may have that backwards
swampdog is offline
Reply With Quote
Old 04-14-17, 07:00 AM
  #7
*MODERATOR*
Thread Starter
iTrader: (142)

misterstyx69's Avatar

Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,438
Thanks: 0
Thanked 33 Times in 31 Posts
..I Fixed this ..

I went MANUAL.

If you ever try to swap a rack out on a Cradled 302 in an FC ..you will know why!
misterstyx69 is online now
Reply With Quote
Old 04-14-17, 07:12 AM
  #8
Rotary Enthusiast
iTrader: (8)

DC5Daniel's Avatar

Join Date: Jul 2012
Location: GA
Posts: 1,229
Thanks: 0
Thanked 1 Time in 1 Post
Originally Posted by misterstyx69
..I Fixed this ..

I went MANUAL.

If you ever try to swap a rack out on a Cradled 302 in an FC ..you will know why!
Way to be a man!

2port S5 rack to ford 302 pump.Problem.-photo975.jpg
DC5Daniel is offline
Reply With Quote
Old 04-14-17, 07:42 AM
  #9
*MODERATOR*
Thread Starter
iTrader: (142)

misterstyx69's Avatar

Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,438
Thanks: 0
Thanked 33 Times in 31 Posts
Originally Posted by DC5Daniel View Post
Way to be a man!

Attachment 596599
Well..If I was a woman I would never get out of the house..
I'd be too busy playin with my Boobies..hahhahha!
misterstyx69 is online now
Reply With Quote
Old 09-16-17, 12:15 AM
  #10
*MODERATOR*
Thread Starter
iTrader: (142)

misterstyx69's Avatar

Join Date: Sep 2005
Location: Smiths Falls.(near Ottawa!.Mapquest IT!)
Posts: 25,438
Thanks: 0
Thanked 33 Times in 31 Posts
UPDATE!...well my hands are getting a work out ..(I'm either using manual steering or playin with my *****!).
I still don't like the manual steering so I am going to look back at that option Again.I didn't really want it But I settled for it to get the car on the road..which I did.(drove it again today..Yay!)
I like the car,the sound,the paint,the Audio system..the only thing is you can't Give it **** and be fully confident that you have total control of the car.It just seems like you have to work the steering..
I wanna be able to Stab the gas pedal to the Floor and comfortably handle the car.
I fully believe that going to the Power steering setup will make this thing a Real FUN toy!

Anyways,not doing it this season..Summer was **** and it's almost over,so I am gonna drive it while I can.
Cheers Guys.
