Opinions of race clearancing rotors??
Yo folks,
I am building a new engine for my ITS car, i shift at a conservative 8,000 rpm and and wondering what you feel is the need for me to have the rotors clearenced. here is a link to the racing beat website that describes the process if you are unframiliar.
http://www.racingbeat.com/FRmazda2.htm
Is this needed and worth it???? Thanks ladies and gents, I appericiate the help!
I am building a new engine for my ITS car, i shift at a conservative 8,000 rpm and and wondering what you feel is the need for me to have the rotors clearenced. here is a link to the racing beat website that describes the process if you are unframiliar.
http://www.racingbeat.com/FRmazda2.htm
Is this needed and worth it???? Thanks ladies and gents, I appericiate the help!
#2
Banned. I got OWNED!!!
Their use of frames makes that link not point to anything correct (unless I just missed it) but I run max clearance on all my 12A race engines. According to a Mazda race manual of some sort, of which a .pdf has floated around the forum before, the hot trick is a "conical" clearance for lack of a better term.
#4
Senior Member
Thread Starter
iTrader: (1)
Join Date: Oct 2006
Location: wisconsin
Posts: 519
Likes: 0
Received 0 Likes
on
0 Posts
i dont think its a legallity issue. All that the process is is removing material from the side of the rotor to prevent it from slapping into the iron at high rpm...I only **** at 8 though. So I am leaning twords it being not needed.
#5
Gen 2 Raced Hard NA 13B
Join Date: Apr 2006
Location: Canada
Posts: 272
Likes: 0
Received 0 Likes
on
0 Posts
Don't Worry
Hi There,
I just put my fresh engine in my race car last week. 13b street port, stock 1990 rotors, stock bearings. Clearances I ran last year.0025” on the rotors and mains. Ran for 40 hours at 9000 RPM pulls in 2nd and 8700Rpm in 3rd and 4th gears. Oil temp coming out of the engine before cooling it down was 250 to 265 Deg. Oil pressure was 120 PSI (Stock Turbo oil pump). I measured my clearances after last season no **** .0025” on both. The shaft had some visual marking but nothing that could be measured. About 15 minutes on the lathe with 2000 grid wet sand and they cleaned up no problems. One thing that did stand out was the stock apex seal (2mm thick) wear. Total lost on them on hight was (All the same) .0200” after 40hrs. It seam I will be replacing the stock apex seals every two years.
I run a Mega Squirt fuel, ignition program and pull at the rear wheels in 4th gear with 4:11 Gears, 225/50 R15 Ra 1 Toyo tires 180HP at 8400 RPM and 110LB @ 7500RPM.
Best part about my rebuild after one full season of racing, One O-Ring set, two seals, one set of apex spring long and short, one timing cover gasket. Resurfaced end and center sections (New at the start wear about .0030” to .0050”). Total cost $700.00USD. for rebuild my time about 20 hours. Cheap!
Race Hard and Safe.
I just put my fresh engine in my race car last week. 13b street port, stock 1990 rotors, stock bearings. Clearances I ran last year.0025” on the rotors and mains. Ran for 40 hours at 9000 RPM pulls in 2nd and 8700Rpm in 3rd and 4th gears. Oil temp coming out of the engine before cooling it down was 250 to 265 Deg. Oil pressure was 120 PSI (Stock Turbo oil pump). I measured my clearances after last season no **** .0025” on both. The shaft had some visual marking but nothing that could be measured. About 15 minutes on the lathe with 2000 grid wet sand and they cleaned up no problems. One thing that did stand out was the stock apex seal (2mm thick) wear. Total lost on them on hight was (All the same) .0200” after 40hrs. It seam I will be replacing the stock apex seals every two years.
I run a Mega Squirt fuel, ignition program and pull at the rear wheels in 4th gear with 4:11 Gears, 225/50 R15 Ra 1 Toyo tires 180HP at 8400 RPM and 110LB @ 7500RPM.
Best part about my rebuild after one full season of racing, One O-Ring set, two seals, one set of apex spring long and short, one timing cover gasket. Resurfaced end and center sections (New at the start wear about .0030” to .0050”). Total cost $700.00USD. for rebuild my time about 20 hours. Cheap!
Race Hard and Safe.
#7
Eats, Sleeps, Dreams Rotary
iTrader: (1)
the modern (86+ 13b) rotors are clearanced fairly well from the factory.
theres a 50/50 chance that you may not need to even touch the rotor.
stock assembly is good for a constant 8500rpm assbeating, if not more
I would suggest having your rotating assembly balanced though, as this can be improved upon quite a bit from the factory. Rotaries don't have a whole lot of rotating parts so the factory can get away with some sloppy balancing and still have everything happy.
Happy Rotoring,
Ben Martin
theres a 50/50 chance that you may not need to even touch the rotor.
stock assembly is good for a constant 8500rpm assbeating, if not more
I would suggest having your rotating assembly balanced though, as this can be improved upon quite a bit from the factory. Rotaries don't have a whole lot of rotating parts so the factory can get away with some sloppy balancing and still have everything happy.
Happy Rotoring,
Ben Martin
Trending Topics
#8
Rotary Freak
"I just put my fresh engine in my race car last week. 13b street port, stock 1990 rotors, stock bearings. Clearances I ran last year.0025” on the rotors and mains. Ran for 40 hours at 9000 RPM pulls in 2nd and 8700Rpm in 3rd and 4th gears. Oil temp coming out of the engine before cooling it down was 250 to 265 Deg. Oil pressure was 120 PSI (Stock Turbo oil pump). I measured my clearances after last season no **** .0025” on both. The shaft had some visual marking but nothing that could be measured. About 15 minutes on the lathe with 2000 grid wet sand and they cleaned up no problems. One thing that did stand out was the stock apex seal (2mm thick) wear. Total lost on them on hight was (All the same) .0200” after 40hrs. It seam I will be replacing the stock apex seals every two years.
I run a Mega Squirt fuel, ignition program and pull at the rear wheels in 4th gear with 4:11 Gears, 225/50 R15 Ra 1 Toyo tires 180HP at 8400 RPM and 110LB @ 7500RPM."
Heavens to Betsy SCCA RX7 Racer, your setup is very familiar to me including shift points, tire sizes and everything. Differences to my set up asre that I was running a Holley 4 barrel/ Racing Beat manifold intake and a cobbled together stock S4 ecu set up. Got you a bit on power though. I got 185 rwhp at 8500 and 134 ft lbs at 6500 rpm. The carb/ ignition set up was not optimized at all, just something I could put on the motor and finish out the season with a new motor.
Going to convert to my Megasquirt/ ITB setup this winter and see where the power ends up, LOL.
On a side note, I have done a bit of racing out west (as a co-driver in the Brown Bros. Cobra R) and wondered what your times are at Portland. Just trying to get a feel for comparitive times for my car at that track. Just a shot of me at Mosport holding off a factory supported Saab 9-3 Turbo and a Golf with a VR6 and sequential style gearbox. We ran this close for over 2 hours.
Regards,
Eric Nummelin
I run a Mega Squirt fuel, ignition program and pull at the rear wheels in 4th gear with 4:11 Gears, 225/50 R15 Ra 1 Toyo tires 180HP at 8400 RPM and 110LB @ 7500RPM."
Heavens to Betsy SCCA RX7 Racer, your setup is very familiar to me including shift points, tire sizes and everything. Differences to my set up asre that I was running a Holley 4 barrel/ Racing Beat manifold intake and a cobbled together stock S4 ecu set up. Got you a bit on power though. I got 185 rwhp at 8500 and 134 ft lbs at 6500 rpm. The carb/ ignition set up was not optimized at all, just something I could put on the motor and finish out the season with a new motor.
Going to convert to my Megasquirt/ ITB setup this winter and see where the power ends up, LOL.
On a side note, I have done a bit of racing out west (as a co-driver in the Brown Bros. Cobra R) and wondered what your times are at Portland. Just trying to get a feel for comparitive times for my car at that track. Just a shot of me at Mosport holding off a factory supported Saab 9-3 Turbo and a Golf with a VR6 and sequential style gearbox. We ran this close for over 2 hours.
Regards,
Eric Nummelin
#9
Gen 2 Raced Hard NA 13B
Join Date: Apr 2006
Location: Canada
Posts: 272
Likes: 0
Received 0 Likes
on
0 Posts
Portland International Raceway
Sanction ICSCC PORTLAND INTERNATIONAL RACEWAY Last Race Sept 24th Weekend I Ran RS Class and the SPM Class just for fun
726 BC Mazda RX7 Red/Yellow 21 10 SCCBC CACC CANUSA Equipment Ltd Time:1:30.711 with the chicane.
I just modified a Gen one pinion gear on to my Gen two pinion shaft so I can run 4:88 gears. Also changed to a thicker cross flow rad. These will be the only changes to my car for this season coming up.
I think I met the Brow Bros. Ford guy. It's his son that runs and not the old man if I'm right.
726 BC Mazda RX7 Red/Yellow 21 10 SCCBC CACC CANUSA Equipment Ltd Time:1:30.711 with the chicane.
I just modified a Gen one pinion gear on to my Gen two pinion shaft so I can run 4:88 gears. Also changed to a thicker cross flow rad. These will be the only changes to my car for this season coming up.
I think I met the Brow Bros. Ford guy. It's his son that runs and not the old man if I'm right.
#10
Rotary Freak
Thats pretty quick using the Festival chicane. Gives me a good idea where I would be, if I ever make the tow LOL.
THe BRown Bros. car is owned and run by Tim Brown. His dad hasn't been out to a race in over 20 years. More than likely you were talking to Don, one of the crew guys who acts like Tim's dad.
Anyway sounds like you have the car running great! I travel to Vancouver about once every couple of months and we should get together and swap war stories, etc....
Thanks,
Eric
THe BRown Bros. car is owned and run by Tim Brown. His dad hasn't been out to a race in over 20 years. More than likely you were talking to Don, one of the crew guys who acts like Tim's dad.
Anyway sounds like you have the car running great! I travel to Vancouver about once every couple of months and we should get together and swap war stories, etc....
Thanks,
Eric
#11
Gen 2 Raced Hard NA 13B
Join Date: Apr 2006
Location: Canada
Posts: 272
Likes: 0
Received 0 Likes
on
0 Posts
I think I can get 5 to 10 more HP Cost $15/ 25 Hours Labour
Originally Posted by RICE RACING
^ what intake manifold you running? Thats some high revs for a NA street port (both peak power and tq)
