Race Car Tech Discuss anything related to road racing and auto X.

FC wheel offset

Old 10-02-12, 02:31 PM
  #1
Senior Member
5 Year Member
Thread Starter

wlfpkrcn's Avatar

Join Date: Jul 2005
Location: CA
Posts: 305
Likes: 0
Received 0 Likes on 0 Posts
FC wheel offset

What kind of offset are you guys running with 8" or 9" wheels. I don't want to add flares if I don't need to.

Thanks
E
wlfpkrcn is offline
Old 10-02-12, 03:26 PM
  #2
Isn't really a professor
iTrader: (1)

Join Date: Feb 2011
Location: Los Angeles
Posts: 72
Likes: 0
Received 0 Likes on 0 Posts
I've got Keizer 15x8 wheels with 5.25" backspace. In the front I have to run a 1/4" spacer so the 225s clear the coilovers.


Last edited by Prof. Chaos; 10-02-12 at 03:31 PM.
Prof. Chaos is offline
Old 10-03-12, 11:40 AM
  #3
Let's get silly...
iTrader: (7)

RockLobster's Avatar

Join Date: May 2004
Location: Rosemount, MN
Posts: 1,703
Likes: 0
Received 3 Likes on 3 Posts
+40 with a 20mm spacer all around 8.5" rims. VERY Mild baseball bat flare in the front just rolled the lip in the rear.

my street car runs 8" rims at +25, no flare, just rolled lips.
RockLobster is offline
Old 10-03-12, 08:49 PM
  #4
Living on the North Coast
iTrader: (30)

DeaconBlue's Avatar

Join Date: Mar 2009
Location: Avon Lake
Posts: 602
Received 4 Likes on 4 Posts
I run 225/45-17 tires on a 8.5" wide 42mm offset rims front and rear. In the front I have a 17mm spacer/adapter and rolled lips. In the rear I have a 22mm spacer/adapter and stock lips. This is with stock style struts/shocks - I have not yet installed the coil-overs.
DeaconBlue is offline
Old 10-04-12, 03:03 PM
  #5
Let's get silly...
iTrader: (7)

RockLobster's Avatar

Join Date: May 2004
Location: Rosemount, MN
Posts: 1,703
Likes: 0
Received 3 Likes on 3 Posts
I should mention i run 225 or 235 tires depending on brand...
RockLobster is offline
Old 10-04-12, 03:07 PM
  #6
Senior Member
5 Year Member
Thread Starter

wlfpkrcn's Avatar

Join Date: Jul 2005
Location: CA
Posts: 305
Likes: 0
Received 0 Likes on 0 Posts
Thanks guys!

We currently run 225's on 15x7. Want to step up to and 8" or wider rim

Any suggestion on rims?
wlfpkrcn is offline
Old 10-04-12, 03:12 PM
  #7
Let's get silly...
iTrader: (7)

RockLobster's Avatar

Join Date: May 2004
Location: Rosemount, MN
Posts: 1,703
Likes: 0
Received 3 Likes on 3 Posts
finding a low offset 15x7" or 8" rim has been nearly impossible for me. There are used kosei's around but hard to find...ive been trying to get a price on some team dynamics pro race 1.2 in either an ET15 or ET20 but no luck as yet.

its easier in 17" to get a low offset bot not super easy, i have been running the 40ET RPF1 with the spaces simply because they are plentiful
RockLobster is offline
Old 10-04-12, 03:40 PM
  #8
Isn't really a professor
iTrader: (1)

Join Date: Feb 2011
Location: Los Angeles
Posts: 72
Likes: 0
Received 0 Likes on 0 Posts
I couldn't find any off the shelf 15x8s that fit under the stock fenders, so I wound up having wheels made. I went with Keizer, but any number of companies can do it. The trick is the amount of time it takes to get them. I cancelled orders with both Spin Werks and Jongbloed before ordering from Keizer -- the other companies were taking too long. And even with Keizer a while.
Prof. Chaos is offline
Old 10-04-12, 03:45 PM
  #9
Senior Member
5 Year Member
Thread Starter

wlfpkrcn's Avatar

Join Date: Jul 2005
Location: CA
Posts: 305
Likes: 0
Received 0 Likes on 0 Posts
MRW can make me steel 15x8 NASCAR style wheels at $70 each but 19lb the Ultra Stars

http://www.mrt-wheels.com/racingwheels.html
wlfpkrcn is offline
Old 10-05-12, 10:21 AM
  #10
Living on the North Coast
iTrader: (30)

DeaconBlue's Avatar

Join Date: Mar 2009
Location: Avon Lake
Posts: 602
Received 4 Likes on 4 Posts
Originally Posted by RockLobster View Post
finding a low offset 15x7" or 8" rim has been nearly impossible for me. There are used kosei's around but hard to find...ive been trying to get a price on some team dynamics pro race 1.2 in either an ET15 or ET20 but no luck as yet.

its easier in 17" to get a low offset bot not super easy, i have been running the 40ET RPF1 with the spaces simply because they are plentiful
I can put you in contact with a friend of mine that imports TD PR 1.2 rims. Send me a PM if you are still interested. I got a quote from him on 17 x 7.5" TD PR 1.2 with the correct offset for the FC RX7 before deciding to go with the wider and lighter weight 17 x 8.5" SSR type C rims (which required adapters).

I would also recommend 17" RPF1 because it would be much easier - just not sure if your chassis setup will work the same with a 17" as it does with the current 15" combo.
DeaconBlue is offline
Old 10-06-12, 11:39 AM
  #11
Senior Member
5 Year Member

gkmccready's Avatar

Join Date: Oct 2006
Location: SFBay
Posts: 321
Likes: 0
Received 1 Like on 1 Post
Originally Posted by wlfpkrcn View Post
MRW can make me steel 15x8 NASCAR style wheels at $70 each but 19lb the Ultra Stars

MRW Racing Wheels buy MRW
Diamond Racing Wheels will also build them, I think for about the same price.
gkmccready is offline
Old 11-26-12, 02:00 PM
  #12
Let's get silly...
iTrader: (7)

RockLobster's Avatar

Join Date: May 2004
Location: Rosemount, MN
Posts: 1,703
Likes: 0
Received 3 Likes on 3 Posts
Steel is always an option. Not one i am crazy about, but cheap and easy to come by.
RockLobster is offline
Old 11-27-12, 11:25 PM
  #13
088
...Serf of Taxifornia...
iTrader: (9)

088's Avatar

Join Date: Jul 2006
Location: Haywards 5000
Posts: 376
Likes: 0
Received 7 Likes on 6 Posts
Originally Posted by RockLobster View Post
finding a low offset 15x7" or 8" rim has been nearly impossible for me. There are used kosei's around but hard to find...ive been trying to get a price on some team dynamics pro race 1.2 in either an ET15 or ET20 but no luck as yet.
Originally Posted by DeaconBlue View Post
I can put you in contact with a friend of mine that imports TD PR 1.2 rims. Send me a PM if you are still interested. I got a quote from him on 17 x 7.5" TD PR 1.2 with the correct offset for the FC RX7
I'll share my recent experience. Earlier this year, I spent a lot of time researching availability of low offset 15" wheels, off-the-shelf. The selection is very limited for the 5x114.3 bolt pattern. In the 7" width, the only choices (with <40 offset) are:

Panasport +0 offset
Spinwerks +0 offset
Team Dynamics +35 offset

I spent 2-3 months waiting on an order of Team Dynamics Pro Race 1.2, +23 offset, which they claimed were on the shelf somewhere in England. Ultimately they admitted they were NLA and no plans to make any. The Pro Race 2 is discontinued.

The Panasports and Spinwerks are > $200 each. The TD is $135.

(For 4x100, the selection is much better -- 15x8s and 15x9s can be found in that BP).

If you can run 17", I have 17x8 SSRs +40 offset, and 5Zigen FN01-RC 17x9s, +15 front, +35 rear. The +15s require the 20mm fiberglass fenders from Mazdatrix (or flares).
088 is offline
Old 11-28-12, 07:59 AM
  #14
SCCAEP
iTrader: (3)

SCCAITS's Avatar

Join Date: Dec 2006
Location: Dallas
Posts: 1,080
Likes: 0
Received 0 Likes on 0 Posts
Originally Posted by RockLobster View Post
team dynamics pro race 1.2 in either an ET15
Had to order mine and it took 2-3 months but was able to get 12 of them for $1800. They will make our pattern in an ET15 (lowest they can go) but you have to wait, normal production is ET35. Ask a local mechanic shop to order for you from TD. The shop I used is out of business but was just a local general repair shop, just need to be in the auto business somehow. Not sure on the markup but am guessing they did cost + 10 or 15% was all. My hookup at Discount Tire used to do the same before he stopped working there.
SCCAITS is offline
Old 11-28-12, 03:22 PM
  #15
Let's get silly...
iTrader: (7)

RockLobster's Avatar

Join Date: May 2004
Location: Rosemount, MN
Posts: 1,703
Likes: 0
Received 3 Likes on 3 Posts
I will probably end up going SSR and keeping my 20mm spacers if i switch to 15" rims. But, boy are they pricey for 15" race rims. They are only made in +42.
RockLobster is offline
