Haltech e6k wiring questions
#1
e6k wiring questions
Alright, wiring up the e6k and trying to make sense of the coil wiring. I've got my tps wired, 02 wired, trigger (stock fc cas) wired, gm map wired.
I have 6 wires left. I've searched for days about wiring diagrams lol I'd ice missed out I'm sorry.
wire colors
Blue/grn -
Dk grn -
Grn/blk -
Dk grn/blk -
White/blk -
Grey -
I've got 3 diagrams, but none of those Colors match. Any help would be appreciated Thank you
I have 6 wires left. I've searched for days about wiring diagrams lol I'd ice missed out I'm sorry.
wire colors
Blue/grn -
Dk grn -
Grn/blk -
Dk grn/blk -
White/blk -
Grey -
I've got 3 diagrams, but none of those Colors match. Any help would be appreciated Thank you
#2
Magic man
iTrader: (20)
Join Date: Nov 2010
Location: grants pass,oregon
Posts: 365
Likes: 0
Received 0 Likes
on
0 Posts
https://www.rx7club.com/showthread.p...235&styleid=20
This is how i hooked mine up.
Pin 36 on haltech= light green to green w/yellow stripe on body harness.
Pin 35 on haltech=white w/black stripe to blue w/yellow stripe on body harness.
Pin 27 on haltech=green w/black stripe to brown w/yellow stripe on body harness.
Haven't had any problems yet.
This is how i hooked mine up.
Pin 36 on haltech= light green to green w/yellow stripe on body harness.
Pin 35 on haltech=white w/black stripe to blue w/yellow stripe on body harness.
Pin 27 on haltech=green w/black stripe to brown w/yellow stripe on body harness.
Haven't had any problems yet.
#3
Haltech e6k wher to splice into for leading/trailing - RX7Club.com
This is how i hooked mine up.
Pin 36 on haltech= light green to green w/yellow stripe on body harness.
Pin 35 on haltech=white w/black stripe to blue w/yellow stripe on body harness.
Pin 27 on haltech=green w/black stripe to brown w/yellow stripe on body harness.
Haven't had any problems yet.
This is how i hooked mine up.
Pin 36 on haltech= light green to green w/yellow stripe on body harness.
Pin 35 on haltech=white w/black stripe to blue w/yellow stripe on body harness.
Pin 27 on haltech=green w/black stripe to brown w/yellow stripe on body harness.
Haven't had any problems yet.
#4
Well, got my car to fire. It ran and idled for about 5 mins. And then stumbled and died. Hasn't started since
Couple things I'm worried about
Map is for a s4 street ported turbo with 850cc injectors, my fc is a s5 bridge 6 port with 550cc.
I don't have my air temp sensor yet
Unable to check haltech yet with laptop. (Installing w98 onto my laptop lol)
Should be trying to get Windows installed tonight so I can try and connect.
Couple things I'm worried about
Map is for a s4 street ported turbo with 850cc injectors, my fc is a s5 bridge 6 port with 550cc.
I don't have my air temp sensor yet
Unable to check haltech yet with laptop. (Installing w98 onto my laptop lol)
Should be trying to get Windows installed tonight so I can try and connect.
