street porting a cermet b housings
i'm going to order the cermet b housings from jhb in the next few days and i have a few thoughts on them. i want my engine to be street ported so do you guys think its possible to port the cermet b housings or should they be ported then coated. because if you port them when theyre already coated there will be that area where its not covered anymore. am i wrong or is it possible.
#6
DGRR 2017 4/26-4/30, 2017
iTrader: (13)
I always wonder about this Cermet stuff.. So, isn't the coating couple of mm thick?? I've talked to someone who's an aerospace eng. and he said he has seen these things chip. I know there are few threads about this stuff, but I think if you are going to spend money on this coating, its better spend few more and get a new housing.
#7
Senior Member
Thread Starter
iTrader: (4)
Join Date: Sep 2003
Location: Los Angeles, CA
Posts: 473
Likes: 0
Received 0 Likes
on
0 Posts
yup herblenny i'm going for the new housings with cermet b option. as for the ceramic apex seals i emailed the jhb guy and he said that i should use ceramic apex seals to compensate for the hardness of the cermet b. as for porting i thought it would be fine but does anybody have any input who has already done this. thanks for your guys input
Trending Topics
#8
DGRR 2017 4/26-4/30, 2017
iTrader: (13)
Originally Posted by EjCabrera
yup herblenny i'm going for the new housings with cermet b option. as for the ceramic apex seals i emailed the jhb guy and he said that i should use ceramic apex seals to compensate for the hardness of the cermet b. as for porting i thought it would be fine but does anybody have any input who has already done this. thanks for your guys input
Its your choice but I think its a complete waste to get a new housing to be cermet'd.
By what I hear, they strip the steel insert for the housing and coats it.
And I can't see them like the oem ones..
I've also talked to Ianetti and asked about the ceramic seals.. He does not recommend his ceramic seals on street driven cars. That was quite surprising to me..
Its up to you, but there have been plenty of people making great power on stock seals and stock housings..
#9
Mr. Links
iTrader: (1)
Originally Posted by EjCabrera
as for porting i thought it would be fine but does anybody have any input who has already done this. thanks for your guys input
https://www.rx7club.com/rotary-car-performance-77/cermet-b-rotor-housings-regular-housings-552487/
Why not PM a few of them as ask them?
#10
Senior Member
Thread Starter
iTrader: (4)
Join Date: Sep 2003
Location: Los Angeles, CA
Posts: 473
Likes: 0
Received 0 Likes
on
0 Posts
thanks for you guys feedback. i also talked to mazdatrix and they had a bad experience with the cermet b and ceramic seals. i read around the forums and was persuaded to go the new housings then street port them and oem 2mm apex seal option.
#11
1.) I am considering this for some engine in the future. I talked to Mark @ JHB while at SS7 & 8, I also talked to him on the phone a couple of times. Very straight forward guy about what prices are, whats overkill for the street, etc.
He told me they remove .009 and if I bought new housings, he'd just be taking that nice new chrome surface off.
If ya send him housings that have .009 deep worth of gouging on the surface (or more), obviously he'll be machining it out smooth as a baby's butt in prep for the Cermet, but I don't know/remember what the maximum material removal allowed is (if you have deeper gouging > .009 in the housing..... like me that is!!! ;-) ).
2.) Talked to Jim at Moriah Motorsports and he swore by Ianettis. Wonder why the Ianetti guy nixed the street app for his ceramic seals.
3.) QUESTION : Anybody had experience with Swaintech thermal coatings on the rotor faces? Do you have to prep the rotors by covering up the apex groove or are they savvy enuf about rotary engines not to coat the inside of the groove?
He told me they remove .009 and if I bought new housings, he'd just be taking that nice new chrome surface off.
If ya send him housings that have .009 deep worth of gouging on the surface (or more), obviously he'll be machining it out smooth as a baby's butt in prep for the Cermet, but I don't know/remember what the maximum material removal allowed is (if you have deeper gouging > .009 in the housing..... like me that is!!! ;-) ).
2.) Talked to Jim at Moriah Motorsports and he swore by Ianettis. Wonder why the Ianetti guy nixed the street app for his ceramic seals.
3.) QUESTION : Anybody had experience with Swaintech thermal coatings on the rotor faces? Do you have to prep the rotors by covering up the apex groove or are they savvy enuf about rotary engines not to coat the inside of the groove?
Last edited by fdbabb; 06-26-06 at 02:26 AM. Reason: splellin airers
#12
Mr. Links
iTrader: (1)
Originally Posted by fdbabb
3.) QUESTION : Anybody had experience with Swaintech thermal coatings on the rotor faces? Do you have to prep the rotors by covering up the apex groove or are they savvy enuf about rotary engines not to coat the inside of the groove?
Thanks for writing. Rotors cost $150 per rotor to coat the faces with our TBC thermal barrier coating. Payment is either Visa, Mastercard or COD where you would need a money order.
The rotors should be clean and disassembled when we receive them. We take care of all the surface preparation from there. If there is just light carbon build up do not worry about doing additional cleaning. However if the build up is significant, you should get the carbon off before we get the parts to avoid extra cleaning charges. The typical turn time on rotors like that is about 2 1/2 weeks in our shop.
Richard
Swain Tech Coatings
The rotors should be clean and disassembled when we receive them. We take care of all the surface preparation from there. If there is just light carbon build up do not worry about doing additional cleaning. However if the build up is significant, you should get the carbon off before we get the parts to avoid extra cleaning charges. The typical turn time on rotors like that is about 2 1/2 weeks in our shop.
Richard
Swain Tech Coatings
