sonix7

anybody know anything about these mounts. are the better than stock or urathane? are they any good at all. who has experience with these motor mounts? Genuine MAZDASPEED Motorsports Rubber Motor Mount Set 93-95
Code: F128-39-040-050A. can be seen here
http://www.mazdaformance.com/rx7.htm. thanx

sonix7

what about the mazdacompetition mounts? MazdaCompetition Mounts for 93-95 Rx-7
Code: F128-SET. same site scroll down http://www.mazdaformance.com/rx7.htm. thanx

sonix7

look under mazdaspeed products.

sonix7

no one has ever used or heard of anybody that has these mounts? damn. I need some feedback so I can make a decision on this motor mount issue.

sonix7

well these must suck. I have never had a post where no one had nothing to say. I will take it for what its worth. last call on anything about these mounts. going, going......

Howard Coleman

iTrader: (6)

i recommend stock motormounts combined w Garfinkle's engine brace. the brace takes all of the torque off the mounts and power plant frame. do a search for garfinkle.

howard coleman

sonix7

that's what I was going to do in the first place, Howard. thanks for solidifying that for me. no Engine Torque Brace, right?

rotoboy661

rotaryextreme brace

garfinkl's brace is solid, gonna feel every vibration

get one with the dampener like rotaryextreme or FEED

Rhode_Dog

Garfinkle's brace uses bushing's, so vibration shouldn't be an issue.

I thought there was issues with the Feed brace regarding clearence with the ABS?

sonix7

Mike, I was trying to figure out if I was going to go with the ETB and an oil pan brace or just the oil pan brace and no ETB. seems like overkill with both, especially when my main concern is the f#*king oil pan leaking and killing the mounts I just got from you. that's all. I was told that with the oil pan brace I wouldn't have to worry about the pan leaking anymore( if done right) and the ETB ain't ****. you know that money thang is an issue. thanx

RecKleSs

I think Wael had them on his CYM. You might want to contact him and see if he can help you out.

Also, www.GothamRacing.com has motor mounts for the FD.

FD mission

it is a solid steel rod but you don't want any flex in a torque brace....I have the Garfinkle brace and love it, might help the oil pan issue as well, who knows

it has bushings so you only notice very mild vibration off idle

sonnguyenrx7

call chuck at rotaryextreme he will tell you how great the mazdaspeed motor mount work on our car.he had it on his car since 1995 510 683 8850

GoodfellaFD3S

iTrader: (213)

Urethane motor mounts are the way to go. Minimal vibration, vastly reduced engine movement, and should last the life of the car. I love mine, would never go back to stock. Plus, they are quite a bit cheaper than the mazdaspeed ones.

I am running the oil pan brace along w/the urethane mounts and not one drop of oil at all. I deep sixed my ETB, all it was doing at this point was transferring vibration to the interior of the car. Along with the Diff Brace my driveline is rock solid, I love the feel

FD mission

these cars need more braces than a 10 year old girl from Kentucky

prjctRx7

what oil pan brace are you using?? and where did you get you urethane motor mounts??

GoodfellaFD3S

iTrader: (213)

www.GothamRacing.com for all of it.

fd0

iTrader: (8)

I have the Mazdaspeed motor mounts (not sure if they are the regular ones or competition ones) and I can't say if they are better or worse because I haven't driven a rex with normal motor mounts to notice the difference. All I can say is with my setup (RB front sway bar and upgraded mounts, I think JimLab urethane bushings, Mazdaspeed motor mounts, RB springs w/Koni shocks, roll bar) my ride is very tight.

When I went WOT, I didn't feel the transmission being loose but I did miss the second to third shift a couple times because I have the Mazdaspeed short shifter and the shifting is pretty stiff and short. Also, I haven't driven my car long enough to get used to the shifting.

Here's a pic of the mounts

JRX

I have the whole set (engine, transmission, diff) mounts. They stiffened everything up really well as the diff mounts had torn.

Cannot compare them to any others though.

J.

VQracer

Rotorsports Racing urethane mounts in use here. I like them.

jeremyb

In conjunction to getting these motor mounts, does anyone have a link to where it explains a write-up or how-to of replacing the mounts?

Jeremy

DCrosby

I made my own, using the stock parts, It's phenomenal. I had gotten so used to the shifter sliding around left to right when I stepped on the gas, in both my '94 & '93, after the mounts, stick sayed glued to the trans tunnel...

Depending on the Poly you use you can get a softer or harder feel out of them, and initially they are quite rough, under 3000 rpm, but wear in over the 1000 mi. breakin period of my motor...

After that I did the diff brace (Solid), and it's almost too solid, I can feel a lot of vibration after 5000rpm, so I'm thinking of going back and doing Poly mounts to replace the stock ones... we'll see...





The trick over other Poly mounts is that some / most use a solid bolt through the middle, which doesn't improve suspension properties over a solid mount much. The stockers are put together like Opposing "T's" like this >< and have no touching parts, they are both cast inside the Polyurathane... this makes it more of a "Floating" situation, and helps the suspension properties significantly.....

RotorMotor

iTrader: (5)

hey! long time no see. yeah i remember you showed me those mounts in LA when we met up. so they are working out well? the only problem i see with casting to rods in the mount, is tearing... it would seem that they would be considerably more prone to tearing at that weak point... who knows.

i just got a set of the competition 1st gen mounts (need them to get the 20b lower)... but now im comtemplating making my own as you did. if you feel like describing the process/materials im interested. it would also be interesting to cast new tranny mounts in that same material. just trying to plan ahead for any drivetrain slop i may be in for w/ the 20b while trying my hardest to minimize vibrations as im sure they would drive me crazy.

anyway hope your doing well. -heath

John Magnuson

Ummmm... the FD has not tranny mount

jimlab

He's talking about a brace...
