meter fuse constantly blowing out??
09-13-06, 04:55 PM
#1
Full Member
Thread Starter
Join Date: Sep 2004
Location: Fresno, CA
Posts: 121
Likes: 0
Received 0 Likes
on
0 Posts
meter fuse constantly blowing out??
87-7 and the metering(the one for the gauges) fuse keeps frying out, haven't took the Voltmeter to it yet, just curious if anone has had this problem too... Not to metion I had to put a new batt. ground cable, put in a stereo with amp, and new alt...
09-13-06, 06:20 PM
#2
Originally Posted by rockman7
87-7 and the metering(the one for the gauges) fuse keeps frying out, haven't took the Voltmeter to it yet, just curious if anone has had this problem too... Not to metion I had to put a new batt. ground cable, put in a stereo with amp, and new alt...
09-13-06, 06:45 PM
#3
HAILERS
Join Date: May 2001
Location: FORT WORTH, TEXAS,USA
Posts: 20,563
Likes: 0
Received 21 Likes
on
19 Posts
Sorry, but the Meter fuse really gets around other than the gauges. I'd make suspect the audio changes that you made recently. Look for a Black wire with a Yellow stripe on it.
Meter fuse does the combination meter, cruise control, backup lights, AAS, cooling fan, theft protection, warning and digital clock, key cylinder lights, seat belt warning buzzer, door locks and stuff in general.
See if you did something PECULIAR with a black/yellow wire and then download the series four wiring schematics and view them.
Meter fuse does the combination meter, cruise control, backup lights, AAS, cooling fan, theft protection, warning and digital clock, key cylinder lights, seat belt warning buzzer, door locks and stuff in general.
See if you did something PECULIAR with a black/yellow wire and then download the series four wiring schematics and view them.
09-14-06, 02:30 PM
#4
Full Member
Thread Starter
Join Date: Sep 2004
Location: Fresno, CA
Posts: 121
Likes: 0
Received 0 Likes
on
0 Posts
thanks for looking out, isn't there wiring diagrams on here somewhere?? I connect some stuff from under the hood the other day so hopefully thats it, but with my luck I'll be back...
09-16-06, 08:16 PM
#6
spazz!
Join Date: May 2006
Location: Knightdale, NC
Posts: 663
Likes: 0
Received 0 Likes
on
0 Posts
How is the problem going? I'm currently dealing with this problem. The guy that had the car before me did some audio work, but I haven't had problems up until about 1 month ago. (I've owned the car for about 4 months.) I'm going to look over some wiring diagrams tomorrow and try to figure this out.
Last edited by Icemark; 09-16-06 at 11:02 PM.
09-16-06, 11:01 PM
#7
Former Moderator. RIP Icemark.
don't bump. Bumps are not allowed here in the 2nd gen RX-7 technical section and will be deleted when found. Furthermore bumps make you look like a spoiled child that thinks your question is more important than any of the 20000 other members.
So when you got the car, the meter fuse was blown, or you have done something recently and now the fuse blows???
The most common is that a clutch job was done, and the reverse light wires got ripped.
So when you got the car, the meter fuse was blown, or you have done something recently and now the fuse blows???
The most common is that a clutch job was done, and the reverse light wires got ripped.
