hmmm lsd question
#1
Rotary Freak
Thread Starter
iTrader: (37)
Join Date: Apr 2006
Location: Rancho Cucamonga
Posts: 2,371
Likes: 0
Received 0 Likes
on
0 Posts
hmmm lsd question
so heres my dilemma. i have a 91 fc. and im trying to figure out if i got lsd or not. now ive read some of the posts about it, and got to this post about "91 coupes having lsd ect ect" now the car was painted before i bought it so it doesnt havea label as to what model, but i am told gxl. it does have the nice fabric and seats, but it does not have a switch saying "adjustable suspension" or what not. so that confuses me. its power everything, wiper. oh yes this car is na too forgot to mention that. now i read on the forum to spin the wheels and if they go same way it got lsd if opposite it doesnt. i spun one wheel and the other turned opposite. so i was guessin my car doesnt have lsd. now i brought it up to my friend who is pretty good with rx-7's. he said that doesnt really matter, his corolla has lsd but still turns opposite, unless he spins it really fast. so he thinks my car should have lsd...so this is kinda where im at, what the heck do i got? if i were to look at the pumpkin or diff, would it have a lsd label on it? im tryin to figure this all out before going to get a s4 lsd to swap in place of mine if not. also s5 gxl's, i heard that for a tubro swap since the gxl is basically mini turbo model taht it shares same rear end, im not sure about that either from waht i have read, but if so thats one step less i have to do for turbo swap. thanks for your comments!
#2
Rotary Enthusiast
iTrader: (1)
Join Date: Jul 2003
Location: Prosser Washington
Posts: 1,248
Likes: 0
Received 0 Likes
on
0 Posts
ok your car shouldnt have a LSD. only the turbo and GTUs modles had LDS is S5.IMO you would be better off going with a S4 LSD anyways. i swapped out my viscous LSD for a clutch LSD last winter. but if you do an S4 LSD you will need the half shafts too..
your car is equiped similar to the S5 turbo, but the drive train is still the smaller N/A drive train. the turbo has all the power options just like the GXL.
all of this info is located at this thread posted at the top of the 2nd gen tech.
https://www.rx7club.com/2nd-generation-specific-1986-1992-17/specifications-what-did-2nd-generation-rx-7-come-w-options-standard-features-249616/
your car is equiped similar to the S5 turbo, but the drive train is still the smaller N/A drive train. the turbo has all the power options just like the GXL.
all of this info is located at this thread posted at the top of the 2nd gen tech.
https://www.rx7club.com/2nd-generation-specific-1986-1992-17/specifications-what-did-2nd-generation-rx-7-come-w-options-standard-features-249616/
#3
Former Moderator. RIP Icemark.
Originally Posted by meximan
so heres my dilemma. i have a 91 fc. and im trying to figure out if i got lsd or not. now ive read some of the posts about it, and got to this post about "91 coupes having lsd ect ect" now the car was painted before i bought it so it doesnt havea label as to what model, but i am told gxl. it does have the nice fabric and seats, but it does not have a switch saying "adjustable suspension" or what not. so that confuses me. its power everything, wiper. oh yes this car is na too forgot to mention that.
now i read on the forum to spin the wheels and if they go same way it got lsd if opposite it doesn't. i spun one wheel and the other turned opposite. so i was guessin my car doesnt have lsd. now i brought it up to my friend who is pretty good with rx-7's. he said that doesnt really matter, his corolla has lsd but still turns opposite, unless he spins it really fast.
so he thinks my car should have lsd...
so this is kinda where im at, what the heck do i got? if i were to look at the pumpkin or diff, would it have a lsd label on it? im tryin to figure this all out before going to get a s4 lsd to swap in place of mine if not. also s5 gxl's, i heard that for a tubro swap since the gxl is basically mini turbo model taht it shares same rear end, im not sure about that either from waht i have read, but if so thats one step less i have to do for turbo swap. thanks for your comments!
So to make it short...
1. If you have a 91 FC without a turbo, you don't have a LSD.
2. If you have a rare A&B package non turbo you might have a LSD (although in all honestly I think the members that thought they had one on a A&B package coupe, just were clueless)... but we already know you don't have leather, so you don't have a B package, so you don't have a LSD.
3. Your buddy is probably not your best choice of info on a cars.
#4
Rotary Freak
Thread Starter
iTrader: (37)
Join Date: Apr 2006
Location: Rancho Cucamonga
Posts: 2,371
Likes: 0
Received 0 Likes
on
0 Posts
thank you for your replys, mort you said my car is similiar to the turbo models minus the drivetrain, so, if doin a turbo swap motor engine and drivetrain, would the rest of the rear end still work? in doin a na lsd swap to swap my s5 viscous POS :P to s4 i need halfshafts. do you know in turbo models if thats the same also, if i go s5 to s4 in a tII rear end is it straight swap or do you need halfshafts for s4 also? im gonna try the tire test again tommaro. and where the heck is prosser WA? lol , thats cool ur in wa another guy to meet!
#6
Rotary Freak
Thread Starter
iTrader: (37)
Join Date: Apr 2006
Location: Rancho Cucamonga
Posts: 2,371
Likes: 0
Received 0 Likes
on
0 Posts
OK once again i read the 91 section, Package A- i have all of those listings of characteristics....now again its said taht package a and B are rumored to have lsd.
#7
Former Moderator. RIP Icemark.
BUT you don't have the B package (no leather)... SO NO LSD. A and B package... not just one or the other.
Besides according to Mazda not a single 91 non turbo built had a LSD. But you already tested and showed that you didn't have a LSD... Not a viscous LSD, not a clucth LSD... YOU DON"T HAVE A LSD!
And again, there is nothing in common between the Turbo and Non turbo drive lines. Why are you not getting that. You will need to replace the rear end, or have a custom drive shaft built if you want to retain your non turbo rear end and do a turbo swap. If you swap a Turbo rear end in, you will need to swap half shafts.
Not seeing why you are not getting these things. Is it just wishful thinking, or an inability to understand what you have?
Maybe to make it simpler:
The only thing common between your non turbo coupe model and a Turbo is the basic body and that you have 5 lug wheels.
Besides according to Mazda not a single 91 non turbo built had a LSD. But you already tested and showed that you didn't have a LSD... Not a viscous LSD, not a clucth LSD... YOU DON"T HAVE A LSD!
And again, there is nothing in common between the Turbo and Non turbo drive lines. Why are you not getting that. You will need to replace the rear end, or have a custom drive shaft built if you want to retain your non turbo rear end and do a turbo swap. If you swap a Turbo rear end in, you will need to swap half shafts.
Not seeing why you are not getting these things. Is it just wishful thinking, or an inability to understand what you have?
Maybe to make it simpler:
The only thing common between your non turbo coupe model and a Turbo is the basic body and that you have 5 lug wheels.
Trending Topics
#8
Rotary Freak
Thread Starter
iTrader: (37)
Join Date: Apr 2006
Location: Rancho Cucamonga
Posts: 2,371
Likes: 0
Received 0 Likes
on
0 Posts
What the hell....this **** pisses me off. OK first off i came on this forum to learn something about rx-7's. i like rx-7's i enjoy workin on my own cars as a hobby NOT as a Career. I do not have any Schooling in mechanics, I AM A CAR ENTHUSIAST, just like many of u started. Now i read threads all the time that are like "read this read that" CHECK THE FAQ's, and put people down about it. thats bull in my mind, IF IM WILLIN TO LEARN SOMETHING , TEACH ME. if you owned a shop and i came in and asked you questions about what something does or a product you have, are you going to tell me, go ask someone else or go read some books? If you dont want to answer my question dont post anything, if i dont understand something help me, dont knock me down for it.
Now in your mazda guide for the year 91 , it says package a is optional, or ...package b is optional but you must have package a too. i said i think i have package A based off everything it lists, package a could have been purchased by itself, i never said i had package b. I read the FAQ's, i had questions about it so i asked. i did the tests, burnout, one tire on teh ground and turn the other, ect. i do 2 tire burnouts, i left one wheel on the ground and one in the air and it moves...so if mazda guide is right, and this rumor i heard and am asking about, about package a having lsd, is then false. i dont see what i have done wrong...other then try and learn something about my car. ..
Now in your mazda guide for the year 91 , it says package a is optional, or ...package b is optional but you must have package a too. i said i think i have package A based off everything it lists, package a could have been purchased by itself, i never said i had package b. I read the FAQ's, i had questions about it so i asked. i did the tests, burnout, one tire on teh ground and turn the other, ect. i do 2 tire burnouts, i left one wheel on the ground and one in the air and it moves...so if mazda guide is right, and this rumor i heard and am asking about, about package a having lsd, is then false. i dont see what i have done wrong...other then try and learn something about my car. ..
#9
Banned. I got OWNED!!!
Join Date: Dec 2006
Location: Palmdale Ca
Posts: 275
Likes: 0
Received 0 Likes
on
0 Posts
Don't sweat it man im doing a somewhat similar swap im putting in an 88 s4 turbo 2 rear end in my 86 n/a rx7 i have the base model with the four lug wheels. im currently swithing over my brakes,spindles and everything else i might need to have the 5 lug and turbo calipers. i've been told that i will need a custom driveshaft made. which is something im not worried about if you have anymore questions you should try and contact one of the vendor spots on the forums. i would recommend rotaryshack or mazdatrix they might give you the info you need and better explain things your maybe not getting good luck to you man .
#10
Former Moderator. RIP Icemark.
Originally Posted by meximan
What the hell....this **** pisses me off. OK first off i came on this forum to learn something about rx-7's. i like rx-7's i enjoy workin on my own cars as a hobby NOT as a Career. I do not have any Schooling in mechanics, I AM A CAR ENTHUSIAST, just like many of u started. Now i read threads all the time that are like "read this read that" CHECK THE FAQ's, and put people down about it. thats bull in my mind, IF IM WILLIN TO LEARN SOMETHING , TEACH ME. if you owned a shop and i came in and asked you questions about what something does or a product you have, are you going to tell me, go ask someone else or go read some books? If you dont want to answer my question dont post anything, if i dont understand something help me, dont knock me down for it.
Now in your mazda guide for the year 91 , it says package a is optional, or ...package b is optional but you must have package a too. i said i think i have package A based off everything it lists, package a could have been purchased by itself, i never said i had package b.
I read the FAQ's, i had questions about it so i asked. i did the tests, burnout, one tire on teh ground and turn the other, ect. i do 2 tire burnouts, i left one wheel on the ground and one in the air and it moves...so if mazda guide is right, and this rumor i heard and am asking about, about package a having lsd, is then false. i dont see what i have done wrong...other then try and learn something about my car. ..
With a working clutch type or viscous type LSD if you jack the rear end up and spin one wheel, the opposite will spin the same direction or not at all.
With a open differential, if you jack the rear end up, and spin one wheel, the opposite will spin the opposite direction. This is the same thing that will happen with a burnt out, wasted and generally used all the hell up LSD (just like your buddy claims to have).
Almost anyone can break both wheels loose on a FC. This would mean two burn out streaks. This does not mean that you have a LSD, but rather that you have poor traction. A 15 year old suspension with tiny 205 width tires (the stock size on a S5 non turbo) is the reason... not because you have a LSD.
A burn out does not mean you have LSD (and for the life of me I can't figure out why anyone would think it does... ). So it is not a test for a LSD.
Now since you have ignored most of the replies in this thread, I doubt you will read any of this, but one hopes you do so you can school your buddy and yourself.
#11
I'm a boost creep...
Join Date: Jan 2002
Location: Auckland, New Zealand
Posts: 15,608
Likes: 0
Received 8 Likes
on
8 Posts
Originally Posted by meximan
Now i read threads all the time that are like "read this read that" CHECK THE FAQ's, and put people down about it. thats bull in my mind...
if you owned a shop and i came in and asked you questions about what something does or a product you have, are you going to tell me, go ask someone else or go read some books?
If you dont want to answer my question dont post anything...
i do 2 tire burnouts...
#14
Can't Hear Now
iTrader: (62)
Originally Posted by JDM_Infini
hmmmm, my '90 GXL spins the other wheel the same way if jacked up, and has always behaved like a car w/ lsd, but from what i'm reading it doesn't?
#16
The Silent but Deadly Mod
iTrader: (2)
I started off the same way you did, except I read a lot of stickies, that's why my post count is so low. They're very clear, and I never had any questions of what does my car have. I could easily find the answers you're looking for in 5 minutes. If you're here to learn, learn the method on how to find the information you're looking for. Don't expect anyone to spoon-feed you information. Put yourself in the others' shoes. Would you really like to respond to 5000 posts on "Does my car come with power locks from the factory?"It's the same thing.
You have a 91, you don't have BOTH the A & B package. You do not have LSD from the factory. You may have LSD if a previous owner put on an aftermarket one.
For the turbo conversion you need:
Turbo engine
Turbo clutch
Turbo flyhweel
Turbo transmission
Turbo driveshaft
Turbo half-shafts
Turbo differential
Turbo starter
Turbo clutch slave
Your friend might know how to drift, but that doesn't mean he knows anything about mechanics. Especially his statement about you having an LSD? That proves a whole lot to many people.
You might just have a shot aftermarket viscous LSD. Or you could just be imagining it.
You have a 91, you don't have BOTH the A & B package. You do not have LSD from the factory. You may have LSD if a previous owner put on an aftermarket one.
For the turbo conversion you need:
Turbo engine
Turbo clutch
Turbo flyhweel
Turbo transmission
Turbo driveshaft
Turbo half-shafts
Turbo differential
Turbo starter
Turbo clutch slave
Your friend might know how to drift, but that doesn't mean he knows anything about mechanics. Especially his statement about you having an LSD? That proves a whole lot to many people.
Originally Posted by JDM_Infini
hmmmm, my '90 GXL spins the other wheel the same way if jacked up, and has always behaved like a car w/ lsd, but from what i'm reading it doesn't?
Last edited by Roen; 03-30-07 at 02:38 PM.
#17
Touge FC3S
iTrader: (1)
Join Date: Oct 2003
Location: So Cal
Posts: 400
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by Roen
I started off the same way you did, except I read a lot of stickies, that's why my post count is so low. They're very clear, and I never had any questions of what does my car have. I could easily find the answers you're looking for in 5 minutes. If you're here to learn, learn the method on how to find the information you're looking for. Don't expect anyone to spoon-feed you information. Put yourself in the others' shoes. Would you really like to respond to 5000 posts on "Does my car come with power locks from the factory?"It's the same thing.
You have a 91, you don't have BOTH the A & B package. You do not have LSD from the factory. You may have LSD if a previous owner put on an aftermarket one.
For the turbo conversion you need:
Turbo engine
Turbo clutch
Turbo flyhweel
Turbo transmission
Turbo driveshaft
Turbo half-shafts
Turbo differential
Turbo starter
Turbo clutch slave
Your friend might know how to drift, but that doesn't mean he knows anything about mechanics. Especially his statement about you having an LSD? That proves a whole lot to many people.
You might just have a shot aftermarket viscous LSD. Or you could just be imagining it.
You have a 91, you don't have BOTH the A & B package. You do not have LSD from the factory. You may have LSD if a previous owner put on an aftermarket one.
For the turbo conversion you need:
Turbo engine
Turbo clutch
Turbo flyhweel
Turbo transmission
Turbo driveshaft
Turbo half-shafts
Turbo differential
Turbo starter
Turbo clutch slave
Your friend might know how to drift, but that doesn't mean he knows anything about mechanics. Especially his statement about you having an LSD? That proves a whole lot to many people.
You might just have a shot aftermarket viscous LSD. Or you could just be imagining it.
you also need senors, harness, cpu and other small things to convert to turbo.
just like roen, i started off searching, my post count is even lower than his. i've found answers to practically all my questions by searching the forum. either way, it sounds like you either have a shot LSD or the most obvious, you dont have LSD at all, so either way you might want to replace your shot LSD or open diff. with a new/good one.
#19
I'm a boost creep...
Join Date: Jan 2002
Location: Auckland, New Zealand
Posts: 15,608
Likes: 0
Received 8 Likes
on
8 Posts
Originally Posted by meximan
NZ your just another one of those idiots...
Test it like I said and you'll know staight away if you have a functioning LSD or not.
#23
Full Member
Join Date: Mar 2005
Location: British Columbia
Posts: 79
Likes: 0
Received 0 Likes
on
0 Posts
hmmm well i find this kind of odd because my 91 T2 doesn't have an LSD in it, i jacked up the back and as i spin one tire the other turns the opposite way, i think i might have screwed! or i'm just stupid haha
