Differential Brace for the fc
#1
D.I.L.U.S.I.
Thread Starter
iTrader: (5)
Join Date: Nov 2002
Location: L-Town pa
Posts: 2,051
Likes: 0
Received 0 Likes
on
0 Posts
Differential Brace for the fc
is there a Differential Brace out there for the fc like the Banzai Racing made up for the fd?
trying to get rid of my wheel hop and thinking this option would help if there is one out there
trying to get rid of my wheel hop and thinking this option would help if there is one out there
#7
D.I.L.U.S.I.
Thread Starter
iTrader: (5)
Join Date: Nov 2002
Location: L-Town pa
Posts: 2,051
Likes: 0
Received 0 Likes
on
0 Posts
im looking at the energy hyper flex full kit i might as well change every one while im at it. ill order the solid diff mounts and will try and track down the brace and the pinion snubber.. hope to have everything done at ones so i can get over this wheel hop..
ITsWILL what pinion snubber did you go with i can only find them for ford or mopar or do you have a pic of where you installed it..thanks
ITsWILL what pinion snubber did you go with i can only find them for ford or mopar or do you have a pic of where you installed it..thanks
Trending Topics
#13
Wiring Nightmare
iTrader: (12)
im looking at the energy hyper flex full kit i might as well change every one while im at it. ill order the solid diff mounts and will try and track down the brace and the pinion snubber.. hope to have everything done at ones so i can get over this wheel hop..
ITsWILL what pinion snubber did you go with i can only find them for ford or mopar or do you have a pic of where you installed it..thanks
ITsWILL what pinion snubber did you go with i can only find them for ford or mopar or do you have a pic of where you installed it..thanks
http://members.tripod.com/~grannys/snubberinstalled.jpg
#15
Top Down, Boost Up
iTrader: (7)
Here's a writeup for changing the front diff mount and adding a pinion snubber. I used the same bump stop PvillKnight7 linked to, and approximately 1/2" worth of washers shims it enough to preload against the nose of the diff.
https://www.rx7club.com/2nd-generation-specific-1986-1992-17/pinion-snubber-diff-mount-replacement-convertible-876959/
https://www.rx7club.com/2nd-generation-specific-1986-1992-17/pinion-snubber-diff-mount-replacement-convertible-876959/
#19
you should use a snubber $12 from autozone 30min install ...on your drivers side tray open it up you have to drill a hole over the mount and install your snubber ...then this will stop the travel of the mount...no more hop...make sure you put silicone on the thread of the snubber and hole
#20
Fistful of steel
iTrader: (7)
I just boxed in a factory front diff mount with steel so it can't move. It has worked great for over a year. Drivetrain noise will go up a bit though.
You MUST use solid subframe bushings with a solid front diff mount and solid rear diff bushings or you will break the mounting tab off the subframe.
You MUST use solid subframe bushings with a solid front diff mount and solid rear diff bushings or you will break the mounting tab off the subframe.
