CP Racing triangular strut bar problems
I have an 89 Turbo 2 and recently purchased the triangulated strut bar from CP. I test fitted it the other day and ran into a couple of problems. 1) On both strut towers the sensors that are mounted on the front side of the towers has to be moved, not a big deal, but then 2) the main bar of the CP strut bar hits the FAN!!! This is a big problem. Brian at MazMax assured me that my engine is sitting right (the stock fan is half in the shroud and half out).
Has anyone else experienced these problems with this strut bar? Help Please, especially with the fan thing.
Has anyone else experienced these problems with this strut bar? Help Please, especially with the fan thing.
09-28-05, 03:53 PM
#3
Senior Member
Join Date: Jun 2004
Location: Houston
Posts: 655
Likes: 0
Received 0 Likes
on
0 Posts
I went with a 10,000 rpm flex fan with a 2" spacer.....it just clears the bar. I think I had about .25" clearance. Now I have yet to really dirve it so I'm not sure if it will keep the coolat cool or if it will over heat.
I also had to grind down the ends of ths straight bar so that it would not hit the hood.
I also had to grind down the ends of ths straight bar so that it would not hit the hood.
09-28-05, 05:54 PM
#5
89 Turbo II
Thread Starter
Join Date: Jan 2005
Location: Oklahoma City
Posts: 362
Likes: 0
Received 0 Likes
on
0 Posts
I think someone hates CP Racing!!! Anyway, all hating aside, Can I get a little more info on that fan? Mazmax is putting a fluidyne radiator on for me this week so it would be the best time to change a few things with the cooling system.
09-28-05, 06:17 PM
#6
Lava Surfer
Join Date: Mar 2002
Location: Kailua, HI
Posts: 2,354
Likes: 0
Received 0 Likes
on
0 Posts
i got out the scissors, and trimmed 1/4" off the corner of each fan blade. oh and i got a shorter power steering belt because the idler pulleyhit the bar as well. oh..and...oh and...yep have fun.
09-29-05, 10:29 AM
#7
Engine, Not Motor
iTrader: (1)
Join Date: Feb 2001
Location: London, Ontario, Canada
Posts: 29,789
Likes: 0
Received 108 Likes
on
91 Posts
On some cars the bars hit. I'm not sure what the difference is. Maybe someone with a bunch of spare fans from different years can measure and see if there is a difference.
Anyway, you may be able to space the bar up slightly with washers on the strut tower bolts. If you can't get enough distance, then you may need to trim the fan. FWIW, on my car, an '86, the bar cleared the fan easily with about an inch or more to spare.
Anyway, you may be able to space the bar up slightly with washers on the strut tower bolts. If you can't get enough distance, then you may need to trim the fan. FWIW, on my car, an '86, the bar cleared the fan easily with about an inch or more to spare.
Trending Topics
09-29-05, 01:18 PM
#9
Senior Member
Join Date: Mar 2004
Location: Ontario, Canada
Posts: 271
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by The Wankler
Problem #1, you bought something from CPRacing.......
Problem #2, you bought something from CPRacing.......
Problem #3, you bought something from CPRacing.......
Problem #2, you bought something from CPRacing.......
Problem #3, you bought something from CPRacing.......
If you have something to say, say it properly. Stop with the lame, pathetically childish trash talk because you're REALLY starting to get on mine and a LOT of other peoples' nerves. Mmkay?
About the bar:
Oddly enough it fit perfectly on my '87 GXL and required trimming of the rad fan on my '88 Base. Something is amiss and I don't think it's the bars. I've heard of people having problems at the firewall because their car is twisted or sagging. I've never heard of it not clearing the hood though, that's a new one. Interesting...
