2nd gen E-fans
#1
2nd gen E-fans
what kinds of e-fans are you guys using?
I am looking to fit a 2nd gen radiator into
my RX2 so i want to buy a e-fan that gonna fit
that size correctly. let me know what you guys have
and how you like it. and pics are always good.
Thanks matt22
I am looking to fit a 2nd gen radiator into
my RX2 so i want to buy a e-fan that gonna fit
that size correctly. let me know what you guys have
and how you like it. and pics are always good.
Thanks matt22
#4
casio isn't here.
Join Date: Sep 2002
Location: Greenpoint, Brooklyn
Posts: 3,332
Likes: 0
Received 0 Likes
on
0 Posts
http://www.rotaryresurrection.com/ >> Tech >> Electric Fan
http://www.aaroncake.net/rx-7/efaninstall.htm
i know those also go into installing, which may also help, but they also mention a couple of possible fans to use and why.
http://www.aaroncake.net/rx-7/efaninstall.htm
i know those also go into installing, which may also help, but they also mention a couple of possible fans to use and why.
#7
casio isn't here.
Join Date: Sep 2002
Location: Greenpoint, Brooklyn
Posts: 3,332
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by 7th Heaven
hmm, that has me wondering. can i use an aftermarket radiator while retaining the stock fan? more specific; a koyo radiator with an s5 fan, will it fit ok?
Trending Topics
#8
^ phew, i was worried for a sec that i was going to have fan blade clearing issues. after reading Kevin's write-up, an Efan won't make THAT much of an improvement over the stock fan, however an aftermarket radiator will make a drastic change to how hot the car will run. so for now i figure i'll stick with the oem fan, the new radiator should be plenty (car never goes over 1/2 anyways, and 1/2 is only when it's been idling in traffic for 10 minutes in those crazy hot FL days).
thanks Casio.
thanks Casio.
#9
Da Monee Pit
Join Date: Dec 2001
Location: Littlefield, Texas
Posts: 843
Likes: 0
Received 0 Likes
on
0 Posts
I use a 16" perma-cool "finger chopper" (ala no guard on it) it pulls about 2900cfm and works like a champ. Fit's perfect.
PRM-19115
http://store.summitracing.com/partde...+400006+301218
PRM-19115
http://store.summitracing.com/partde...+400006+301218
#14
Da Monee Pit
Join Date: Dec 2001
Location: Littlefield, Texas
Posts: 843
Likes: 0
Received 0 Likes
on
0 Posts
No fan shroud. I had one on but it keeps it cooler without a shroud. I know it sounds weird but I guess it's the way they designed it.
I have the fan going to a relay and use my E6K to control it. It's an accessory wire (I can give you exact name of the wire and the setting tab I used on the haltech program when I get a chance to look at it, the car is in Dallas at the moment getting some clutch work and tuning done, I can tell you the tab tomorrow when I get a chance to look at the haltech program on my laptop). Anyway I have the Haltech set to turn the fan on at 190 and shut it off at 185. I used the thermostat switch and controller from permacool (a seperate part) but it didn't work very well for me, I had a bad relay though i found out after I switched it over to the haltech so that may have been the problem before I switched from the permacool thermostat and switch.
I have the fan going to a relay and use my E6K to control it. It's an accessory wire (I can give you exact name of the wire and the setting tab I used on the haltech program when I get a chance to look at it, the car is in Dallas at the moment getting some clutch work and tuning done, I can tell you the tab tomorrow when I get a chance to look at the haltech program on my laptop). Anyway I have the Haltech set to turn the fan on at 190 and shut it off at 185. I used the thermostat switch and controller from permacool (a seperate part) but it didn't work very well for me, I had a bad relay though i found out after I switched it over to the haltech so that may have been the problem before I switched from the permacool thermostat and switch.
#21
Rotary Enthusiast
Join Date: Jun 2004
Location: trenton,il
Posts: 760
Likes: 0
Received 0 Likes
on
0 Posts
thats wat im so scared of is the wiring part cus i dont know how to wire it in or wat i got a feiro gt e-fan
but i dont know how to wire it in im afraid il burn sumthing up
but i dont know how to wire it in im afraid il burn sumthing up
#22
Compression Tester Guy
iTrader: (3)
Join Date: Apr 2003
Location: Houston, TX
Posts: 1,010
Likes: 0
Received 0 Likes
on
0 Posts
I had a Fiero efan in my car and it could not keep up once I moved down here. Temps were always between 195 and 210 just normal driving without AC on. I put the stock fan and shroud back in and now my temps stay between 150 and 180, AC on or not. I won't ever use an efan again.
-John
P.S.- I used the Painless Wiring Electric Fan Controller....very easy to install and works great!
-John
P.S.- I used the Painless Wiring Electric Fan Controller....very easy to install and works great!
#23
i am legendary
Join Date: Sep 2003
Location: Kirkland, WA
Posts: 8,478
Likes: 0
Received 0 Likes
on
0 Posts
I use an escort e-fan. Used to have it set up through a probe for a thermostat to have it turn on at about 190 but it was working extremely shitty and I didn't want my car to overheat (got iffy a couple times, this was all before the rebuild too btw), so I just have it set up to be on all the time. Temps stay around 178ish to 185 all the time measured by an electrical water temp gauge at the block.
#24
Dyslexia gotta love it
Join Date: Aug 2004
Location: Geneseo IL usa
Posts: 460
Likes: 0
Received 0 Likes
on
0 Posts
i'll stick with the stockfan and in the futucher maby use liquid nitrogin <--- ya i cant spell
Last edited by tecknomage; 11-14-04 at 05:53 PM. Reason: said efans instead of stock fans lol
#25
Rotary Enthusiast
Join Date: Oct 2002
Location: California, Bay Area
Posts: 1,165
Likes: 0
Received 0 Likes
on
0 Posts
They only problem ive had with my fierro fan is the damn thermal probe in the rad kinda sux,.. i have to have it turn on at like 160 while idleing to have it come on at like 185 when the car is moving,..
