turbo manifold
#1
Smile Like a Donut
Thread Starter
Join Date: Feb 2004
Location: Don't you wish you knew....
Posts: 1,236
Likes: 0
Received 0 Likes
on
0 Posts
turbo manifold
Hey I was just curious on what kind turbo manifold I would need to get to fullfil my turbo dream. tried searhing but couldn't find anything.
#5
FB+FC=F-ME
S5 (89-91) TII has a nice, simple cast manifold that will fit all 13Bs.It may require some grinding if the 13B center plate has a boss on it like the FC non-turbo 13Bs do.No big deal.Its also a good flowing little manifold that doesnt suffer the cracking issues like the S4 manifolds do.Ive run 14psi through mine for years with no ill effects.
Youd probably be limited to a S5 turbo instead of a fancy aftermarket turbo,but thats still good for more boost than you should run through a 70s 13B anyways.About 10-11psi is the limit for the stock T18,but you could also go hybrid with the S5 turbo and convert it to a TO4 compressor.You be good for 14psi then but your N/A engine would likely scatter quickly from that much boost.
Youd probably be limited to a S5 turbo instead of a fancy aftermarket turbo,but thats still good for more boost than you should run through a 70s 13B anyways.About 10-11psi is the limit for the stock T18,but you could also go hybrid with the S5 turbo and convert it to a TO4 compressor.You be good for 14psi then but your N/A engine would likely scatter quickly from that much boost.
Trending Topics
#9
I woulden't put a FC manifold in a FB. FC manifolds place the turbo too far forward and damn near stuff the compressor housing into the radiator. FB's can have the turbo placed more rearward.
#13
Banned. I got OWNED!!!
Join Date: Nov 2002
Location: KING COUNTY, WA
Posts: 4,980
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by CarlRx7
i have a s5 manifold and s5 turbo on my 12a and the compressor is no where near my radiator.
carl.
carl.
