Swapping my leading coil- want confirmation.
#1
Noob and trying to learn
Thread Starter
Swapping my leading coil- want confirmation.
I have a 1984 rx-7 gs. I have a 12a engine in it. Pulled from a very unhappy dying car in the scrapyard.
I bought the msd blaster 8222.
I have electronic ignition since it is after 1979 and ignitors on the side of distributor?
I do not need the ballast resistor since after 1980?
I bought two should I swap both?(Both are original factory coils)
The one nearest the headlight is trailing and the one nearest driver is leading.
Lastly, I know this is the info from other previous threads, but it would be a nice condensed answer sheet for myself and others.
Thanks for the time
photos of car in attachments
I bought the msd blaster 8222.
I have electronic ignition since it is after 1979 and ignitors on the side of distributor?
I do not need the ballast resistor since after 1980?
I bought two should I swap both?(Both are original factory coils)
The one nearest the headlight is trailing and the one nearest driver is leading.
Lastly, I know this is the info from other previous threads, but it would be a nice condensed answer sheet for myself and others.
Thanks for the time
photos of car in attachments
#2
Moderator
iTrader: (3)
Join Date: Mar 2001
Location: https://www2.mazda.com/en/100th/
Posts: 30,844
Received 2,605 Likes
on
1,848 Posts
I do not need the ballast resistor since after 1980?
I bought two should I swap both?(Both are original factory coils)
The one nearest the headlight is trailing and the one nearest driver is leading.
#3
Noob and trying to learn
Thread Starter
Thanks for the reply. I looked last night apparently my buddy didn't know which coil was which so I will be taking the time to properly wire the*cap and the plugs.
Trailing top.
Leading lower.
T1 and L1 front.
T2 and L2 rear.
Correct?
Next addressing hot start issues.
Trailing top.
Leading lower.
T1 and L1 front.
T2 and L2 rear.
Correct?
Next addressing hot start issues.
#5
Noob and trying to learn
Thread Starter
Well it would seem that my car runs substantially better with the new leading coil and the wires in the correct location. Also my car seems to want to start easier... Imagine that... lol
I believe the next step is to redo the timing since it is different now that things are switched.
I believe the next step is to redo the timing since it is different now that things are switched.
#6
1st-Class Engine Janitor
iTrader: (15)
"Wires in the correct location" probably had more impact than the coil change.
Having leading and trailing swapped has the same effect as being 20 degrees late on timing. Runs, but not well.
Having front and rear swapped puts you 180 degrees out on timing and the car will not start. I know that one from painful experience.
Having leading and trailing swapped has the same effect as being 20 degrees late on timing. Runs, but not well.
Having front and rear swapped puts you 180 degrees out on timing and the car will not start. I know that one from painful experience.
#7
Noob and trying to learn
Thread Starter
So I switched everything and it was running better.
Got my secondaries mechanical now and when I am driving hard, I push hard in 3 gear and above my engine cuts out but will go normal if I let go of the gas... Fuel starvation issue possibly?
Got my secondaries mechanical now and when I am driving hard, I push hard in 3 gear and above my engine cuts out but will go normal if I let go of the gas... Fuel starvation issue possibly?
