just bought a stardust blue FB with quite some questions...
#1
Junior Member
Thread Starter
Join Date: Mar 2014
Location: Belgium
Posts: 20
Likes: 0
Received 0 Likes
on
0 Posts
just bought a stardust blue FB with quite some questions...
Hi guys,
My first post here. I’m from Belgium, Europe and I’ve bought a stardust blue metallic FB 2 weeks ago. It’s a weekend / hobby car with a few good points but also like always some details that need attention. The goal is to build a nice Japanese classic on a budget. Not that I want to go super cheap but I have limits, or in other words, the girlfriend has limits. HAHA! I know a bit of mechanics, I had a Volkswagen notchback 1500S and a Alfa romeo GT junior lusso before where I turned some wrenches on. Not that I can rebuild engines but I know every part and what it does and I’m not new to basic trouble shooting, mechanics, syncronsing carburetors, dialing the ignition and stuff like that. The rotary is new to me but I kinda dig the concept for quite a while now… I’ve already read some topics in the FAQ pages.
The paint is a 7/10, some different shades in the blue due to some bad repaint(s) but no visible rust or major dents. The interior is 90% perfect, quite unusual over here. No rips or stains on the seats, nice carpet, nice dash…
The 12A starts right away every time, shifting is good, all the electronics work.
The bad:
I guess the fan clutch is seized, I can stop it with a broom but with quite some force, I wouldn’t try it with my hands… if the engine is cold I can turn the fan but not that very well, but yeah, what’s okay? I don’t know…
As soon as I start the car the fan starts to blow like a maniac, I can’t hear the engine anymore. I used the search function but this forum is BIG!! Can you buy these fan clutches new? I don’t want to go the electric fan way straight away…
Any leads?
Next, I want to upgrade the bushings and see to improve the steering. The steering is bad! I also read before that this is a typical “problem” with these cars but what the heck? A beetle with 1940 technology steers better!
Is there a kit out there to renew every bushing or problem areas for the steering aspect? I hope you guys can point me in the right direction.
The bushing right now on the suspension and sway bars are old and cracked, that can’t be good…
For the suspension I saw that I can order some bushings from racing beat… Good choice? Maybe other leads? Cheaper/better? I’m willing to buy all over the world, the shipping from the usa costs me a damn arm and leg!
The plans for the future if I can get the car MOT’d I want to lower it a bit. (it already has koni struts in the back so that’s a good thing!)
A nice period correct set of 15” wheels with I guess a 205/70/15 tire on them.
A full racing beat street port exhaust, alternatives? Again, the shipping is killing me…
Racing beat air filter (white cone) a nice upgrade or rather a market stunt? And play around with the opening of the butterfly’s and jetting maybe?
New motor mounts, stiffer
Maybe new disc brakes and pads if they turn out to be bad but I hope not…
But first I try to upload some pictures of the new ride, a new topic is always nicer with pictures, isn’t it?
Dem
My first post here. I’m from Belgium, Europe and I’ve bought a stardust blue metallic FB 2 weeks ago. It’s a weekend / hobby car with a few good points but also like always some details that need attention. The goal is to build a nice Japanese classic on a budget. Not that I want to go super cheap but I have limits, or in other words, the girlfriend has limits. HAHA! I know a bit of mechanics, I had a Volkswagen notchback 1500S and a Alfa romeo GT junior lusso before where I turned some wrenches on. Not that I can rebuild engines but I know every part and what it does and I’m not new to basic trouble shooting, mechanics, syncronsing carburetors, dialing the ignition and stuff like that. The rotary is new to me but I kinda dig the concept for quite a while now… I’ve already read some topics in the FAQ pages.
The paint is a 7/10, some different shades in the blue due to some bad repaint(s) but no visible rust or major dents. The interior is 90% perfect, quite unusual over here. No rips or stains on the seats, nice carpet, nice dash…
The 12A starts right away every time, shifting is good, all the electronics work.
The bad:
I guess the fan clutch is seized, I can stop it with a broom but with quite some force, I wouldn’t try it with my hands… if the engine is cold I can turn the fan but not that very well, but yeah, what’s okay? I don’t know…
As soon as I start the car the fan starts to blow like a maniac, I can’t hear the engine anymore. I used the search function but this forum is BIG!! Can you buy these fan clutches new? I don’t want to go the electric fan way straight away…
Any leads?
Next, I want to upgrade the bushings and see to improve the steering. The steering is bad! I also read before that this is a typical “problem” with these cars but what the heck? A beetle with 1940 technology steers better!
Is there a kit out there to renew every bushing or problem areas for the steering aspect? I hope you guys can point me in the right direction.
The bushing right now on the suspension and sway bars are old and cracked, that can’t be good…
For the suspension I saw that I can order some bushings from racing beat… Good choice? Maybe other leads? Cheaper/better? I’m willing to buy all over the world, the shipping from the usa costs me a damn arm and leg!
The plans for the future if I can get the car MOT’d I want to lower it a bit. (it already has koni struts in the back so that’s a good thing!)
A nice period correct set of 15” wheels with I guess a 205/70/15 tire on them.
A full racing beat street port exhaust, alternatives? Again, the shipping is killing me…
Racing beat air filter (white cone) a nice upgrade or rather a market stunt? And play around with the opening of the butterfly’s and jetting maybe?
New motor mounts, stiffer
Maybe new disc brakes and pads if they turn out to be bad but I hope not…
But first I try to upload some pictures of the new ride, a new topic is always nicer with pictures, isn’t it?
Dem
#3
Moderator
iTrader: (3)
Join Date: Mar 2001
Location: https://www2.mazda.com/en/100th/
Posts: 30,844
Received 2,605 Likes
on
1,848 Posts
nice car! how do you drive it upside down?
fan clutches are available new still, although they were very expensive ($300ish depending on model/year). they do have a low failure rate, so used is probably an option
have a search through here, the steering box has several adjustments on it, so that is the first place to start. you should check all the other steering components too, but if its "worse than a 1940 beetle" than its probably the box.
the US shop manuals are here Foxed.ca - Mazda RX-7 Manuals the euro cars are 90% the same, biggest difference is/are the trim levels.
fan clutches are available new still, although they were very expensive ($300ish depending on model/year). they do have a low failure rate, so used is probably an option
have a search through here, the steering box has several adjustments on it, so that is the first place to start. you should check all the other steering components too, but if its "worse than a 1940 beetle" than its probably the box.
the US shop manuals are here Foxed.ca - Mazda RX-7 Manuals the euro cars are 90% the same, biggest difference is/are the trim levels.
#4
My wife bought me 2 RX-7s
Join Date: Aug 2001
Location: Saskatoon, Saskatchewan, Canada
Posts: 2,328
Likes: 0
Received 2 Likes
on
2 Posts
Good color choice.
I just did the fan clutch on my 7 and was lucky enough to snag one of the $50 units from Rockauto. I was going to suggest one for you, but they've sold out.
As for the steering, the problem areas are the steering box, as j9fd3s mentioned, but the other major item to check is the idler arm. If the bushings are bad there, you'll have very vague and unresponsive steering. If you do get a nice set of 15 inch rims, don't go with 205/70/15 tires. That's way off the stock circumference and you'll have issues with fender rub and the speedo will be ~15% off. You'd be better off with a 50 section-width tire.
I just did the fan clutch on my 7 and was lucky enough to snag one of the $50 units from Rockauto. I was going to suggest one for you, but they've sold out.
As for the steering, the problem areas are the steering box, as j9fd3s mentioned, but the other major item to check is the idler arm. If the bushings are bad there, you'll have very vague and unresponsive steering. If you do get a nice set of 15 inch rims, don't go with 205/70/15 tires. That's way off the stock circumference and you'll have issues with fender rub and the speedo will be ~15% off. You'd be better off with a 50 section-width tire.
#6
Junior Member
Thread Starter
Join Date: Mar 2014
Location: Belgium
Posts: 20
Likes: 0
Received 0 Likes
on
0 Posts
hi guys,
thx! yeah, I already did the quick and dirty fix with the screw on top, it's not a power steering model so I adjusted the screw counter clock wise to the max but that doesn't change much... The other steering box "fixes" doesn't look easy...
how can I check the idler arm? I hope to get under the car next weekend so any input would be nice.
thx! yeah, I already did the quick and dirty fix with the screw on top, it's not a power steering model so I adjusted the screw counter clock wise to the max but that doesn't change much... The other steering box "fixes" doesn't look easy...
how can I check the idler arm? I hope to get under the car next weekend so any input would be nice.
#7
Junior Member
Thread Starter
Join Date: Mar 2014
Location: Belgium
Posts: 20
Likes: 0
Received 0 Likes
on
0 Posts
Yeah, with my calculations the 205/50/15 would almost be the same height as a 185/70/13...
Trending Topics
#11
Moderator
iTrader: (3)
Join Date: Mar 2001
Location: https://www2.mazda.com/en/100th/
Posts: 30,844
Received 2,605 Likes
on
1,848 Posts
open hood, go to the passenger side (right front wheel), grab steering center link and pull up, if it moves you need an idler arm or the 2 bushings. the bushings are super easy to do, you just loosen the nut on the top and pop em in and out.
#14
Junior Member
Thread Starter
Join Date: Mar 2014
Location: Belgium
Posts: 20
Likes: 0
Received 0 Likes
on
0 Posts
I guess you always like the “exotic stuff” the most… HAHA. If you guys like the rotor rims so much I’m always in for a swap!
Something else. I’ve also read some topics about direct fire ignition, sounds interesting for the future. For starters, I have some MSD blaster II coils laying around so I want to swap them with the old ones. Can I just swap them or do I need to do something else? I’ve read some stories about frying some parts… A nice upgrade because I have them laying around or shouldn’t I bother?
#15
Senior Member
iTrader: (2)
Join Date: May 2013
Location: Los Angeles
Posts: 542
Likes: 0
Received 0 Likes
on
0 Posts
You didn't say how many miles are on the car. If it's high mileage, it's probably the steering box. Sometimes an adjustment works but if the box is too badly worn, you just have to replace it like I did.
#16
Junior Member
Thread Starter
Join Date: Mar 2014
Location: Belgium
Posts: 20
Likes: 0
Received 0 Likes
on
0 Posts
the car has 120,000 km's, so that's app. 75,000 miles on the odometer but I can't verify if that's true... Some parts like the interior suggests it's true, others don't...
#17
Moderator
iTrader: (3)
Join Date: Mar 2001
Location: https://www2.mazda.com/en/100th/
Posts: 30,844
Received 2,605 Likes
on
1,848 Posts
things like the interior are difficult to reproduce
