checkin' the flywheel teeth
12-13-02, 07:18 PM
#1
Senior Member
Thread Starter
Join Date: Mar 2001
Location: -
Posts: 520
Likes: 0
Received 0 Likes
on
0 Posts
checkin' the flywheel teeth
I've been getting an occasional "grinding" noise when I turn the ignition key, and the local Mazda dealership tells me that I need a new starter and a new flywheel, because they both have chipped teeth!
Naturally, I want to confirm this diagnosis, especially since I have an RB 16# steel flywheel and it cost quite a bit about 3 years ago. I want to check the flywheel teeth for damage, and I'd like to know a good way for me (and a buddy) to do this, with the engine in the car. Thanks!
Naturally, I want to confirm this diagnosis, especially since I have an RB 16# steel flywheel and it cost quite a bit about 3 years ago. I want to check the flywheel teeth for damage, and I'd like to know a good way for me (and a buddy) to do this, with the engine in the car. Thanks!
12-13-02, 07:26 PM
#3
roadkill hats rock
Join Date: Jul 2001
Location: Austin, Texas
Posts: 1,396
Likes: 0
Received 0 Likes
on
0 Posts
well you could always take a peak at your starter and if it looks great, dont worry. but its prolly chewed up and if so drop the tranny and take a look at the flywheel. i have the same thing and have gotten the same advice. havent fixed it yet cause im swapping to a TII tranny and will get a new flywheel when i get that.
12-13-02, 07:40 PM
#4
Open up! Search Warrant!
Join Date: May 2002
Location: Kicking down doors in a neighborhood near you
Posts: 3,838
Likes: 0
Received 2 Likes
on
2 Posts
Take the starter off and you will see a few of the flywheel teeth. You can paint one so you will recongnize it again. Next, take a screw driver with a long handle (for leverage) and rotate the flywheel gently and inspect the teeth. Don't crank it fast enough to start the engine. Take the spark plugs out if you want to be extra safe.
12-13-02, 08:04 PM
#5
roadkill hats rock
Join Date: Jul 2001
Location: Austin, Texas
Posts: 1,396
Likes: 0
Received 0 Likes
on
0 Posts
will the screwdriver hurt the fw? i was gonna say look at it and have a buddy turn the motor by hand, but itd be easier to drop the tranny since you are msot likely going to have to change the flywheel anyways doh. and if not you can go ahead and chage your trann fluid
12-13-02, 08:07 PM
#6
I think theres an inspection plate on the top of the engine you can take off and look down in there...Disable the ignition and have someone "bump" it over with the key as you watch it. Then, pull the starter and check the teeth on that. Its easier to do it thisway rather than pulling the whole tranny
.
~T.J.
.~T.J.
Last edited by RotorMotorDriver; 12-13-02 at 08:09 PM.
12-13-02, 08:12 PM
#7
Open up! Search Warrant!
Join Date: May 2002
Location: Kicking down doors in a neighborhood near you
Posts: 3,838
Likes: 0
Received 2 Likes
on
2 Posts
I keep forgetting how low the compression is on rotary engines. A friend could either turn the crank pulley by hand, or put a long breaker bar on the crank pulley bolt and turn it like that. (no the bolt won't come out. They're a bitch to get out) Disable the ignition so it doesn't accidentally start and hurt someone.
Trending Topics
12-13-02, 08:30 PM
#9
roadkill hats rock
Join Date: Jul 2001
Location: Austin, Texas
Posts: 1,396
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by RotorMotorDriver
I think theres an inspection plate on the top of the engine you can take off and look down in there...Disable the ignition and have someone "bump" it over with the key as you watch it. Then, pull the starter and check the teeth on that. Its easier to do it thisway rather than pulling the whole tranny.
~T.J.
I think theres an inspection plate on the top of the engine you can take off and look down in there...Disable the ignition and have someone "bump" it over with the key as you watch it. Then, pull the starter and check the teeth on that. Its easier to do it thisway rather than pulling the whole tranny
.~T.J.
12-13-02, 08:42 PM
#11
now for sale
Join Date: Nov 2001
Location: PDX, OR
Posts: 214
Likes: 0
Received 0 Likes
on
0 Posts
My car does the same thing. When I bought it, the guy told me that the flywheel needed to be repalaced. But upon changing out the clutch, the fly wheel was fine, so my suspissions point to the starter. The problem may be the part that engages the fly wheel doesnt do it fully due to age or somthing. I mean, my car is 20 years old. But if the flywheel were the culprit, then wouldn't the car not ever start if the starter was engaging the bad part of the flywheel? Mine grinds the first time I turn the key, and then it turns over on the second try. Course, it doesn't do it all the time. But starting after gassing up is embarassing sometimes...
12-13-02, 08:43 PM
#12
roadkill hats rock
Join Date: Jul 2001
Location: Austin, Texas
Posts: 1,396
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by faye x7
That picture of your nose get's scarier and scarier...or...whoever's nose that is.
That picture of your nose get's scarier and scarier...or...whoever's nose that is.
hows this one?
Last edited by gamble302; 12-13-02 at 08:46 PM.
12-13-02, 09:02 PM
#15
Nikki-Modder Rex-Rodder
Join Date: Feb 2001
Location: Trying to convince some clown not to put a Holley 600 on his 12a.
Posts: 2,890
Likes: 0
Received 14 Likes
on
6 Posts
T.J.'s right- There'a plate right behind the carb. You can just udo the coils and have someonetry to start it. I think it goes slow enough for you to see the teeth. Surely you'll notice a broken one.
The "broken flywheel teeth" is A BULLSHIT DEAL!!!
Any mechanic saying that as a definite thing and not just a possibility needs a good slap in the head!
The starter teeth are made softer than the flywheel teeth. They do this on purpose so that you won't bust the flywheel ring gear. That's right- It's a big thin ring gear that is heat shrunk onto the flywheel. (...as RotorMotorDriver says- "Ask me how I know!")
To break a tooth off the ring gear would more than likely crack it, and it could come loose from the flywheel - maybe even in pieces...very fast pieces!
You should probably remove the starter and see if the bendix comes all the way out smoothly. Obviously if the teeth are all worn down on the front corners it's time for a new one.
Get your core charge refund.
The "broken flywheel teeth" is A BULLSHIT DEAL!!!
Any mechanic saying that as a definite thing and not just a possibility needs a good slap in the head!
The starter teeth are made softer than the flywheel teeth. They do this on purpose so that you won't bust the flywheel ring gear. That's right- It's a big thin ring gear that is heat shrunk onto the flywheel. (...as RotorMotorDriver says- "Ask me how I know!")
To break a tooth off the ring gear would more than likely crack it, and it could come loose from the flywheel - maybe even in pieces...very fast pieces!
You should probably remove the starter and see if the bendix comes all the way out smoothly. Obviously if the teeth are all worn down on the front corners it's time for a new one.
Get your core charge refund.
12-13-02, 09:06 PM
#17
Senior Member
Thread Starter
Join Date: Mar 2001
Location: -
Posts: 520
Likes: 0
Received 0 Likes
on
0 Posts
[QUOTE] time for a new one hows this one?
Whew.. thank you for pointing the camera UP..
Dana Carvey voice: I think I'm gonna hurl!!!
---
P.S: Thanks, Sterling, I'll check it out.
Where IS that freakin' beer smilie..
Whew.. thank you for pointing the camera UP..
Dana Carvey voice: I think I'm gonna hurl!!!
---
P.S: Thanks, Sterling, I'll check it out.
Where IS that freakin' beer smilie..
Last edited by genrex; 12-13-02 at 09:09 PM.
12-13-02, 09:06 PM
#18
roadkill hats rock
Join Date: Jul 2001
Location: Austin, Texas
Posts: 1,396
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by Wankelguy
LOL, you must have a square-drive screwdriver, then.
LOL, you must have a square-drive screwdriver, then.
good luck keepin me out hehe
now where exactly is that plate?
12-13-02, 09:08 PM
#19
brilliantly stupid
Join Date: Nov 2002
Location: Rockford, IL
Posts: 1,100
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by gamble302
lol its not so bad. i started with the kermit avatar, and it got jacked. so i made this one to poke fun at manntis the ghostly canadian, and im getting jacked again! time for a new one
hows this one?
lol its not so bad. i started with the kermit avatar, and it got jacked. so i made this one to poke fun at manntis the ghostly canadian, and im getting jacked again! time for a new one
hows this one?
12-13-02, 09:10 PM
#20
roadkill hats rock
Join Date: Jul 2001
Location: Austin, Texas
Posts: 1,396
Likes: 0
Received 0 Likes
on
0 Posts
[QUOTE]Originally posted by genrex
see im not as ugly as my av would have you think
and yes im quite good at makin funny faces. and have wicked bed head at 5:30 every single day when i wake up for work
time for a new one hows this one?
Whew.. thank you for pointing the camera UP..
Dana Carvey voice: I think I'm gonna hurl!!!
Whew.. thank you for pointing the camera UP..
Dana Carvey voice: I think I'm gonna hurl!!!
and yes im quite good at makin funny faces. and have wicked bed head at 5:30 every single day when i wake up for work
12-13-02, 09:11 PM
#21
Originally posted by Sterling
T.J.'s right- There'a plate right behind the carb. You can just udo the coils and have someonetry to start it. I think it goes slow enough for you to see the teeth. Surely you'll notice a broken one.
The "broken flywheel teeth" is A BULLSHIT DEAL!!!
Any mechanic saying that as a definite thing and not just a possibility needs a good slap in the head!
The starter teeth are made softer than the flywheel teeth. They do this on purpose so that you won't bust the flywheel ring gear. That's right- It's a big thin ring gear that is heat shrunk onto the flywheel. (...as RotorMotorDriver says- "Ask me how I know!")
To break a tooth off the ring gear would more than likely crack it, and it could come loose from the flywheel - maybe even in pieces...very fast pieces!
You should probably remove the starter and see if the bendix comes all the way out smoothly. Obviously if the teeth are all worn down on the front corners it's time for a new one.
Get your core charge refund.
T.J.'s right- There'a plate right behind the carb. You can just udo the coils and have someonetry to start it. I think it goes slow enough for you to see the teeth. Surely you'll notice a broken one.
The "broken flywheel teeth" is A BULLSHIT DEAL!!!
Any mechanic saying that as a definite thing and not just a possibility needs a good slap in the head!
The starter teeth are made softer than the flywheel teeth. They do this on purpose so that you won't bust the flywheel ring gear. That's right- It's a big thin ring gear that is heat shrunk onto the flywheel. (...as RotorMotorDriver says- "Ask me how I know!")
To break a tooth off the ring gear would more than likely crack it, and it could come loose from the flywheel - maybe even in pieces...very fast pieces!
You should probably remove the starter and see if the bendix comes all the way out smoothly. Obviously if the teeth are all worn down on the front corners it's time for a new one.
Get your core charge refund.
Very well put!
My compliments on the thoughtfulness of your post.
I'm also glad someone finally said the "broken teeth" scenario was B.S.
The dealerships totally suck, our local dealership doesn't know squat about rotaries, they don't even work on 'em anymore!
12-13-02, 10:56 PM
#22
Open up! Search Warrant!
Join Date: May 2002
Location: Kicking down doors in a neighborhood near you
Posts: 3,838
Likes: 0
Received 2 Likes
on
2 Posts
I worked with a guy who hit an unseen speed bump last summer with a 1970+ Vega, causing it to bottom out. Somehow, he busted some teeth off the flywheel(so he says). Once in a while, the starter had no teeth to engage, so he had to put it in gear and push the car forward so the flywheel would rotate.
J/K
J/K
12-14-02, 12:13 AM
#23
Nikki-Modder Rex-Rodder
Join Date: Feb 2001
Location: Trying to convince some clown not to put a Holley 600 on his 12a.
Posts: 2,890
Likes: 0
Received 14 Likes
on
6 Posts
...It most certainly can happen, and I've heard a story or two. But seems like everytime I hear what a mechanic has to say, it's always that the flywheel needs to be replaced.
"...And uh, while we'll have take your tranny out anyway, how old is yer clutch?"
"...And uh, while we'll have take your tranny out anyway, how old is yer clutch?"
