Mystery switch
So I'v had this switch in my car since day one, it's under my steering wheel to the right and flips up and down with FIVE wires running to my radio, three of witch then run back out under my carpet ( brown-yellow and white. I did some digging ( literally pulled up the carpet ) and found the cables rand own the center to the rear of my car next to this box tucked away under the rear-wheel plastic cover along with a bunch of cables. The 3 wires end at a 3 point connection and are tied with a zip tie to the modulator box but is not actually connected to it. It seems my antenna isn't even plugged in and cut (which explains why my radio sounds like dog **** and the modulator box has two cables running out of it that are not plugged into anything.
The plug at the end of the 3 colored wires that are hardwired into my radio looks like this .
for now it seems I have no antenna and the modulator box is just chilling back there not plugged into anything .
The plug at the end of the 3 colored wires that are hardwired into my radio looks like this .
for now it seems I have no antenna and the modulator box is just chilling back there not plugged into anything .
