Silverfc88

iTrader: (7)

Went to the Junkyard looking for ball studs for a custom job that I wanted to do and I was looking around at all of the Crown Vics and Taurus's laying around. I happen to glance to the side and see this 89 Lincoln Mark VII, so I look at the wheels and sure enough it has the meshies on it! I have been looking around for these for a couple of years and most Crown Vics/Grand Marquies and early Marks have the wheels taken already.



The wheels are in decent shape. Took me some time to take them off the car with the wheel locks on them. The fronts came off ok, but the rears wouldn't budge. So one of the guys working at the yard moved the car with a loader to the garage and we torched the wheel locks off. You can see the burn marks left from the torch in the pics, but there was no damage to the wheels.



These are basically my before pics. I'll update as I refinish them.


The wheels are 16x7 5x114.3 and they look to be around a +20 offset. The only problem I have with them right now is that the front calipers rub on the wheels. If I put on a small spacer they don't rub at all. It only rubs on this little nub that is sticking out of caliper. I think if I grind down that nub it should be ok without the spacers. The wheels look to be very close to the fender so I want to avoid spacers.



Straight from the junkyard. They need alot of work!









And my buddy just messing around.



All center caps. I'm think about sending one out to see if someone can cut me out a piece from aluminum to replace the faded rubber stickers.




After a few minutes of cleaning and short section that I decided to strip the old clear from the lip just to see what was underneath.

Silverfc88

iTrader: (7)

Got three done and I think they came out pretty good. I got some of the curb marks off, but my hands would start to hurt real bad so I just kinda gave up on a couple of them. I had to use a file on one of them it was curbed so bad. I just gotta stop being lazy and get the fourth one done.














This was over a time span of about a month.

SpeedKing

iTrader: (4)

aznpoopy

nice job

HeyITZthatFC

the end products are fkin sick dude.

Silverfc88

iTrader: (7)

Thanks




I forgot to edit it out of my post, but DO NOT grind down the nub on the front calipers. There is a cavity behind it and you will loose your brake fluid!

Rotary_Powerd

You have given me the inspiration to do the same to my Phone Dials I bought! your wheels looks sick!

How did you strip them clean like that, could you list some of your procedures? They look great!

Spirit Rx-7

iTrader: (15)

did you use aircraft remover to strip the clear? nice wheels

Silverfc88

iTrader: (7)

Yep, thats the best stuff to use. I've used that Zipp stuff or whatever its called and its more work than aircraft remover.





I copied this from someplace else, but is the basic steps I took to repolish the wheels. I posted some of my steps in addition. If the stock wheels are powder coated. Then it might be easier just to sand the whole thing and repaint with some wheel paint.


1 can of Aircraft Remover
1 pkg of 220-320 grit sandpaper
1 pkg of 400 grit sandpaper
1 pkg 600 grit sandpaper
1 pkg of 800 grit sandpaper
1 pkg of 1000 -1500 grit sandpaper
1 pkg of 2000 grit sandpaper
1 tin of NEVR DULL
1 tin of Mothers Billet Polish
1 pkg of microfiber cloths
1 roll of painters masking tape.

The total cost of all this weighs in around 50 bucks. But to get all your wheels polished out will run you upwards of 100 bucks per wheel!

Step 1:

Mask off the wheel lip. You DO NOT want any of the Aircraft Stripper to touch your painted wheel surface. It takes less than a minute to remove paint from a metal surface. So mask off this section well. You only want to apply stripper to the lip of the wheel. If your repainting the centers then I don't think it really matters if you tape of the lip.


Step 2:

Using a paintbrush approved for chemicals (can be picked up from Home Depot for like 2 bucks.) Spread a light coat of Aircraft Remover onto the wheel lip. YOU DO NOT WANT THIS STUFF TO DRIP. And whatever you do, don't get this on your skin. I recommend some chemical gloves. Once you have applied this stuff to the wheel lip, let it sit for a good half hour. I know it may look like it is done after the first minute or two, but you really want the clear coat to release from the metal.

Step 3:

Remove as much of the crusty stuff from the lip as you can with a piece of steel wool or a rag that you don't care about. Then roll the wheel out back and spray it off with the hose. You want to get all that crap off of there. If there is any clear coat left on the lip, you may need to re apply the stripper to it again.

Step 4:

Get a cup of water handy. Take a piece of that 400 grit paper and tear it off. You want about a 1"X1" piece. Splash a bit of water in the area of the wheel lip that you plan on starting with. Then dip your sand paper in the water and start sanding the lip. You want nice long strokes. The 400 grit should be enough to remove any surface imperfections. If you see dents that aren't coming out, try picking up a pack of 320 grit. You don't want to go too low though as you may not be able to remove the grooves that the sand paper leaves behind. Continue dipping and sanding with 400 grit as needed until the entire lip has been sanded. It is important to sand every inch of the lip to ensure uniformity of the finished product. I use bigger strips of sandpaper like 2x2


Step 5:

Wipe off the residues from the 400 grit paper. In fact, every time you step to a finer grit paper, you want to clean the surface with that "ruined" towel. The deposits from the 400 paper can cause lines when sanding with the 800 paper. Do the same as before with the 800 paper...lots of water, lots of long sweeping sanding motion. I don't even bother with the towel, I just rinse the whole wheel in between each step of sanding.


Step 6:

Repeat with 1000 grit paper, then the 2000 grit paper. You are almost done!!!

Step 7:

Ok, so you have wet sanded the lip with the 2000 grit paper, and wiped off the residue. It is lookin' pretty good at this point. Kinda dull, but smooth. Open that can of NEVR-Dull. Rip a chunk of the wadding off and start rubbing the surface of that wheel. This is the point when elbow grease will pay off. The same black residue will continue to show up here. Make sure to hit the entire surface with the NEVR-DULL cotton thingy. THen throw it the fock away...I hate it when I find dirty wadding in the NEVRDULL can. Let the residue dry to a haze then buff it off with a towel. I just skip to the Mothers polish step. The Mothers mag polish is the ****!

Step 8:

Right now you are looking at your wheel lip saying, "damn, can it get any better?" YES, it can and it will. Pull out one of those microfiber towels. Wrap it over your finger and open that Mothers polish I told you to buy. Put just a dab on the end of the 'towel finger.' You don't need much and you don't want to slop this stuff everywhere because it isn't cheap. Just like with the Nevr-Dull, start buffing. The more you buff, the better the lip will turn out. Keep buffing and don't let the polishing compound dry up until you have polished the entire wheel. Once you have polished the entire lip surface, let it dry for a second or two. Then buff it off with a clean section of the micro fiber towel.

Step 9:

Seriously, your wheel lip will look better than when you bought it. Most performance wheel manufacturers do not polish their lips to this level. It is MIRROR finished. Truely stunning.
You now have two options. YOu can either
1.) Wax the lip with a cream wax (NOT the spray stuff)
2.) Clearcoat the lip. I recommend Dupli-Color wheel coatings.
Before you spray it down with clear coat, make sure to wipe that lip clean with some windex. You don't want anything to keep the clearcoat from adhering. If you don't clearcoat it or wax it, it WILL corrode.
I usually just use the spray wax stuff and I've never had a problem with it and I repolish every once in a while. You really have to neglect your wheels to have them corrode I think.

consrx7

Those Wheels Look Niceeeeeeeee.. How Much Did U Pay For The Wheels??

streetRx7

iTrader: (5)

great job.....looking really good..... before an after.....WOW.....don't even look like same rims...

jimlab

Wow, it's rare that I'm impressed by much on this forum, but you really did a first class job on refurbishing those wheels. I started chuckling when I saw the first picture of your junkyard "find", and stopped when I got to the second post. Nice job.

Sort of like the thread on AVS Forum where the guy starts off talking about building his own home theater in his garage...



And ends up with this.

aznpoopy

holy crap... that's some awesome work too

jimlab

No doubt, and he turned his research on acoustically transparent screen material into a full time job selling pre-made screens.

http://www.smxscreen.com/

Apparently he used to be a **** photographer.

RX7UP

95nracer:

Great Job!

Dwayne

owen is fat

so do they fit or what?
I thought those didnt fit well up front or looked way goofy sticking out, cant remember.

nice find btw and yeah man they look GREAT!

KhanArtisT

iTrader: (2)

god daaayum!! they look money!

Healing

So how much did you buy these for?

Silverfc88

iTrader: (7)

Just from the test fit in the front it "should" fit. I'm going to throw some tires (205-55R16 Blizzaks) on two of them and test the front and rear. I'll get some pics on fitment.


Thanks for the compliments!



I don't want to say the exact amount just in case I want to sell them down the road, but they where cheap enough.

Narfle

iTrader: (16)

People would sell organs to have wheels so nicely refurbished. I dont see why anyone would think they were write offs in the first pic; they're just really dirty. But, they were in pretty primo condition(no bends i can see). You did a great job cleaning, polishing, and painting them. Really great work and quite a find, too!

forced inducted fd dude

im working on getting these

willub and company

iTrader: (3)

Man! I'm gonna have to jack the rims off my grandmothers towncar!

slo

iTrader: (1)

how much do they weigh?

13btII

i'd really like to know how the fitment is. very nice job!

Silverfc88

iTrader: (7)

I'm finally done with the last wheel and also did the center caps.


I tried my best with the center caps and I even tried to polish the clear rubber that is on the BBS. They came out pretty good.









I'll be getting some wheels weights later. I don't have a scale in the house. Next will be to get the tires mounted.
