Pineapple racing oil pan
#1
Rotary Freak
Thread Starter
Join Date: Nov 2001
Location: trinidad and tobago
Posts: 2,715
Likes: 0
Received 0 Likes
on
0 Posts
Pineapple racing oil pan
Hi all , If any of you intend to use one of these pans in your build like I did , make sure and check it for leaks BEFORE installation ! I found out the hard way that their casting process is flawed ! I have identified two leaks ! once the sump is filled up oil streams from under the car even if the motor isnt running or if its just parked (for days sometimes) . Now I have to drop the cross member to pull it for repairs.
#6
Rotary Freak
Thread Starter
Join Date: Nov 2001
Location: trinidad and tobago
Posts: 2,715
Likes: 0
Received 0 Likes
on
0 Posts
Yes I used silicone and the o ring , but the oil is actually seeping through the wall at the two points . It cannot be fixed on the car it has to be removed . It would be a great product though if the QC was better.
Trending Topics
#10
Original Gangster/Rotary!
iTrader: (213)
We had a customer's pan leak from the back middle portion of the pan wall. Not sure where it was sourced from, Pineapple/Groundzero/Xcessive. Seemed to be a porous casting...... this was back in 2006. Personally the lack of an oil level sending unit makes the unit undesirable to me for a street car. My FD is modded pretty damn heavily and still rockin' the oem oil pan. No leaks either
#11
Rotary Freak
Thread Starter
Join Date: Nov 2001
Location: trinidad and tobago
Posts: 2,715
Likes: 0
Received 0 Likes
on
0 Posts
We had a customer's pan leak from the back middle portion of the pan wall. Not sure where it was sourced from, Pineapple/Groundzero/Xcessive. Seemed to be a porous casting...... this was back in 2006. Personally the lack of an oil level sending unit makes the unit undesirable to me for a street car. My FD is modded pretty damn heavily and still rockin' the oem oil pan. No leaks either
#12
Original Gangster/Rotary!
iTrader: (213)
Are there midgets under your FD pressing on the bottom of the pan ?
On a serious note, you could always pick up a new oem oil pan if yours is damaged. They're not very much, relatively speaking anyway.
#13
Rotary Freak
Thread Starter
Join Date: Nov 2001
Location: trinidad and tobago
Posts: 2,715
Likes: 0
Received 0 Likes
on
0 Posts
Either way I will have to drop the front cross member to remove the oil pan , I'll just have the leaks repaired (welded) and replace the pan.
#16
Rotary Freak
Thread Starter
Join Date: Nov 2001
Location: trinidad and tobago
Posts: 2,715
Likes: 0
Received 0 Likes
on
0 Posts
It's not a crack , it looks like it was a bubble .Seems like when the aluminum was poured there were bubbles in there that remained there until the aluminum cooled and herdened in the mold.This would then leave a spece for the oil to pass through. The repair for this is to gouge out the space and have it refilled with TIG aluminum welding. If it were a crack the repair procedure would be the same.
#17
Rotary Freak
Thread Starter
Join Date: Nov 2001
Location: trinidad and tobago
Posts: 2,715
Likes: 0
Received 0 Likes
on
0 Posts
#18
NYC's Loudest FD
I've been using this pan for about 35k miles here in NYC and I've never had any leaks or problems with this pan or the LIM that they sell, just my 2 cents.
#21
Rotary Freak
Thread Starter
Join Date: Nov 2001
Location: trinidad and tobago
Posts: 2,715
Likes: 0
Received 0 Likes
on
0 Posts
Had another oil leak , this time it's one of my MOCAL 25 row oil coolers ! there really is no substitute for the OEM stuff when it comes to reliability!
#23
Rotor Head Extreme
iTrader: (8)
True about the vacuum hoses but in Mazda's defense, I guess they never factored the engine running so hot and prematurely deteriorating the hoses so fast. I know Mazda had some service bulletins and completley replaced vacuum hoses in several vehicles under warranty. Mine was one of them. I never had vacuum problems when I bought mine. But anyways, since were talking oil system, the OEM oil system is nearly bullet proof.
#24
Back door, no babies...
iTrader: (14)
We had a customer's pan leak from the back middle portion of the pan wall. Not sure where it was sourced from, Pineapple/Groundzero/Xcessive. Seemed to be a porous casting...... this was back in 2006. Personally the lack of an oil level sending unit makes the unit undesirable to me for a street car. My FD is modded pretty damn heavily and still rockin' the oem oil pan. No leaks either
http://www.xcessivemanufacturing.com...l?pid=8&step=2
#25
Bibliophile
iTrader: (1)
Join Date: Dec 2005
Location: Anaheim California
Posts: 136
Likes: 0
Received 0 Likes
on
0 Posts
I had my pineapple pan installed four years ago and tried several different options to create a better seal after discovering a crack straight from factory, eventually I ended up just going back to stock
