Single Turbo RX-7's Questions about all aspects of single turbo setups.

BorgWarner EFR 8374 IWG Dyno Results

Old 03-28-15, 08:41 PM
  #51
Full Member

Join Date: Jun 2010
Location: Bristol, U.K
Posts: 58
Likes: 0
Recieved 1 Like on 1 Post
Originally Posted by lOOkatme View Post
at sea level the EFR8374 turbo is tough to beat. I like the IWG version.

I would run this, even at altitude I like the EFR8374. the 7670 is also a great option if you do more autox, tight circuit stuff. the efr8374 is like the michael jordan of basketball. He has a good vert, he can dribble, can shoot, has hands the size of a gigantic person, and knows the game. the efr7670 is more like a point guard who isn't as tall but can do almost all the same stuff (isiah thomas?).
Looking at the data from turblown...the 8374 def looks like the better midrange/high rpm turbo.....big plus point is the lower egt's and Spools almost as fast as the 7670.

lmao.....
rx7srbad is offline
Old 03-29-15, 10:45 AM
  #52
Senior Member

Marf's Avatar

Join Date: May 2013
Location: Sussex, UK
Posts: 300
Likes: 0
Recieved 0 Likes on 0 Posts
Where are the EGT number comparisons. Missed those.

Very tempted by the 7670 IWG 0.92 as my car is 90% road, but with the potential of more track work the 8374 1.04 EWG does appeal too, despite the additional expense of the EWG setup.
Marf is offline
Old 03-30-15, 12:30 AM
  #53
3-Rotor madness

Join Date: Jun 2004
Location: sweden
Posts: 391
Likes: 0
Recieved 1 Like on 1 Post
How would the turbo work on a 20b roadrace car? My rules states 600rwhp as a maximum so this would be perfect, but how would the backpreassure be? External gate is a must ofc. ....why dont anyone sell 8374/9180 hybrids :-(
rx7jocke is offline
Old 03-30-15, 12:35 PM
  #54
Adaptronic Distributor
RX7Club Vendor
Thread Starter
iTrader: (12)

Turblown's Avatar

Join Date: Dec 2001
Location: Twin Cities, MN
Posts: 6,869
Recieved 21 Likes on 19 Posts
Originally Posted by Marf View Post
Where are the EGT number comparisons. Missed those.

Very tempted by the 7670 IWG 0.92 as my car is 90% road, but with the potential of more track work the 8374 1.04 EWG does appeal too, despite the additional expense of the EWG setup.
I do not think anyone has done that yet. 99% of the kits we sells are the 8374.

As soon as the engine is back together on our roadcourse car I am doing an entire dyno comparison days( back to back tests between 7670, 8374, 9180, iwg vs ewg, shortly vs long etc). I have all of the turbos, and manifolds finished sitting here ready for it.

Rotors are on their way back from balancing on the engine...
__________________
Rx7 Rotary Performance Parts
Turblown is offline
Old 03-30-15, 12:36 PM
  #55
Adaptronic Distributor
RX7Club Vendor
Thread Starter
iTrader: (12)

Turblown's Avatar

Join Date: Dec 2001
Location: Twin Cities, MN
Posts: 6,869
Recieved 21 Likes on 19 Posts
Originally Posted by rx7jocke View Post
How would the turbo work on a 20b roadrace car? My rules states 600rwhp as a maximum so this would be perfect, but how would the backpreassure be? External gate is a must ofc. ....why dont anyone sell 8374/9180 hybrids :-(
On a 20B I would just run a 9180( with the 3" vband inlet option we carry).

No reason to run a 8374 mated to a 90mm turbine wheel found in the 9180....
__________________
Rx7 Rotary Performance Parts
Turblown is offline
Old 03-30-15, 02:08 PM
  #56
B O R I C U A
iTrader: (14)

KNONFS's Avatar

Join Date: Mar 2001
Location: VA
Posts: 5,360
Recieved 8 Likes on 8 Posts
Originally Posted by Turblown View Post
As soon as the engine is back together on our roadcourse car I am doing an entire dyno comparison days( back to back tests between 7670, 8374, 9180, iwg vs ewg, shortly vs long etc). I have all of the turbos, and manifolds finished sitting here ready for it.

Rotors are on their way back from balancing on the engine...
KNONFS is offline
Old 03-30-15, 02:49 PM
  #57
3-Rotor madness

Join Date: Jun 2004
Location: sweden
Posts: 391
Likes: 0
Recieved 1 Like on 1 Post
I would use a 9180 if the rules allowed me....do you think the 8374 is to small for 500-550 hp on a 20b? Will it choke to death by backpressure?
rx7jocke is offline
Old 03-30-15, 04:46 PM
  #58
Full Member

Join Date: Aug 2009
Location: Phoenix, AZ
Posts: 90
Likes: 0
Recieved 0 Likes on 0 Posts
Originally Posted by rx7jocke View Post
I would use a 9180 if the rules allowed me....do you think the 8374 is to small for 500-550 hp on a 20b? Will it choke to death by backpressure?
if you are restricted on compressor inducer to an EFR8374, my suggestion would be the 1.45 a/r. that is an outstanding combination. invest in a turbo shaft speed sensor.

Originally Posted by Turblown View Post
No reason to run a 8374 mated to a 90mm turbine wheel found in the 9180....
agreed 100%. the fact is a larger turbine wheel :compressor wheel ratio will increase turbo shaft speed for a given boost level, not worth the tradeoff when you have the 1.45 a/r available

Originally Posted by Turblown View Post
99% of the kits we sells are the 8374
you and me both! EFR 8374 is *that* good. I pulled my 8374 off my evo, to try some other turbos.. but now I think its going back on.
Full-Race Geoff is offline
Old 03-31-15, 11:11 AM
  #59
Senior Member

Marf's Avatar

Join Date: May 2013
Location: Sussex, UK
Posts: 300
Likes: 0
Recieved 0 Likes on 0 Posts
Originally Posted by Turblown View Post
I do not think anyone has done that yet. 99% of the kits we sells are the 8374.

As soon as the engine is back together on our roadcourse car I am doing an entire dyno comparison days( back to back tests between 7670, 8374, 9180, iwg vs ewg, shortly vs long etc). I have all of the turbos, and manifolds finished sitting here ready for it.

Rotors are on their way back from balancing on the engine...
Brilliant, look forward to that comparison
Marf is offline
Old 04-01-15, 02:31 PM
  #60
Time or Money, Pick one
iTrader: (31)

silverTRD's Avatar

Join Date: Oct 2005
Location: Torrance, ca.
Posts: 2,715
Likes: 0
Recieved 14 Likes on 14 Posts
What could one expect with a similar setup but pump gas 91 with water/meth injection instead of e85?

Also, what's the reason behind the 1.5" runners on the manifold? Is the larger 2" just not needed? Just wondering.
silverTRD is offline
Old 04-05-15, 05:28 PM
  #61
Rotary Freak
iTrader: (3)

Jay7 Nyc's Avatar

Join Date: Feb 2004
Location: NYC - SFL
Posts: 1,696
Likes: 0
Recieved 0 Likes on 0 Posts
Interested to see what results Turblown is able to achieve.
Jay7 Nyc is offline
Old 04-08-15, 05:38 PM
  #62
Rotary Freak
iTrader: (8)

rx72c's Avatar

Join Date: Jun 2003
Location: Australia
Posts: 2,608
Likes: 0
Recieved 0 Likes on 0 Posts
I will have a GTX4202 vs EFR9180 with 1.45 rear comparison coming soon.
Back to back on the same car.
Just sorting out some issues with the car so hopefully not long.
rx72c is online now
Old 04-19-15, 02:38 PM
  #63
Full Member

Join Date: Jun 2010
Location: Bristol, U.K
Posts: 58
Likes: 0
Recieved 1 Like on 1 Post
any updates?
rx7srbad is offline
Old 04-19-15, 11:49 PM
  #64
Rotary Enthusiast

Havoc's Avatar

Join Date: Aug 2004
Location: Australia - Perth
Posts: 1,316
Recieved 7 Likes on 6 Posts
yes, go look at the raceonly facebook page.

Awesome result!
Havoc is offline
Old 04-20-15, 04:07 AM
  #65
Full Member

Join Date: Jun 2010
Location: Bristol, U.K
Posts: 58
Likes: 0
Recieved 1 Like on 1 Post
Originally Posted by Turblown View Post
515rwhp was the max recorded. We have a ported motor going in now, and we will be testing all 3 turbochargers back to back( 7670/8374/9180 IWG). I have all the turbochargers here ready to go.

Turblown EFR IWG 8374 Turbo System Testing - YouTube

Turblown EFR IWG 8374 Roll Racing - YouTube
Sorry should have been more specific....any updates/results on the above turbos being tested on the ported motor?
rx7srbad is offline
Old 04-20-15, 08:32 AM
  #66
Full Member
5 Year Member

Join Date: Oct 2009
Location: Scottsdale, AZ
Posts: 85
Likes: 0
Recieved 0 Likes on 0 Posts
Wow, I was 100% on the 7670... but the 8374 is interesting. I'd like to know what's the power you can get from each on 91 octane, subscribing to this for dyno shootout!
Haraise is offline
Old 04-20-15, 07:36 PM
  #67
Adaptronic Distributor
RX7Club Vendor
Thread Starter
iTrader: (12)

Turblown's Avatar

Join Date: Dec 2001
Location: Twin Cities, MN
Posts: 6,869
Recieved 21 Likes on 19 Posts
I didn't tune this one, it was on a PFC in England(FD3S chassis)

7670 IWG @ 1.1 bar, pump gas, stock ports, stock ignition( 9s), 3" exhaust, vmount, bosch 044 etc..
Attached Thumbnails BorgWarner EFR 8374 IWG Dyno Results-efriwg7670fc3s-1.1bar.jpg
__________________
Rx7 Rotary Performance Parts
Turblown is offline
Old 04-20-15, 09:08 PM
  #68
Full Member
5 Year Member

Join Date: Oct 2009
Location: Scottsdale, AZ
Posts: 85
Likes: 0
Recieved 0 Likes on 0 Posts
Whoa, 400 whp on pump? Have you seen that with the 7670 in the states? On 91 octane?
Haraise is offline
Old 04-21-15, 08:35 PM
  #69
Adaptronic Distributor
RX7Club Vendor
Thread Starter
iTrader: (12)

Turblown's Avatar

Join Date: Dec 2001
Location: Twin Cities, MN
Posts: 6,869
Recieved 21 Likes on 19 Posts
I have made 440rwhp on the airwerks 7670 on pump only(22psi).
Turblown is offline
Old 04-22-15, 03:04 AM
  #70
Full Member

wangracing's Avatar

Join Date: Nov 2011
Location: Perth, Australia
Posts: 86
Likes: 0
Recieved 0 Likes on 0 Posts
Am running the 8374 with 1.05 hot side fully divided short manifold and twin external gates on my mildly ported 13BREW. Is running E85 fuel. Was chasing area under the curve and response as opposed to peak number as it is a tarmac rally car. Car is running 20psi, is hitting that at approx 3200 rpm and making 442 ATW. Am very happy with the results. Great initial spool up and power, epic midrange and top end and great transient response on and off the throttle. Spool is just always there. The minute you breathe on the throttle its making boost.

I would have considered the IWG for simplicity but they were an unknown quantity as to whether the internal gate could cope with rotary flow when we were at that stage of the build so we erred on the side of caution with the ext gate setup.

Name:  image-1.jpg
Views: 3420
Size:  45.8 KB

Name:  IMG_0664.jpg
Views: 3506
Size:  74.2 KB
wangracing is offline
Old 04-22-15, 03:50 AM
  #71
Rotary Enthusiast

Havoc's Avatar

Join Date: Aug 2004
Location: Australia - Perth
Posts: 1,316
Recieved 7 Likes on 6 Posts
great result Blaise, would love to see the back to back reference to the Tdx61 as well you had
Havoc is offline
Old 04-22-15, 03:54 AM
  #72
Rotary Enthusiast

Havoc's Avatar

Join Date: Aug 2004
Location: Australia - Perth
Posts: 1,316
Recieved 7 Likes on 6 Posts
Also what gearing are you running? Or did you stop at 6K rpm?
Havoc is offline
Old 04-22-15, 03:55 AM
  #73
Full Member

wangracing's Avatar

Join Date: Nov 2011
Location: Perth, Australia
Posts: 86
Likes: 0
Recieved 0 Likes on 0 Posts
Unfortunately never actually ran the tdx61r. Made the manifold and everything but once I saw the reports of what the EFR was doing I gambled on it being the best way forward. Would definitely be interesting to see how the TDX61 stacks up though.
wangracing is offline
Old 04-22-15, 05:53 AM
  #74
Enthusiast
iTrader: (5)

rx7 SE's Avatar

Join Date: Aug 2004
Location: Charlotte, NC
Posts: 2,180
Likes: 0
Recieved 1 Like on 1 Post
Originally Posted by wangracing View Post



What is the rpm spread in this graph above? The torque curve looks excellent! All these efr threads are making want to ditch the 6266 .
rx7 SE is offline
Old 04-22-15, 07:29 AM
  #75
B O R I C U A
iTrader: (14)

KNONFS's Avatar

Join Date: Mar 2001
Location: VA
Posts: 5,360
Recieved 8 Likes on 8 Posts
Originally Posted by wangracing View Post
Unfortunately never actually ran the tdx61r. Made the manifold and everything but once I saw the reports of what the EFR was doing I gambled on it being the best way forward. Would definitely be interesting to see how the TDX61 stacks up though.
Would love to know how the TDX61 stacks up! I've been dreaming of a TDX61 on my FC for like 2 years now
KNONFS is offline
