FC3S: Panspeed Style Drop Vented Hood
03-26-12, 07:19 PM
#251
Dude your in Japan, go out and buy the real thing from Pan Speed, Garage Kagotani or the FORESIGHT Racing hood. Be alot cheaper. For us State side this is the route to go if you can get a hold of Them at Shine Auto.... I've been trying to get one of these hoods now for awhile, I'm about to order up on of the 3 hoods from RHD Japan if they don't get back to me soon.
03-28-12, 12:53 PM
#253
There were no survivors
Dude your in Japan, go out and buy the real thing from Pan Speed, Garage Kagotani or the FORESIGHT Racing hood. Be alot cheaper. For us State side this is the route to go if you can get a hold of Them at Shine Auto.... I've been trying to get one of these hoods now for awhile, I'm about to order up on of the 3 hoods from RHD Japan if they don't get back to me soon.
07-31-12, 01:55 AM
#254
If you are having a problem getting the hood to latch down, grind down the diameter of rod on the latch. The main problem is the thickness of the rod on the latch. We can't seem to source Japanese (metric) sized latches or at least the size Mazda used for the FC. We use a rod size for the latch that is close, but slightly bigger. Grinding it down should help.
07-31-12, 01:55 AM
#255
If you are having a problem getting the hood to latch down, grind down the diameter of the rod on the latch. The main problem is the thickness of the rod. We can't seem to source Japanese (metric) sized latches or at least the size Mazda used for the FC. We use a rod size for the latch that is close, but slightly bigger. Grinding it down should help.
Ken
Ken
09-05-12, 05:52 AM
#257
Check out aerocatch hood pins. Very high quality.
I assume the frp one will be similar since half the carbon fiber hood is frp anyways.
02-21-14, 07:53 AM
#270
Rotary Enthusiast
Join Date: May 2005
Location: bartlett IL
Posts: 919
Likes: 0
Received 0 Likes
on
0 Posts
I have what is probably the last untouched virgin new from the factory never installed, drilled or even come near a car panspeed hood on the planet. If anyone is interested in the real thing let me know.
The following users liked this post:
rotary#10 (11-08-18)
11-08-18, 09:40 AM
#275
From my own experience with this hood.
This hood works well if you have an efan and s4 radiator. Zero clearance issues.
It also works with S5 radiator but you have to trim out a small area for the fill in neck.
Not really compatible with stock fan shroud.
Ducting the radiator to the hood opening will release alot of hot air after the coolers exchange.
Fitment was good when I purchased it years ago.
This hood works well if you have an efan and s4 radiator. Zero clearance issues.
It also works with S5 radiator but you have to trim out a small area for the fill in neck.
Not really compatible with stock fan shroud.
Ducting the radiator to the hood opening will release alot of hot air after the coolers exchange.
Fitment was good when I purchased it years ago.
