Mill RX8 rotors for 3MM RX7 apex seals?
#26
Moderator
iTrader: (3)
i never said it made sense to me. i just said i read it somewhere, and now i guess it wasn't you that said it. i have NOT had the chance to work with Renesis parts yet, so i'm relying solely on what info i can get from others until i can do my own stuff. all i can say is whomever it was that said it, was someone that i felt to be credible or else it would have just washed in one ear and out the other.
#28
i never said it made sense to me. i just said i read it somewhere, and now i guess it wasn't you that said it. i have NOT had the chance to work with Renesis parts yet, so i'm relying solely on what info i can get from others until i can do my own stuff. all i can say is whomever it was that said it, was someone that i felt to be credible or else it would have just washed in one ear and out the other.
The oil scraper does not stop compression leakage from one chamber/side/face etc. to the other. Also most have found this oil scraper to produce extra abnormal housing ware in a very short time when applied to the pre-renesis housings. I have not personaly tested that claim.
Mazda states it's there to reduce blowby from the exhaust to the intake port. I believe it's there to protect the second oil seal/o-ring from the exhaust heat due to the position of the exhaust port and also from combustion temperature/heat due to excessive leakage from the new side seal design.
#29
Moderator
iTrader: (3)
okay, i just spent a few minutes searching and came up with bupkiss. i spazz out from time to time, and misinterpret new information at times, but i can't shake the memory of seeing it somewhere. however, i'll chalk it up to my own psychosis and drop it as misinformation and a mistake on my part. it's already taken up way too much time in this thread. as i said, it didn't make sense, but whatever. i did find that you were the one that mentioned the thing about the excess housing wear though, so my memory 50% good. maybe too much rum?
This Thread
EDIT: yeah you were responding while i was writing this.
This Thread
EDIT: yeah you were responding while i was writing this.
#32
'Top Secret' is a shop from Japan.
Have no clue why you thought I had any relationship with that shop.
The casting on the renesis rotor is so thin I wonder if it's any stronger than the previous S5/6 rotors? I really don't believe those rotors were meant for anything with the word horsepower in the same sentence.
Only time will tell.
Have no clue why you thought I had any relationship with that shop.
The casting on the renesis rotor is so thin I wonder if it's any stronger than the previous S5/6 rotors? I really don't believe those rotors were meant for anything with the word horsepower in the same sentence.
Only time will tell.
#34
Banned. I got OWNED!!!
your right again!
ive seen alot of renesis rotor failures due to the thin casting cracking, leading to bearing failure.. (there is a really thin spot next to the bearing that prone to cracking)
this i why i would NEVER use these rotors in a boosted application where there is alot more load on the rotors..
#35
Yeh you will get better conmpression one way but not the important way!!
When I see a renesis rotor make more power than a 9.7 rotor then I wil beleive it. Gauge compression is not improtant to me. That does not make power.
I know what's the difference between long vs short side seals and using the oil scraper vs not power wise of which it still is not higher that the non renesis rotor.
When I see a renesis rotor make more power than a 9.7 rotor then I wil beleive it. Gauge compression is not improtant to me. That does not make power.
I know what's the difference between long vs short side seals and using the oil scraper vs not power wise of which it still is not higher that the non renesis rotor.
Last edited by crispeed; 01-18-08 at 01:56 PM.
#36
your right again!
ive seen alot of renesis rotor failures due to the thin casting cracking, leading to bearing failure.. (there is a really thin spot next to the bearing that prone to cracking)
this i why i would NEVER use these rotors in a boosted application where there is alot more load on the rotors..
ive seen alot of renesis rotor failures due to the thin casting cracking, leading to bearing failure.. (there is a really thin spot next to the bearing that prone to cracking)
this i why i would NEVER use these rotors in a boosted application where there is alot more load on the rotors..
#37
Speed Mach Go Go Go
Thread Starter
iTrader: (2)
Join Date: Oct 2001
Location: My 350Z Roadster kicks my RX7's butt
Posts: 4,772
Likes: 0
Received 2 Likes
on
2 Posts
ive seen alot of renesis rotor failures due to the thin casting cracking, leading to bearing failure.. (there is a really thin spot next to the bearing that prone to cracking) this i why i would NEVER use these rotors in a boosted application where there is alot more load on the rotors..
I think the savings is at least $300/pair. I'd have to check mazdacomp again. So it would be more expesnive to mill but the 3mm would be harder to break.
Compression is lower at idle but with 3mm but not relavent under load. With this being the case it won't balace out the higher compression RX8 rotors as I thought.
#38
registered user
iTrader: (1)
Join Date: Jan 2006
Location: San Diego
Posts: 2,469
Likes: 0
Received 0 Likes
on
0 Posts
Here's an idea, buy some used 9.0 rotors, and if the seal grooves are at all out have them machined for 3mm seals.
a real good set of 9.0 rotors can always be had for like 200 dollars if you look around.
a real good set of 9.0 rotors can always be had for like 200 dollars if you look around.
Thanks, that was a good reply.
I think the savings is at least $300/pair. I'd have to check mazdacomp again. So it would be more expesnive to mill but the 3mm would be harder to break.
Compression is lower at idle but with 3mm but not relavent under load. With this being the case it won't balace out the higher compression RX8 rotors as I thought.
I think the savings is at least $300/pair. I'd have to check mazdacomp again. So it would be more expesnive to mill but the 3mm would be harder to break.
Compression is lower at idle but with 3mm but not relavent under load. With this being the case it won't balace out the higher compression RX8 rotors as I thought.
#39
#41
Moderator
iTrader: (3)
ahhhh ... redemption. perhaps it was one of your posts somewhere (here or over at rx8club), but i knew i read it somewhere. i really started to get worried about my memory there for a second. that kind of thing would bother me - although i'm trying to allow myself to let things like that go.
#42
Moderator
iTrader: (3)
boooo! way to go reminding me of how freakin' old i am ...
just joshin'. as i said, i never figured it. i guess i still can't ... and the only Renesis i have right now is sitting in my Rx-8 and (knock on wood) i have intentions of pulling that apart any time in the near future, so i'll have to wait for my hands-on experiences a little while longer. until then, you guys have to keep me honest.
just joshin'. as i said, i never figured it. i guess i still can't ... and the only Renesis i have right now is sitting in my Rx-8 and (knock on wood) i have intentions of pulling that apart any time in the near future, so i'll have to wait for my hands-on experiences a little while longer. until then, you guys have to keep me honest.
#43
We've had great success cutting 3mm grooves on Rx8 Rotos for PP. N/A race engines.
Back when the Rx8 Rotors first became available, we sacrificed a new Rotor, dissected it and took carefull mesurements of critical areas were modifications would normally be made.
We've since have built many race engines using Rx8 components.
One example of late:
Look at thread : https://www.rx7club.com/race-car-tech-103/94-rx-7-track-car-project-begins-506890/ pages 5 & 6. for more info.
Correct.
Obtaining good power from these rotors is not as easily done as w/ previous ones, but they will yield great power once the combination is found.
As w/ all progressions into newer technologies, it requires time, testing, and new ideas in mapping to find the tune that inevitably unleashes the extra power.
Close inspection of these Rotors has shown the Parabolic Arc of the flanks to be different in both shape and volume as compared to all previous series of Rotors.
Having found that, it becomes obvious the Thermodynamic characteristics are now different reflecting the changes in chamber geometry.
Tuning, in the traditional sense must therefore be adjusted if optimum performance is to be obtained.
Correct again !
If you are talking "TURBO" application, Rx8 Rotors are not even a consideration.
But on N/A engines, they do have their merits. ...... If tuned appropriately.
