Race Car Tech Discuss anything related to road racing and auto X.

FD brakes early fading. help!

Old 07-18-04, 05:05 PM
  #1
Cheese
10 Year Member
Thread Starter

ORX705's Avatar

Join Date: May 2001
Location: Australia
Posts: 452
Likes: 0
Received 0 Likes on 0 Posts
FD brakes early fading. help!

after running the FD on the track for the first time i was quite alarmed how quickly the brakes faded. 1st lap 3rd corner the brakes were cooked. the fluid was dot 4 and i changed it before the race, the discs are standard (unsure on type of brake pads). i can only assume the pads are crap.

here are my plans for the next race
1. Bendix ultimate pads F&R
2. Slotted rotors F&R
3. hook up some form of front brake ducting
4. dot 5 fluid

Anything else i should look into? Any tips on setting up brake ducts?

Thanks
ORX705 is offline
Old 07-18-04, 05:15 PM
  #2
Rotary Enthusiast
10 Year Member

John Magnuson's Avatar

Join Date: Dec 2002
Location: San Diego, CA
Posts: 1,147
Likes: 0
Received 0 Likes on 0 Posts
I don't think slotted rotors will help a whole lot. The biggies are putting in some track specific pads at the track, good fluid and if you can do a good brake ducting system then by all means do so!
John Magnuson is offline
Old 07-18-04, 05:57 PM
  #3
Eats, Sleeps, Dreams Rotary
5 Year Member

Fatman0203's Avatar

Join Date: May 2003
Location: MIA
Posts: 3,639
Likes: 0
Received 0 Likes on 0 Posts
Slotted not worth the cash. Go for some TRACK only pads, were they perform their best when HOT, and look and search for people that have made brake ducts.
Fatman0203 is offline
Old 07-18-04, 06:22 PM
  #4
Weird Cat Man
10 Year Member

Wargasm's Avatar

Join Date: Aug 2001
Location: A pale blue dot
Posts: 2,868
Likes: 0
Received 0 Likes on 0 Posts
I strongly recommend a set of track ONLY pads such as the Hawk Blue. That should solve your problem. Ducting is a fun idea but I think your MAIN problem is the pads.
Wargasm is offline
Old 07-18-04, 07:18 PM
  #5
Cheese
10 Year Member
Thread Starter

ORX705's Avatar

Join Date: May 2001
Location: Australia
Posts: 452
Likes: 0
Received 0 Likes on 0 Posts
ok, thanks.

i had a read through a few other posts and it most certainly seems to be the pads. i shall look into getting some race pads. for those of you who use your cars for street; when you change the pads back for street use do you use the same discs?

now to really show those rx8 kids
Attached Thumbnails FD brakes early fading. help!-1.jpg
ORX705 is offline
Old 07-18-04, 09:29 PM
  #6
Old Rotary Dog
10 Year Member

wrankin's Avatar

Join Date: Feb 2003
Location: Durham, NC
Posts: 1,461
Likes: 0
Received 2 Likes on 2 Posts
most people I know keep the same brake rotors and just change the pads at the track.

if you choose to go with hawk blues, do a forum search about how to preserve your rims. the dust from those pads is slightly corrosive and will discolor your rims if they are not protected.

btw, which DOT-4 fluid were you using?

-bill
wrankin is offline
Old 07-18-04, 09:38 PM
  #7
Eats, Sleeps, Dreams Rotary
5 Year Member

Fatman0203's Avatar

Join Date: May 2003
Location: MIA
Posts: 3,639
Likes: 0
Received 0 Likes on 0 Posts
Originally Posted by ORX705
ok, thanks.

i had a read through a few other posts and it most certainly seems to be the pads. i shall look into getting some race pads. for those of you who use your cars for street; when you change the pads back for street use do you use the same discs?

now to really show those rx8 kids
It IS your pads, yes use the same rotors. Check for warpage after the track event and make sure you bed the pads in correctly. There is an article on sport compact (just came out) that has a silver supra, it has some good info about brakes , talks about the STI adn EVO and their brakes and upgrades etc etc.
Fatman0203 is offline
Old 07-18-04, 09:47 PM
  #8
Lives on the Forum
15 Year Member

DamonB's Avatar

Join Date: Feb 2001
Location: Dallas
Posts: 9,617
Likes: 0
Received 0 Likes on 0 Posts
Was the fade caused by overheated pads or overheated fluid?

Overheated pads will leave a firm pedal but with reduced bite on the rotor. When this happens the brake pedal still feels nice and firm but the car won't slow. A higher temp pad will help here.

Overheated fluid will leave a soft pedal that may go to the floor or need to be pumped. When this happens getting more cooling air to the brakes or a higher temp fluid will help.
DamonB is offline
Old 07-18-04, 11:45 PM
  #9
Cheese
10 Year Member
Thread Starter

ORX705's Avatar

Join Date: May 2001
Location: Australia
Posts: 452
Likes: 0
Received 0 Likes on 0 Posts
the pedal was very firm but with a lot less bite.

the pedal remains firm however i will change the fluid to motul dot 5. i was using castrol dot 4

i understand its the pads in this case but you think slotted discs are a waste of money?
ORX705 is offline
Old 07-19-04, 01:19 AM
  #10
Back on the road again!
iTrader: (4)

Svelte_7's Avatar

Join Date: May 2002
Location: Bay Area
Posts: 447
Received 0 Likes on 0 Posts
I have the turboimport.com setup (slotted and dimpled rotors with PBR pads) and it worked alright with me at Buttonwillow. I did however flush and use Motul 600 jsut before so that probably something to do being able to predict brake-behavior.
Svelte_7 is offline
Old 07-19-04, 06:20 AM
  #11
Rotary Freak
5 Year Member

cruiser's Avatar

Join Date: Dec 2002
Location: Slovenia, Europe
Posts: 2,524
Likes: 0
Received 0 Likes on 0 Posts
I'm using ATE Super Blue brake fluid and I can boil it on the track in a couple of laps. I think its my pads transferring too much heat to the caliper pistons and heating up the fluid too much.

I'm going with some custom made brake pads as my next set. If that doesnt do the trick, then I will need to make some ducting for the brakes
cruiser is offline
Old 07-19-04, 07:01 AM
  #12
Lives on the Forum
15 Year Member

DamonB's Avatar

Join Date: Feb 2001
Location: Dallas
Posts: 9,617
Likes: 0
Received 0 Likes on 0 Posts
Originally Posted by ORX705
the pedal was very firm but with a lot less bite.
Definitely overheated pads.


Originally Posted by ORX705
you think slotted discs are a waste of money?
No, slotted discs are not a waste of money. If you're only running at the track on occasion and on street tires there's not a big need for them IMO. Just stay away from any disc that is drilled if you plan to do much track time.
DamonB is offline
Old 07-19-04, 12:36 PM
  #13
Post quality not quantity
10 Year Member

bond007's Avatar

Join Date: Feb 2001
Location: Durham, NC
Posts: 521
Likes: 0
Received 0 Likes on 0 Posts
Originally Posted by DamonB
Definitely overheated pads.
No, slotted discs are not a waste of money. If you're only running at the track on occasion and on street tires there's not a big need for them IMO. Just stay away from any disc that is drilled if you plan to do much track time.
Slotted rotors have also been known to crack...
Drilled = bad -- cast with holes = good
bond007 is offline
Old 07-21-04, 02:44 PM
  #14
Rotary Freak
10 Year Member
iTrader: (6)

Section8's Avatar

Join Date: Jan 2002
Location: Golden, CO
Posts: 1,810
Likes: 0
Received 0 Likes on 0 Posts
Originally Posted by bond007
Slotted rotors have also been known to crack...
Drilled = bad -- cast with holes = good
I've actually heard that even cast with holes rotors should be avoided as well, as there is still area for cracks to form
Section8 is offline
Old 07-21-04, 04:59 PM
  #15
Lives on the Forum

rynberg's Avatar

Join Date: Dec 2001
Location: San Lorenzo, California
Posts: 14,717
Likes: 0
Received 2 Likes on 2 Posts
There is seriously something wrong with your brakes if you are fading them on the FIRST lap, THIRD corner. Even a completely stock brake system with 10-year old brake fluid should do better than that.

The last time I was at Buttonwillow, I did manage to melt a set of HPS pads (with ATE Super Blue fluid) but that took many laps. When I was slower, it took several laps for me to even notice fade on the stock brakes.
rynberg is offline
Old 07-21-04, 05:25 PM
  #16
Cheese
10 Year Member
Thread Starter

ORX705's Avatar

Join Date: May 2001
Location: Australia
Posts: 452
Likes: 0
Received 0 Likes on 0 Posts
ok we know it is the pads overheating. so the problem is not enough heat dispersion or some seriously **** pads (which is still what i suspect). there are no brake ducts attached, but i know the some s6 didn't come with brake ducts.

the 3rd corner on thsi particular track is amongst some fairly heavy braking. i am only amateur too, so i use my brakes a lot. but yes i agree 1st lap shouldn't be much of a problem.

i have better pads and front slotted rotors coming in, will see how it goes next time.
ORX705 is offline
Old 07-24-04, 12:26 AM
  #17
WWFSMD
10 Year Member

maxcooper's Avatar

Join Date: Jun 2001
Location: SoCal
Posts: 5,035
Likes: 0
Received 3 Likes on 3 Posts
For those with fluid boiling problems, you might want to check that you are using the shims (e.g. the FD uses two shims on the back of each front pad). It seems like the shims would help reduce the amount of heat transferred from the pads to the pistons and then to the fluid.

-Max
maxcooper is offline
Old 07-25-04, 01:52 PM
  #18
Rotary Freak
5 Year Member

cruiser's Avatar

Join Date: Dec 2002
Location: Slovenia, Europe
Posts: 2,524
Likes: 0
Received 0 Likes on 0 Posts
Shims... taking off my front brake pads I found out there is only 1 shim on all pads. Grrrr...

Can you manufacture your own or must they be original stuff ?

Seems logical to me that additional shim could help disperse the heat.
cruiser is offline
Old 07-25-04, 08:53 PM
  #19
Full Member
10 Year Member

Join Date: Feb 2001
Location: chicago
Posts: 211
Likes: 0
Received 0 Likes on 0 Posts
Look at the big brake kit at the "suspension, wheel and steering section"
1RedR1and1RedPEP is offline
Old 07-26-04, 12:53 AM
  #20
Rotary Freak
5 Year Member

cruiser's Avatar

Join Date: Dec 2002
Location: Slovenia, Europe
Posts: 2,524
Likes: 0
Received 0 Likes on 0 Posts
Big brakes require 17" rims at the track and I only want to use stock ones for those purposes
cruiser is offline
Old 07-26-04, 09:48 AM
  #21
Old Rotary Dog
10 Year Member

wrankin's Avatar

Join Date: Feb 2003
Location: Durham, NC
Posts: 1,461
Likes: 0
Received 2 Likes on 2 Posts
Unless you are running some serious HP and speed (which I don't believe our poster is) the stock brake system on an FD (running track pads and fresh high-temp brake fluid) is more than sufficient for most track usage.

Find and fix the *real* problem and fix it first before you go off and throw $$ away on something that may not even be an issue.

-bill
wrankin is offline
Old 07-26-04, 04:43 PM
  #22
Rotary Enthusiast
10 Year Member

John Magnuson's Avatar

Join Date: Dec 2002
Location: San Diego, CA
Posts: 1,147
Likes: 0
Received 0 Likes on 0 Posts
Having raced my FD both with and without shims I really don't think that shims made a difference in heat transfer.
John Magnuson is offline
Old 07-27-04, 06:54 PM
  #23
Cheese
10 Year Member
Thread Starter

ORX705's Avatar

Join Date: May 2001
Location: Australia
Posts: 452
Likes: 0
Received 0 Likes on 0 Posts
no i agree, i'm not spending $4000 plus on brakes on essentially a stock car. i raced a r33 skyline on the same track, although heavier i had no problems. i wouldn't say the brakes on the skyline was anything special either (note: we're not talking GTR brembo brakes here).

anyway, i changed all 4 pads and replaced the front discs with slotted items. adding some factory brake ducts as well.
ORX705 is offline
Old 07-29-04, 01:57 PM
  #24
iTrader: (4)

BASTARD's Avatar

Join Date: Dec 2003
Location: NorCal
Posts: 2,280
Likes: 0
Received 0 Likes on 0 Posts
Stop dragin the brake pedal ...lol..j/k. change your pads and try it again
BASTARD is offline
Old 08-22-04, 10:38 PM
  #25
Cheese
10 Year Member
Thread Starter

ORX705's Avatar

Join Date: May 2001
Location: Australia
Posts: 452
Likes: 0
Received 0 Likes on 0 Posts
just an update. took the car to track over the weekend and the brakes were great!!! and i was fairly cruel to them too. they lasted the 6 laps

all i had achnged were to front slotted discs, and bendix ultimate pads all round. also added the factory brake ducts.
ORX705 is offline
