Okay so this is how I wired the relay. I have the 1e pin from the harness disconnected but the compressor is not turning on. With the oem computer the ac works fine. Is the 1e wire from the harness suppose to go somewhere? If so where? Also is my wiring right?


Black wire: I attached it to the c85 on the powerfc
Green wire: to 4u on oem harness shematics I believe
Red wire ( on the back): 1* on oem harness which is blank
Red wire (front) ground from old 1e pin position.



Everything is fixed!!! All I had to do was follow the directions.... 10 min idle (without any loads) 10 min with defroster on and 10 minutes with a/c on and defroster off. It literarily took 7 to 8 minutes before the surge stopped! Let it idled for 5 minutes more then turned the car off waited 1 minute and started it again and the surge was gone"!!! So if your idle is bouncing or hunting or surging with the air conditioning on but works on all other settings all you have to do is wait... It sounds easy but all of us who had or have this problem do not like to hear the engine for crazy for longer than 1 minute or two but I was fed up and waiting a few minutes longer fixed it""""""!!,!!,!
