working on a repu lsd kit

Old 10-26-16, 11:54 PM
  #1
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
working on a repu lsd kit

started working on a repu lsd kit since the one someone made in the past is no longer available i might be able to make more if there is alot of interest but i want test it first


xp882 is offline
Old 10-27-16, 06:09 AM
  #2
Full Member

Join Date: May 2015
Location: Nashville
Posts: 147
Liked 0 Times in 0 Posts
More specific info about the kit please.
almoststockrepu is offline
Old 10-27-16, 08:53 AM
  #3
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
it would allow you to use an lsd torsen form a fd rx7 in a repu rear. you need a ring gear spacer and axle spacer also new bolts you will have to grind two notches in the alxe housing for the new bolts to clear like a fd rear end the pics are of the axle spacer first pic and ring gear spacer second pic

here is the info to the first kit that is nla
http://www.mazdarepu.com/board/viewthread.php3?FID=1&TID=1908
xp882 is offline
Old 10-27-16, 09:22 AM
  #4
Full Member

Join Date: May 2015
Location: Nashville
Posts: 147
Liked 0 Times in 0 Posts
Are the carrier bearings compatible? What are you doing about pinion depth when the crush sleeves are no longer available? How much shimming of the LSD is going to be required with your "ring gear spacer" ?
almoststockrepu is offline
Old 10-27-16, 10:10 AM
  #5
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
ring gear will be in the same place hope this helps.. bearing are the same
xp882 is offline
Old 10-27-16, 03:29 PM
  #6
#turbodavebuilt
iTrader: (50)

turbo_dave's Avatar

Join Date: Nov 2006
Location: EL SERENO
Posts: 2,111
Liked 3 Times in 3 Posts
#ballin
turbo_dave is offline
Old 10-27-16, 04:17 PM
  #7
Blood, Sweat and Rotors
iTrader: (1)

DriveFast7's Avatar

Join Date: Aug 2001
Location: California
Posts: 3,733
Liked 0 Times in 0 Posts
Originally Posted by almoststockrepu View Post
Are the carrier bearings compatible? What are you doing about pinion depth when the crush sleeves are no longer available? How much shimming of the LSD is going to be required with your "ring gear spacer" ?
Use the carrier bearings from the FD and the crush sleeve can be stretched out and then re-crushed. Been there done that. with the ring gear in the same spot the adjusters won't need to be moved.

Glad to see someone else doing a kit Al!
DriveFast7 is offline
Old 10-27-16, 05:09 PM
  #8
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
thanks brad its adam not al btw lol all good.. just following your lead someone had to remake this thanks for the tips!
xp882 is offline
Old 10-27-16, 08:00 PM
  #9
Out In the Barn
iTrader: (8)

KansasCityREPU's Avatar

Join Date: Mar 2005
Location: Liberty, Missouri
Posts: 4,169
Liked 94 Times in 89 Posts
subbed
KansasCityREPU is offline
Old 10-29-16, 09:32 PM
  #10
REPU Garage
iTrader: (17)

Join Date: Jun 2007
Location: Northern Colorado
Posts: 623
Likes: 0
Liked 0 Times in 0 Posts
I'm down
Turbo8 is offline
Old 11-02-16, 12:29 PM
  #11
Blood, Sweat and Rotors
iTrader: (1)

DriveFast7's Avatar

Join Date: Aug 2001
Location: California
Posts: 3,733
Liked 0 Times in 0 Posts
Nice work Adam! I think you could sell some of these on eBay too to recoup development time.
DriveFast7 is offline
Old 11-02-16, 01:44 PM
  #12
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
thanks brad i might just do that alot time invested indeed... anyway got it installed today took it for a drive and a couple burnouts so far so good nice and quiet
xp882 is offline
Old 11-02-16, 07:35 PM
  #13
REPU Garage
iTrader: (17)

Join Date: Jun 2007
Location: Northern Colorado
Posts: 623
Likes: 0
Liked 0 Times in 0 Posts
Just do it already!


Turbo8 is offline
Old 10-22-17, 09:30 PM
  #14
Can Post Only in New Member Section

Join Date: Oct 2017
Location: Carson
Posts: 1
Liked 0 Times in 0 Posts
Are this still available?
75REPU is offline
Old 10-24-17, 10:13 AM
  #15
Over rev'd, under torqued

motormanalpha's Avatar

Join Date: Nov 2010
Location: Colorado
Posts: 26
Likes: 0
Liked 1 Time in 1 Post
Still interested... any updates?
motormanalpha is offline
Old 10-24-17, 11:41 AM
  #16
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
I have sold a few kits looks like 1975 repu is getting the last one i have currently.. i will work on getting more done up soon

Originally Posted by motormanalpha View Post
Still interested... any updates?
xp882 is offline
The following users liked this post: xp882
75REPU (10-25-17)
Old 10-25-17, 10:07 AM
  #17
Rotary Enthusiast
iTrader: (1)

Join Date: Apr 2012
Location: NH
Posts: 855
Liked 35 Times in 29 Posts
I'm interested in a kit. I must have missed the memo that you had them available. Send me a PM when you have kits to sell.
chuyler1 is offline
Old 10-25-17, 02:05 PM
  #18
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by chuyler1 View Post
I'm interested in a kit. I must have missed the memo that you had them available. Send me a PM when you have kits to sell.
yeah sorry man i didnt know there would be so much interest i just made a few extras for friends and people keep sending request i will get on making some more i have the ring gear spacers done just working on using my friends lay to make the axle spacers
xp882 is offline
Old 10-29-17, 05:00 PM
  #19
Less Cubes, More Balls
iTrader: (4)

spokanerxdude's Avatar

Join Date: Feb 2005
Location: Spokane, WA
Posts: 559
Liked 2 Times in 2 Posts
WA repu spacer

I'll take one!! How Much???
spokanerxdude is offline
Old 11-02-17, 03:17 PM
  #20
www.VJMU.org

SiRMarlon's Avatar

Join Date: Jan 2009
Location: Los Angeles, CA
Posts: 118
Likes: 0
Liked 0 Times in 0 Posts
I just recently installed this kit on my REPU and it's night and day difference. It also helps I put some really sticky tires on the truck as well! Rear grip for days now!
SiRMarlon is offline
Old 11-08-17, 01:56 PM
  #21
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
I have six spacers ready to go 220 shipped for the two spacers you will need to get your own bolts a few bucks at autozone i have part numbers email me [email protected]
xp882 is offline
Old 11-08-17, 11:46 PM
  #22
Rare for a Reason
iTrader: (13)

Narfle's Avatar

Join Date: Nov 2002
Location: Dagobah
Posts: 5,447
Liked 87 Times in 65 Posts
Now I just need a repu....
Narfle is online now
Old 11-09-17, 12:19 PM
  #23
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
4 left going quick
xp882 is offline
Old 11-10-17, 10:23 AM
  #24
Rotary Enthusiast
iTrader: (1)

Join Date: Apr 2012
Location: NH
Posts: 855
Liked 35 Times in 29 Posts
Originally Posted by xp882 View Post
4 left going quick
I just shared the thread with the Facebook Group for you.
chuyler1 is offline
Old 11-10-17, 10:12 PM
  #25
Senior Member
Thread Starter
iTrader: (1)

xp882's Avatar

Join Date: Mar 2001
Location: chino,CA,USA
Posts: 270
Likes: 0
Liked 1 Time in 1 Post
Originally Posted by chuyler1 View Post
I just shared the thread with the Facebook Group for you.
thanks buddy
