3rd Generation Specific (1993-2002) 1993-2002 Discussion including performance modifications and Technical Support Sections.

Spoiler/Wing for FD without drilling holes

Old 12-10-18, 07:43 PM
  #1
Junior Member
Thread Starter

Southern_Rotary's Avatar

Join Date: Sep 2018
Location: Louisiana
Posts: 19
Likes: 0
Recieved 0 Likes on 0 Posts
Spoiler/Wing for FD without drilling holes

Are there any wings or really any aero available that use the stock pre-99 spoiler holes? I've been looking at the panspeed wing but I cannot even begin to bring myself to drill holes in my low mileage '92 Efini. Any other options or suggestions?
Southern_Rotary is offline
Old 12-10-18, 09:46 PM
  #2
OMG WTF

Join Date: Jul 2006
Location: Regina, SK
Posts: 239
Recieved 0 Likes on 0 Posts
Maybe the Mazdaspeed wing? You could probably put a ton of double sided tape on that wing since it has a large contact area, but even then, I'd still secure it by drilling holes through my hatch lol. Or.. you could just purchase a second hatch just to do whatever with. I've honestly toyed with the idea of having a hatch with a GT Spoiler on it, and then a wingless hatch for street use, but it just seems like such a hassle so I've never bothered.
L-Spec is online now
Old 12-10-18, 10:54 PM
  #3
Senior Member

Sideo's Avatar

Join Date: May 2006
Location: reno nevada
Posts: 745
Recieved 7 Likes on 6 Posts
Theorie made an awesome no drilling required track wing but I am not sure if thats what you are looking for also does not appear to be available.

https://www.rx7club.com/group-buy-pr...1025900/page8/
Sideo is offline
Old 12-11-18, 03:31 AM
  #4
Viable fossil
iTrader: (14)

Sgtblue's Avatar

Join Date: Oct 2003
Location: Mid-west
Posts: 10,214
Recieved 158 Likes on 138 Posts
I think the later "whale-tail" spoiler uses the inner holes from our stock S6 spoiler. The outer holes you'll have to fill. Not sure how much real “aero” either provides though.




Last edited by Sgtblue; 12-11-18 at 05:20 AM.
Sgtblue is offline
Old 12-11-18, 07:23 AM
  #5
RX-7 Bad Ass
iTrader: (52)

DaleClark's Avatar

Join Date: Jan 2002
Location: Pensacola, FL
Posts: 11,168
Recieved 272 Likes on 232 Posts
I have an RE-Amemiya wing that looks like the stock R1 wing but bigger. It uses the same bolt holes. I think the Racing Beat spoilers may do as well.

Dale
DaleClark is offline
Old 12-11-18, 09:56 AM
  #6
mdp
Always Bad Advice

mdp's Avatar

Join Date: Nov 2005
Location: San Diego
Posts: 305
Recieved 69 Likes on 47 Posts
Originally Posted by DaleClark View Post
I have an RE-Amemiya wing that looks like the stock R1 wing but bigger. It uses the same bolt holes. I think the Racing Beat spoilers may do as well.

Dale
I just replaced a cracked Racing Beat spoiler with a stock R1 spoiler and unfortunately, the bolt holes are a little off. The inner holes had to be drilled larger and the outer front holes were off so much they had to be filled and re drilled.
Alot more effort that the drop in replacment I had thought.
mdp is offline
Old 12-12-18, 10:35 PM
  #7
Junior Member
Thread Starter

Southern_Rotary's Avatar

Join Date: Sep 2018
Location: Louisiana
Posts: 19
Likes: 0
Recieved 0 Likes on 0 Posts
Originally Posted by DaleClark View Post
I have an RE-Amemiya wing that looks like the stock R1 wing but bigger. It uses the same bolt holes. I think the Racing Beat spoilers may do as well.

Dale
Do you know the model of that RE-Amemiya wing?
Southern_Rotary is offline
Old 12-13-18, 09:40 AM
  #8
RX-7 Bad Ass
iTrader: (52)

DaleClark's Avatar

Join Date: Jan 2002
Location: Pensacola, FL
Posts: 11,168
Recieved 272 Likes on 232 Posts
I think it's called the Type-1

https://www.vividracing.com/reamemiy...02-p-6087.html

Don't know if it's really available new any more. I've seen them every now and again on Ebay.

My car is an R2 and it bolted right up to the stock spoiler holes, no weirdness, just bolted right on perfectly.

Same shape as a stock spoiler just bigger. Many people have seen it then did a double-take - "is that a stock spoiler?". I really dig it, looks good and clean just a little "extra" to it.

Dale
DaleClark is offline
Old 12-13-18, 10:04 AM
  #9
Viable fossil
iTrader: (14)

Sgtblue's Avatar

Join Date: Oct 2003
Location: Mid-west
Posts: 10,214
Recieved 158 Likes on 138 Posts
^Looks like that Amemiya type 1 spoiler only uses the inner holes too...with the ends over the quarter panel. So you’d have cover the outer holes or fill them.
Sgtblue is offline
Old 12-13-18, 10:46 AM
  #10
RX-7 Bad Ass
iTrader: (52)

DaleClark's Avatar

Join Date: Jan 2002
Location: Pensacola, FL
Posts: 11,168
Recieved 272 Likes on 232 Posts
Nope, it uses all 8 mounting holes. I've uninstalled/reinstalled it a number of times to know for sure .

I did have to re-paint my rear hatch since the old spoiler rubbed the paint away at the edges and this spoiler covers different parts of the hatch. If the paint was mint this spoiler is a simple bolt-on process.

BTW, since this is an info dump, the spoiler has an RE-Amemiya logo cast into the fiberglass on the underside middle. It also had I think 2 studs to help install it. The hardware when I got it was long gone so I used metric stainless hardware. All the bolts go into riv-nuts on the spoiler. The gaskets between the spoiler and car are different than stock so I made my own from rubber gasket material from a local gasket shop and used a little black RTV to insure they sealed around the bolt holes.

Of course now everyone has a ton of info on a probably out-of-production and hard to source spoiler. Yay internet!

Dale
DaleClark is offline
The following users liked this post:
Sgtblue (12-13-18)
Old 12-13-18, 10:39 PM
  #11
Rare for a Reason
iTrader: (13)

Narfle's Avatar

Join Date: Nov 2002
Location: Dagobah
Posts: 5,454
Recieved 88 Likes on 66 Posts
Originally Posted by Sgtblue View Post
Not sure how much real “aero” either provides though.
The s6 spoiler is documented to reduce lift. And, some Mazda literature I've read mentions the efini spoiler is more efficient. And, the 99spec is actually a wing that produces non-marginal downforce.
Narfle is offline
Old 12-14-18, 06:34 AM
  #12
amp
old yella
iTrader: (50)

amp's Avatar

Join Date: Jan 2002
Location: NYC | PA
Posts: 3,467
Recieved 45 Likes on 33 Posts
buy another hatch and drill that... set original aside
amp is offline
Old 12-27-18, 12:27 AM
  #13
Doritos on a toothpick

BoostCrzy's Avatar

Join Date: Oct 2002
Location: west palm beach, FL
Posts: 1,124
Recieved 4 Likes on 4 Posts
No drilling necessary. Feed type 2.


BoostCrzy is offline
Old 12-27-18, 10:47 PM
  #14
Endure Persevere Succeed
iTrader: (26)

Jaiyurai's Avatar

Join Date: Apr 2005
Location: Berkeley, CA
Posts: 1,545
Recieved 13 Likes on 12 Posts
Feed type 2 uses the factory two outer holes. The two inner need to be filled in.
99+ spoilers use all the factory holes.
Mazdaspeed uses the outer holes like the Feed type 2 but also covers the whole deck. No need to fill in the inner holes.
Jaiyurai is offline
The following users liked this post:
L-Spec (12-28-18)
