Lines top of hangar + charcoal canister
09-11-19, 10:54 AM
#3
09-15-19, 11:13 AM
#6
Eye In The Sky
iTrader: (2)
Join Date: Feb 2001
Location: In A Disfunctional World
Posts: 7,894
Likes: 0
Received 114 Likes
on
66 Posts
In the rear, I only removed the the canister and the hose going to the FE metal line forward.
The hose from the fuel tank to the canister was routed up into a crevice in the body work to keep out trash and fluids. Insert a small filter to it.
Thus the system as far as the fuel tank is concern, works like normal, it maintains pressure.
I use the two large parallel lines for fuel to the engine, and use the small FE line as the new return fuel line.
Have never had fuel smell problems doing it this way.
The hose from the fuel tank to the canister was routed up into a crevice in the body work to keep out trash and fluids. Insert a small filter to it.
Thus the system as far as the fuel tank is concern, works like normal, it maintains pressure.
I use the two large parallel lines for fuel to the engine, and use the small FE line as the new return fuel line.
Have never had fuel smell problems doing it this way.
