keep in mind that the original source is actually a parts book. in the USA the book (singular, one) got taken apart and photographed into Mirco-fish. Then they took the microfilm and copied that into the computer, so this is why some pictures are terrible quality. and then, since the original Electronic Parts Catalog (EPC), there have been 9 more that we know about. we're currently running GEPC II, Global Electronic Parts Catalog, non flash, in the USA. or the Snap On one.
so i guess its like music, it used to be live, then on the scroll of paper (or copper), and then record, 8 track, tape, CD, MP2, MP3, so there are a lot of ways to see the same data.
The following users liked this post:
Redbul (02-27-21)
#53
Moderator
iTrader: (3)
Join Date: Mar 2001
Location: https://www2.mazda.com/en/100th/
Posts: 30,842
Received 2,605 Likes
on
1,848 Posts
i saw this in a Miata service bulletin, and it gives you some idea of how many markets/catalogs Mazda has (of course its missing Japan!)
#54
Junior Member
Join Date: May 2021
Location: Tokyo, Japan
Posts: 19
Likes: 0
Received 0 Likes
on
0 Posts
Version 4 - Jan 1996 - December 1998
This is where some larger changes are made to the FD.
Computer changed to 16 bit.
Manual models increase from 255ps to 265ps.
Round tail lights.
Changed dash illumination from amber to green.
Vintage Red
Silverstone metallic
Brilliant Black
Chaste White
This is where some larger changes are made to the FD.
Computer changed to 16 bit.
Manual models increase from 255ps to 265ps.
Round tail lights.
Changed dash illumination from amber to green.
Vintage Red
Silverstone metallic
Brilliant Black
Chaste White
- Touring X
- Type RZ (4) - Same options as before, just in new 1996 spec.
- Type RS - Same options as before and now includes 4.30 final drive.
- Type RB Bathurst
- Type RB - Appears to be the base model of this year.
- Type RB Bathurst X - 700 units made. Projector type fog lights, special design rear wing, rear wiper, and special decal.
- Type RS-R - 500 units made. Revealed in October 1997 after the change from "Efini RX-7" to Mazda RX-7 in Japan. Also the 30th anniversary of the rotary engine. A mix of the RZ and RS trims, only available in Yellow and White with gunmetal wheels. This car has a gauge cluster with the 30th anniversary design.
#57
Lives on the Forum
iTrader: (26)
By Series 5 you mean Version 5, or are you asking about second generation FC?
Initial parts catalogue for Version 5 does not show any type having two seats.
For version 4 cars only the Type RZ (airbag and non-airbag) are shown to be two seaters (nininnori).
For version 6, The Spirit R Typa A and the Type RZ are shown to be two seaters.
It is possible that if there was a Version 5 Type RZ produced after the first parts catalogue, it may have been a two seater).
Also as the rear bins set up was generally available, it is possible that any type could have the rear bins switched in..
Initial parts catalogue for Version 5 does not show any type having two seats.
For version 4 cars only the Type RZ (airbag and non-airbag) are shown to be two seaters (nininnori).
For version 6, The Spirit R Typa A and the Type RZ are shown to be two seaters.
It is possible that if there was a Version 5 Type RZ produced after the first parts catalogue, it may have been a two seater).
Also as the rear bins set up was generally available, it is possible that any type could have the rear bins switched in..
The following users liked this post:
Matyas (04-29-23)
