A complet projects completed - pics
I finally finished my custom IC project I started a few months ago with the completion and installation of my air duct. The picture show the aluminum air box before painting the lower portion and taping the holes, installed, and the air scoop. It fit's like a glove. I also converted my taillights to 99 spec. I don't know what to do next. I might actually drive the car a little first but I just love working on it.
#2
Senior Member
Join Date: Apr 2002
Location: Tokyo/Texas
Posts: 685
Likes: 0
Received 0 Likes
on
0 Posts
it's hard to see in the picture, but where the 90 degree bend in the air duct is, it looks like there's a rather large hole on the side that you might want to consider patching up. Nice setupu though. Congrats.
#5
Senior Member
Thread Starter
Join Date: Oct 2003
Location: Lynnwood, WA
Posts: 452
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by johnchabin
Is blocking the radiator this much causing any increase in coolant temps?
Looks like a good fit. Nice work.
Is blocking the radiator this much causing any increase in coolant temps?
Looks like a good fit. Nice work.
#6
Senior Member
Thread Starter
Join Date: Oct 2003
Location: Lynnwood, WA
Posts: 452
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by Spool Up
it's hard to see in the picture, but where the 90 degree bend in the air duct is, it looks like there's a rather large hole on the side that you might want to consider patching up. Nice setup though. Congrats.
it's hard to see in the picture, but where the 90 degree bend in the air duct is, it looks like there's a rather large hole on the side that you might want to consider patching up. Nice setup though. Congrats.
#7
Senior Member
Thread Starter
Join Date: Oct 2003
Location: Lynnwood, WA
Posts: 452
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by Spool Up
it's hard to see in the picture, but where the 90 degree bend in the air duct is, it looks like there's a rather large hole on the side that you might want to consider patching up. Nice setup though. Congrats.
it's hard to see in the picture, but where the 90 degree bend in the air duct is, it looks like there's a rather large hole on the side that you might want to consider patching up. Nice setup though. Congrats.
Trending Topics
#10
Senior Member
Thread Starter
Join Date: Oct 2003
Location: Lynnwood, WA
Posts: 452
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by wickedrx7
Nice duct work. I want to extend my M2 medium duct work to pick up more air.
Did you custom make the intercooler setup too or just the duct work.
Nice duct work. I want to extend my M2 medium duct work to pick up more air.
Did you custom make the intercooler setup too or just the duct work.
#11
Senior Member
Thread Starter
Join Date: Oct 2003
Location: Lynnwood, WA
Posts: 452
Likes: 0
Received 0 Likes
on
0 Posts
Originally posted by turbojeff
That thing blocks half the air inlet in the nose of the car. You'd be better off with a FMIC. Reduce the size of the duct, it doesn't need to come down all the way to the bottom of the bumper. The IC needs less air than the radiator.
That thing blocks half the air inlet in the nose of the car. You'd be better off with a FMIC. Reduce the size of the duct, it doesn't need to come down all the way to the bottom of the bumper. The IC needs less air than the radiator.
#16
Rotary Enthusiast
iTrader: (2)
Originally posted by luizajeff
You'll notice that the fan housing creates a space about 4" from the radiator itself. The stock IC and duct covers the same amount of space so there is almost no change here. However, by removing the stock size battery and replacing it with my new Hawker mini battery, and removing the stock air box on the intake and replacing it with the Greddy (Trust) intake I have actually opened up almost half of the radiator area to good air flow. So if anything, the eng. should run cooler.
You'll notice that the fan housing creates a space about 4" from the radiator itself. The stock IC and duct covers the same amount of space so there is almost no change here. However, by removing the stock size battery and replacing it with my new Hawker mini battery, and removing the stock air box on the intake and replacing it with the Greddy (Trust) intake I have actually opened up almost half of the radiator area to good air flow. So if anything, the eng. should run cooler.
#20
I AM A THIEF - READ GOOD GUY / BAD GUY
Join Date: Sep 2003
Location: Chattanooga, TN
Posts: 217
Likes: 0
Received 0 Likes
on
0 Posts
thats the same setup I just did. Do you plan on getting an alum. AST? where are you going to mount/tape the stock one until you get an aftermarket one?
Sean
Sean
#21
Hey, where did my $$$ go?
Join Date: Feb 2001
Location: Bimingham, AL
Posts: 4,413
Likes: 0
Received 0 Likes
on
0 Posts
Ummm, from the looks of it your taking up about 30% of the nose. Is the pic just missleading? Can you take a pic farther back so we can get a better picture? If its really taking up about 30% that might be to much, at a minimum its going to create a hot spot behind the duct
If its really that large its to big, it'll actually create pressure in front of the IC core and make it harder for air to get thru it. You duct opening only needs to be about 30% the size of your core.....cause the majority of the core is metal and doesnt flow air.
In other words if your core say 10x10" your duct opening only needs to be about 10x3"
STEPHEN
If its really that large its to big, it'll actually create pressure in front of the IC core and make it harder for air to get thru it. You duct opening only needs to be about 30% the size of your core.....cause the majority of the core is metal and doesnt flow air.
In other words if your core say 10x10" your duct opening only needs to be about 10x3"
STEPHEN
Last edited by SPOautos; 04-14-04 at 03:53 PM.
