pics of aftermarket turbo exhaust mani's
Haven't we ALL heard this
Joined: Mar 2001
Posts: 3,948
Likes: 1
From: Indiana
Originally Posted by stylEmon
they are all custom built, so the price is different for each. this one has lots bungs and the wg dumps into the dp... so each is built specifically for the customer. get a hold of 1revvin7 for a price.
James
Originally Posted by monterx7
off topic...why do some tilt the center section of the turbo like you did?
Originally Posted by Bad2ndgen
Hey man, The new site is up. Its not quite done yet but is functional, I haven't got all the pictures and stuff up yet. I bought a new shop and have been spending all my time getting that up and going but there is some very exciting stuff on the horizon. How's the car running, did you ever get it completed? Sorry if you have posted about it but I haven't been on here for a long while.
Sweet man, Congrats on the new shop! Hope things work out well for you. You did a hell of a job on my Manifold and DP, nothing but compliments have come my way on them.
Car is running very well right now...PM me if you want and I'll tell you all about it. I want to be able to keep this thread on topic.
Originally Posted by Bad2ndgen
Hey man, The new site is up. Its not quite done yet but is functional, I haven't got all the pictures and stuff up yet. I bought a new shop and have been spending all my time getting that up and going but there is some very exciting stuff on the horizon. How's the car running, did you ever get it completed? Sorry if you have posted about it but I haven't been on here for a long while.
You should post pics of your car, and other customers; as there are a lot of people jumping on the "pretty" bandwagon...
Senior Member
Joined: Jul 2002
Posts: 615
Likes: 0
From: Richland Wa.
Yes when I built yours I took the opportunity to build a jig so I could replicate them, I wish I would have built a jig for the downpipe though... You guy's should post all the good pictures you have so I can put them on the website. Thanks for the business too!
Originally Posted by Bad2ndgen
Yes when I built yours I took the opportunity to build a jig so I could replicate them, I wish I would have built a jig for the downpipe though... You guy's should post all the good pictures you have so I can put them on the website. Thanks for the business too!
BTW - Don't be shy, show them your car
Senior Member
Joined: Jul 2002
Posts: 615
Likes: 0
From: Richland Wa.
There will be plenty of show off of my car pretty soon, I am doing another build on it soon and will be documenting the entire process in the form of a writeup on here. If someone wants to see my cas as it is now they can check out the following links...
www.linderpowersystems.com
www.myspace.com/linderpowersystems
P.S. If someone feels the need they can post pics up, I just don't want to promote myself to much on here as I am not a paying vendor....Yet!
www.linderpowersystems.com
www.myspace.com/linderpowersystems
P.S. If someone feels the need they can post pics up, I just don't want to promote myself to much on here as I am not a paying vendor....Yet!
Originally Posted by 88rxn/a
nice manifold!!
i like the dual wastegate setup!
i like the dual wastegate setup!
I bought it when I had the "drag racing" mentality; will see how it works on a street\auto X mentality.
Senior Member
Joined: Jul 2002
Posts: 615
Likes: 0
From: Richland Wa.
It will work great with a properly sized turbo, I have one on a car with a 62-1 1.15a/r and am seeing full boost (15 psi) at 3500 rpm's and pulls hard to around 8000. The car made 360hp and 290tq on a dyno dynamics...
Fast Regards
Justin Linder
www.linderpowersystems.com
www.myspace.com/linderpowersystems
Fast Regards
Justin Linder
www.linderpowersystems.com
www.myspace.com/linderpowersystems
Originally Posted by Bad2ndgen
It will work great with a properly sized turbo, I have one on a car with a 62-1 1.15a/r and am seeing full boost (15 psi) at 3500 rpm's and pulls hard to around 8000. The car made 360hp and 290tq on a dyno dynamics...
Fast Regards
Justin Linder
www.linderpowersystems.com
www.myspace.com/linderpowersystems
Fast Regards
Justin Linder
www.linderpowersystems.com
www.myspace.com/linderpowersystems
I have ABSOLUTELLY no doubt that the turbo manifold WILL perform as I expected. I did a FULL research before deciding which one I was going to invest my money on.
Senior Member
Joined: Jul 2002
Posts: 615
Likes: 0
From: Richland Wa.
It is actually more for turbo response than anything else, I have been building manifolds this way for about six years and have seen great results. By keeping the runners completely separate all the way to the divided turbo you keep the pressure and velocity at its maximum thus spooling the turbo quicker, you can not do this with a single gate. I usually see full boost about 500-700rpm sooner and have seen as much as 1000rpm sooner vs some real crappy designs, The fact that you can control boost perfectly is just an added advantage.
Justin Linder
Justin Linder
Originally Posted by Bad2ndgen
It is actually more for turbo response than anything else, I have been building manifolds this way for about six years and have seen great results. By keeping the runners completely separate all the way to the divided turbo you keep the pressure and velocity at its maximum thus spooling the turbo quicker, you can not do this with a single gate. I usually see full boost about 500-700rpm sooner and have seen as much as 1000rpm sooner vs some real crappy designs, The fact that you can control boost perfectly is just an added advantage.
Justin Linder
Justin Linder
+1
Justin..PM'd you man
Senior Member
Joined: Jul 2002
Posts: 615
Likes: 0
From: Richland Wa.
Originally Posted by Comitatus
Justin,
Yo man...glad things are going well for you. I've been meaning to send you an email for a while now.
Had my car tuned back in summer 06, put down about 470-480whp at 18psi on 110 leaded. Pretty conservative tune at that point.
I only run 12psi on 93 octane on the street.
The manifold is working out awesome! I love it, and get compliments everywhere I go. I definitely appreciate the work you put in on it for me.
Took the car to the track this past weekend for the first time. Made the first 4 passes of my life. Keep in mind that im still running stock 16x7 wheels and kumho ecsta SPT street tires. Boost controller read peak of 11psi. 1st and 3rd runs were no traction through 4th, and had 14.1 and 14.2 @110 timeslips. 2nd run was 12.9 @ 117 w/ 2.1 60'. 4th and last run of the day, 12.6 @116.9 w/ 2.1 60'.
Overall not bad...much more in it...I believe its an 11sec car that will trap 120's on 12 psi - low boost...just need traction.
What are you doing to your car? When will the site be completely finished?
Luke
Yo man...glad things are going well for you. I've been meaning to send you an email for a while now.
Had my car tuned back in summer 06, put down about 470-480whp at 18psi on 110 leaded. Pretty conservative tune at that point.
I only run 12psi on 93 octane on the street.
The manifold is working out awesome! I love it, and get compliments everywhere I go. I definitely appreciate the work you put in on it for me.
Took the car to the track this past weekend for the first time. Made the first 4 passes of my life. Keep in mind that im still running stock 16x7 wheels and kumho ecsta SPT street tires. Boost controller read peak of 11psi. 1st and 3rd runs were no traction through 4th, and had 14.1 and 14.2 @110 timeslips. 2nd run was 12.9 @ 117 w/ 2.1 60'. 4th and last run of the day, 12.6 @116.9 w/ 2.1 60'.
Overall not bad...much more in it...I believe its an 11sec car that will trap 120's on 12 psi - low boost...just need traction.
What are you doing to your car? When will the site be completely finished?
Luke
My car is getting a 13brew, full bridge, rx8 eccentric shaft and stat gears, my new LPS apex seal prototypes and exhaust sleeves, custom upper plenum with duel throttle body's, x8 1680cc injectors, 74mm bb turbo w/1.32 divided x-trim, ceramic coatings everywhere, 26x12x4" intercooler 3" to duel 3" IC plumbing, 4" ss exhaust, Autronic sm4/r500cdi engine management with 4 coils, and Magnaflow fuel system components. Also exedy tripple plate clutch, DSS axles and drive line... Thats about all I can think of for now. I will be doing a full write up on the build on here once I get the shop done.
The web site is just waiting on me to get more product on there and more pictures. I am going to start advertising on here when its all done. It is functional now though and I am going to be developing a full race style manifold for FC's when I do my car that will use larger tubing along with duel 44mm Tial wastegates and will be matched to my new exhaust sleeves for the best possible flow... Pretty exciting stuff coming up Im really stoked to get everything rolling!
Keep in touch Luke
Justin
Originally Posted by T04Eneedy
who made your manifold?how much?
I couldn't tell you how much, i'd have to kill you, j/k. Im not sure my friend left it when he moved and two years later I picked it up and made everything work!
PS: Boricua, dont be mad!!! ahhaha. j/k
