Non Turbo TPS location?
07-03-06, 02:29 PM
#1
pistons=teh suck
Thread Starter
Join Date: May 2003
Location: NJ
Posts: 933
Likes: 0
Received 0 Likes
on
0 Posts
Non Turbo TPS location?
Im following the adjustment write up on fc3s.org, but their pictures are of a TII. Can anyone tell me, or even better, post a picture of where it is?
07-03-06, 06:49 PM
#3
And the Revolution...
teamfc3s.org, has a factory service manual. Its on the throttle body just like the turbo. Looks just like the turbo one too. You should see the adjustment screw as well, it is round, not hexed with a flathead screwdriver slot. This is for S4's of course. S5's have 2 TPS's they're connected to each other tho.
Chris
Chris
07-04-06, 06:11 AM
#5
Banned. I got OWNED!!!
Join Date: Jun 2005
Location: Vallejo, CA
Posts: 759
Likes: 0
Received 0 Likes
on
0 Posts
Here you go. # 1 is a picture of it on the keyboard. # 2 is on the stove. # 3 is on my bed. # 4 is on the toilet. Pretty good huh! You can read it on the computer, while cooking, watching tv in bed, even while your taking a dump.
Very helpful book, use it anywhere in the house.
PEACE THE DOG
Very helpful book, use it anywhere in the house.
PEACE THE DOG
Trending Topics
07-04-06, 09:03 AM
#8
Rotary Enthusiast
Join Date: Mar 2004
Location: St Louis
Posts: 1,473
Likes: 0
Received 0 Likes
on
0 Posts
Originally Posted by sectachrome
Im following the adjustment write up on fc3s.org, but their pictures are of a TII. Can anyone tell me, or even better, post a picture of where it is?
Her it is, on the engine, right in the center. It has wires coming off of it and these things that look like buttons that can be pushed.
